replacement and/or system reset-
ting. (For models with the low tire
pressure warning system)
Do not install a deformed wheel or
tire even if it has been repaired. Such
wheels or tires could have structural
damage and could fail without warn-
ing.
The use of retread tire is not recom-
mended.
For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety In-
formation” (Canada) in the Warranty
Information Booklet.
Wheel balanceUnbalanced wheels may affect vehicle handling
and tire life. Even with regular use, wheels can
get out of balance. Therefore, they should be
balanced as required.
Wheel balance service should be performed
with the wheels off the vehicle. Spin balancing
the front wheels on the vehicle could lead to
transmission damage.For additional information regarding tires, refer to
“Important Tire Safety Information” (US) or “Tire
Safety Information” (Canada) in the Warranty
Information booklet.
Care of wheelsWash the wheels when washing the vehicle
to maintain their appearance.
Clean the inner side of the wheels when the
wheel is changed or the underside of the
vehicle is washed.
Do not use abrasive cleaners when washing
the wheels.
Inspect wheel rims regularly for dents or
corrosion. Such damage may cause loss of
pressure or poor seal at the tire bead.
NISSAN recommends that the road wheels
be waxed to protect against road salt in areas
where it is used during winter.Spare tire (T-type spare tire)Observe the following precautions if the T-type
spare tire must be used, otherwise your vehicle
could be damaged or involved in an accident.
CAUTION
The T-type spare tire should be used
only for emergency. It should be re-
placed by the standard tire at the first
opportunity.
Drive carefully while the T-type spare
tire is installed.
Avoid sharp turns and abrupt braking
while driving.
Periodically check the T-type spare
tire inflation pressure, and always
keep it at 60 psi (420 kPa, 4.2 bar).
Do not drive your vehicle at speeds
faster than 50 MPH (80 km/h).
Do not use tire chains on a T-type
spare tire. Tire chains will not fit
properly on the T-type spare tire and
may cause damage to the vehicle.
Tire tread of the T-type spare tire will
wear at a faster rate than the original
tire. Replace the T-type spare tire as
soon as the tread wear indicators
8-36
Maintenance and do-it-yourself
04.5.17/Z33-D/V5.0
Page 226 of 262
appear.
Because the T-type spare tire is
smaller than the original tire, ground
clearance is reduced. To avoid dam-
age to the vehicle do not drive over
obstacles. Also do not drive the ve-
hicle through an automatic car wash
since it may get stuck.
Do not use the T-type spare tire on
other vehicles.
Do not use more than one T-type
spare tire at the same time.
Do not tow a trailer while the T-type
spare tire is installed.
Maintenance and do-it-yourself
8-37
04.5.17/Z33-D/V5.0
Page 236 of 262
WHEELS AND TIRES
Road wheelModel Type Position SizeOffset
in (mm)
Coupe AluminumFront17 x 7-1/2JJ 1.18 (30)
18 x 8JJ* 1.18 (30)
Rear17 x 8JJ 1.30 (33)
18 x 8JJ* 1.18 (30)
18 x 8-1/2JJ* 1.30 (33)
Roadster AluminumFront17 x 7-1/2JJ 1.18 (30)
18 x 8JJ* 1.18 (30)
Rear17 x 8JJ 1.30 (33)
18 x 8JJ* 1.18 (30)TireModel Type Position Size Pressure (Cold)
CoupeConventionalFront 225/50R17 94W 240 kPa (35 psi)
Rear 235/50R17 96W 240 kPa (35 psi)
Front 225/45R18 91W* 240 kPa (35 psi)
Rear 245/45R18 96W* 240 kPa (35 psi)
Spare —T145/90D16 420 kPa (60 psi)
T155/80R17* 420 kPa (60 psi)
Road-
sterConventionalFront 225/50R17 94W 220 kPa (32 psi)
Rear 235/50R17 96W 220 kPa (32 psi)
Front 225/45R18 91W* 240 kPa (35 psi)
Rear 245/45R18 96W* 240 kPa (35 psi)
Spare — T145/90D16 420 kPa (60 psi)
*: For option
DIMENSIONS AND WEIGHTS
Coupe Roadster
Overall length in (mm) 169.6 (4,309) 169.6 (4,309)
Overall width in (mm) 71.5 (1,815) 71.5 (1,815)
Overall height in (mm) 51.9 (1,319) 52.3 (1,328)
Front tread in (mm) 60.4 (1,535) 60.4 (1,535)
Rear tread in (mm)60.6 (1,539)*1
60.8 (1,545)*260.6 (1,539)*1
60.8 (1,545)*2
Wheelbase in (mm) 104.3 (2,649) 104.3 (2,649)
Gross vehicle weight rating lb(kg)
See the F.M.V.S.S. certification label
on the driver’s side lock pillar. Gross axle weight rating
Front lb(kg)
Rear lb(kg)
*1: The wheel offset is 1.30 in (33 mm).
*2: The wheel offset is 1.18 in (30 mm).
Technical and consumer information
9-9
04.5.17/Z33-D/V5.0
Page 258 of 262
S
Safety
Child seat belts ................................................... 1-25
Reporting safety defects (US only)................ 9-22
Towing safety....................................................... 9-17
Seat
Belt warning light................................................ 1-23
Lever, Tilting passenger’s seat .......................... 1-7
Seat belt(s)
Child safety .......................................................... 1-25
Infants and small children ................................. 1-25
Injured persons.................................................... 1-26
Larger children .................................................... 1-26
Pre-tensioner seat belt system ....................... 1-19
Precautions on seat belt usage ...................... 1-23
Pregnant women ................................................. 1-26
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-28
Seat belt maintenance ...................................... 1-29
Seat belts ............................................................. 1-23
Three-point type.................................................. 1-26
Seat(s)
Heated seats........................................................ 2-26
Seats ........................................................................ 1-2
Ventilated net seats .............................................. 1-6
Secondary rear hatch release ................................ 3-10
Secondary trunk lid release .................................... 3-13
Security system, Vehicle security system ........... 2-17
Security systems (Nissan Vehicle Immobilizer
System), Engine start ............................................... 2-18
Servicing air conditioner ................................... 4-3, 4-6
Shift lock release ....................................................... 5-12
ShiftingAutomatic transmission .............................. 5-6, 5-9
Manual transmission ................................. 5-7, 5-12
Side air bag system (See supplemental side air bag
and curtain air bag system) .................................... 1-17
Soft top
Soft top care and cleaning ................................. 7-2
Soft top indicator light ........................... 2-16, 3-22
Soft top operation .............................................. 3-18
Care of the soft top and the vehicle body... 3-27
If the top does not open or close
electrically ............................................................. 3-24
Spark plugs................................................................. 8-17
Speed, Average speed............................................... 2-9
Speed, Speed indicator ............................................. 2-8
Speedometer ................................................................ 2-4
Starting
Before starting the engine .................................. 5-8
Jump starting .......................................................... 6-7
Precautions when starting and driving ............ 5-2
Push starting .......................................................... 6-9
Starting the engine ............................................... 5-8
Steering
Power steering fluid ........................................... 8-13
Power steering system ...................................... 5-19
Tilting steering wheel......................................... 3-15
Stopwatch ..................................................................... 2-9
Storage ........................................................................ 2-29
Stowing golf bags ..................................................... 2-34
Sun visor, Extension ................................................. 3-16
Sunglasses holder .................................................... 2-30
Supplemental air bag warning labels................... 1-20
Supplemental air bag warning light .......... 1-21, 2-14
Supplemental restraint system............................... 1-10Precautions on supplemental restraint
system.................................................................... 1-10
Supplemental side and curtain air bag
system .......................................................................... 1-17
Switch
Hazard warning flasher switch ........................ 2-25
Headlight switch ................................................. 2-23
Ignition switch ........................................................ 5-6
Ignition switch automatic transmission
models ............................................................ 5-6, 5-9
Ignition switch manual transmission
models .......................................................... 5-7, 5-12
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-21
Traction control system (TCS) off switch .... 2-27
Turn signal switch .............................................. 2-24
Vehicle dynamic control (VDC) off switch ... 2-27
T
Tachometer.................................................................... 2-5
Temperature gauge, Engine coolant temperature
gauge .............................................................................. 2-5
Theft (Nissan Vehicle Immobilizer System), Engine
start ............................................................................... 2-18
Three way catalyst ....................................................... 5-3
Tilting passenger’s seat ............................................. 1-7
Tilting steering wheel ............................................... 3-15
Tire
Flat tire ..................................................................... 6-2
Low tire pressure warning system........... 5-3, 6-2
Pressure indicator............................................... 2-10
Pressure, Low tire pressure warning light ... 2-13
04.5.17/Z33-D/V5.0
10-5
Page 259 of 262
Uniform tire quality grading .............................. 9-21
Tires
Spare tire .............................................................. 8-36
Tire chains ............................................................ 8-34
Tire pressure ........................................................ 8-30
Tire rotation .......................................................... 8-34
Types of tires ....................................................... 8-33
Wheel/tire size ....................................................... 9-9
Wheels and tires ................................................ 8-30
Top
If the top does not open or close
electrically ............................................................. 3-24
Soft top operation .............................................. 3-18
Top latch lever ..................................................... 3-21
Top tether strap child restraint........................ 1-36
Towing
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-16
Towing load/specification chart ...................... 9-16
Towing safety....................................................... 9-17
Traction control system (TCS)............................... 5-22
Traction control system (TCS) off switch ........... 2-27
Trailer towing .............................................................. 9-16
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-39
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Transmission selector lever lock release ...... 5-12
Transmitter (See remote keyless entry system) ... 3-4
Traveling or registering your vehicle in another
country ......................................................................... 9-10
Trip computer ............................................................... 2-8Trip odometer ............................................................... 2-9
Trunk
Interior trunk lid release .................................... 3-12
Secondary trunk lid release ............................. 3-13
Turn signal switch ..................................................... 2-24
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-21
Up-shift indicator (M/T models) ............................ 5-13
Up-shift indicator setting (rpm) (M/T models) ... 2-10
V
Vanity mirror light ...................................................... 2-38
Vehicle
Dimensions and weights ..................................... 9-9
Identification number (VIN)............................... 9-10
Loading information............................................ 9-14
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-17
Vehicle dynamic control (VDC) off switch ... 2-27
Vehicle dynamic control (VDC) system ........ 5-22
Ventilated net seats..................................................... 1-6
Ventilators ...................................................................... 4-2
Volt meter ...................................................................... 2-7
W
Warning labels, Air bag warning labels .............. 1-20
Warning light
Air bag warning light .............................. 1-21, 2-14Anti-lock brake warning light ........................... 2-11
Brake warning light ............................................ 2-12
Door open warning light ................................... 2-12
Low tire pressure warning light ...................... 2-13
Warning lights ............................................................ 2-11
Warning, Hazard warning flasher switch ............ 2-25
Warning, Low tire pressure warning
system.................................................................... 5-3, 6-2
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-11
Warranty, Emission control system warranty ..... 9-22
Washer switch
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-9
Wheel/tire size.............................................................. 9-9
Wheels and tires ....................................................... 8-30
Cleaning aluminum alloy wheels ....................... 7-4
Window washer fluid ............................................... 8-14
Window(s)
Automatic adjusting function ........................... 2-37
Cleaning................................................................... 7-3
Power windows................................................... 2-35
Windshield wiper and washer switch .................. 2-20
Wiper
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Wiper blades ....................................................... 8-19
X
Xenon headlights....................................................... 2-22
04.5.17/Z33-D/V5.0
10-6
