2004 Mercury Marauder key

²O/D OFF lamp is illuminated.
²Provides engine braking.
²Use when driving conditions cause excessive shifting from O/D to
other gears. Examples: city traffic, hilly terrain, heavy loads, trailer
towing and when engine braking is required.
²To return to O/D (overdrive mode), press the transmission control
switch. The O/D OFF lamp will not be illuminated.
²O/D (Overdrive) is automatically returned each time the key is turned
off.
2 (Second)
This position allows for second gear only.
²Provides engine braking.
²Use to start-up on slippery roads.
²To return to D (Overdrive), move the gearshift lever into the D
(Overdrive) position.
²Selecting 2 (Second) at higher speeds will cause the transmission to
downshift to second gear at the appropriate vehicle speed.
1 (First)
²Provides maximum engine braking.
²Allows upshifts by moving gearshift lever.
²Will not downshift into 1 (First) at high speeds; allows for 1 (First)
when vehicle reaches slower speeds.
Forced downshifts
²Allowed in D (Overdrive) or Drive.
²Depress the accelerator to the floor.
²Allows transmission to select an appropriate gear.
If your vehicle gets stuck in mud or snow
If your vehicle gets stuck in mud or snow, it may be rocked out by
shifting from forward and reverse gears, stopping between shifts in a
steady pattern. Press lightly on the accelerator in each gear.
Do not rock the vehicle if the engine is not at normal operating
temperature or damage to the transmission may occur.
O/ D
OFF
2004 Marauder(mdr)
Owners Guide (post-2002-fmt)
USA English(fus)
Driving
121

The fuel pump shut-off switch is
located on the left side of the trunk
behind the left rear tail light and the
trunk liner.
Use the following procedure to reset the fuel pump shut-off switch.
1. Turn the ignition to the OFF position.
2. Check the fuel system for leaks.
3. If no fuel leak is apparent, reset the fuel pump shut-off switch by
pushing in on the reset button.
4. Turn the ignition to the ON position. Pause for a few seconds and
return the key to the OFF position.
5. Make a further check for leaks in the fuel system.
FUSES AND RELAYS
Fuses
If electrical components in the
vehicle are not working, a fuse may
have blown. Blown fuses are
identified by a broken wire within
the fuse. Check the appropriate
fuses before replacing any electrical
components.
15
2004 Marauder(mdr)
Owners Guide (post-2002-fmt)
USA English(fus)
Roadside Emergencies
131

Working with the engine off
1. Set the parking brake and shift to P (Park).
2. Turn off the engine and remove the key.
3. Block the wheels.
Working with the engine on
1. Set the parking brake and shift to P (Park).
2. Block the wheels.
Note:Do not start your engine with the air cleaner removed and do not
remove it while the engine is running.
OPENING THE HOOD
1. Inside the vehicle, pull the hood
release handle located under the
instrument panel.
2. Go to the front of the vehicle and
release the auxiliary latch that is
located under the front of the hood.
3. Lift the hood until the lift
cylinders hold it open.
2004 Marauder(mdr)
Owners Guide (post-2002-fmt)
USA English(fus)
Maintenance and Specifications
167

Exhaust fumes ..........................111
F
Floor mats ...................................59
Fluid capacities .........................208
Foglamps .....................................28
Fuel ............................................181
calculating fuel
economy ............................43, 185
cap ...........................................182
capacity ...................................208
choosing the right fuel ...........183
comparisons with EPA fuel
economy estimates .................188
detergent in fuel .....................184
filling your vehicle with
fuel ...........................181±182, 185
filter, specifications ........185, 207
fuel pump shut-off switch .....130
improving fuel economy ........185
octane rating ...................184, 211
quality ......................................184
running out of fuel .................184
safety information relating to
automotive fuels .....................181
Fuses ..................................131±132
G
Garage Door Opener
(see Homelink wireless control
system) ........................................54
Gas cap (see Fuel cap) ............182
Gas mileage
(see Fuel economy) .................185
Gauges .........................................13
H
Hazard flashers .........................130Head restraints ...........................74
Headlamps ...................................27
aiming ........................................29
autolamp system .......................27
bulb specifications ....................32
daytime running lights .............28
flash to pass ..............................29
high beam .................................28
replacing bulbs .........................33
turning on and off ....................27
Heating
heating and air conditioning
system .......................................24
HomeLink universal
transceiver (see Garage door
opener) ..................................44, 57
Homelink wireless control
system ..........................................54
Hood ..........................................167
I
Ignition ...............................108, 211
Infant seats (see Safety seats) ..99
Inspection/maintenance (I/M)
testing ........................................190
Instrument panel
cleaning ...................................163
cluster ........................................10
lighting up panel and
interior .......................................29
J
Jack ............................................139
positioning ...............................139
storage .....................................139
Jump-starting your vehicle ......145
K
Keyless entry system .................68
2004 Marauder(mdr)
Owners Guide (post-2002-fmt)
USA English(fus)
Index
220

autolock .....................................67
keypad .......................................68
programming entry code .........68
Keys .......................................70±72
positions of the ignition .........108
L
Lamps
autolamp system .......................27
bulb replacement
specifications chart ..................32
daytime running light ...............28
fog lamps ...................................28
headlamps .................................27
headlamps, flash to pass ..........29
instrument panel, dimming .....29
interior lamps .....................31±32
replacing bulbs ...................32±37
Lane change indicator
(see Turn signal) ........................31
Lights, warning and indicator ....10
anti-lock brakes (ABS) ..........113
Limited-slip axle .......................122
Load limits .................................122
Locks
autolock .....................................67
childproof ..................................61
doors ..........................................60
Lubricant specifications ...209, 211
Lumbar support, seats ...............74
M
Mirrors
automatic dimming rearview
mirror ........................................49
fold away ...................................49
heated ........................................49
side view mirrors (power) .......49Moon roof ....................................54
Motorcraft parts ................185, 207
O
Octane rating ............................184
Oil (see Engine oil) ..................169
P
Panic alarm feature, remote
entry system ................................64
Parking brake ............................114
Parts (see Motorcraft parts) ....207
Pedals (see Power adjustable
foot pedals) .................................50
Power adjustable foot pedals .....50
Power distribution box
(see Fuses) ...............................135
Power door locks ..................60, 67
Power mirrors .............................49
Power Point
Cigar lighter ..............................47
Power steering ..................116±117
fluid, checking and adding ....190
fluid, refill capacity ................208
fluid, specifications .................209
Power Windows ...........................48
R
Radio ............................................17
Rear window defroster ...............26
Relays ................................131, 138
Remote entry system ...........62, 64
illuminated entry ......................66
locking/unlocking doors .....60, 63
2004 Marauder(mdr)
Owners Guide (post-2002-fmt)
USA English(fus)
Index
221
