2004 MERCEDES-BENZ SL600 service indicator

ContentsOperation......................................... 237
The first 1000 miles (1500 km) ......... 238
Driving instructions ............................ 239
Drive sensibly – save fuel ............. 239
Drinking and driving ..................... 239
Pedals .......................................... 239
Power assistance ......................... 240
Brakes .......................................... 240
Driving off..................................... 242
Parking ......................................... 242
Tires ............................................. 243
Hydroplaning ................................ 243
Tire traction .................................. 244
Tire speed rating .......................... 244
Winter driving instructions ........... 245
Standing water ............................. 246
Passenger compartment .............. 246
Driving abroad .............................. 246Control and operation of radio
transmitters ................................. 247
Catalytic converter ....................... 247
Emission control .......................... 248
Coolant temperature .................... 249
At the gas station .............................. 250
Refuelling ..................................... 250
Check regularly and before
a long trip ..................................... 252
Engine compartment ......................... 253
Hood ............................................ 253
Engine oil ..................................... 255
Transmission fluid level ................ 258
Oil level in the ABC system .......... 258
Coolant ........................................ 258
Battery ......................................... 260
Windshield washer system and
headlamp cleaning system ........... 261Tires and wheels................................ 262
Important guidelines .................... 262
Life of tires................................... 263
Direction of rotation..................... 263
Checking tire inflation pressure ... 263
Rotating wheels ........................... 267
Winter driving .................................... 268
Winter tires .................................. 268
Block heater (Canada only) .......... 269
Snow chains................................. 269
Maintenance...................................... 271
Clearing the service indicator ...... 271
Service term exceeded ................ 272
Calling up the service indicator .... 272
Resetting the service indicator .... 272
Vehicle care....................................... 274
Cleaning and care of the vehicle .. 274

Contents
Practical hints................................. 281
What to do if … .................................. 282
Lamps in instrument cluster ........ 282
AIRBAG OFF indicator lamp ......... 290
Messages in the display ............... 291
Where will I find ...? ........................... 323
First aid kit ................................... 323
Vehicle tool kit, jack, and spare
wheel ........................................... 323
Locking/unlocking in an emergency . 325
Unlocking the vehicle ................... 325
Locking the vehicle ...................... 327
Lowering the load assist manually 327
Replacing batteries in the
SmartKey/SmartKey with
KEYLESS-GO* .............................. 328
Replacing bulbs ................................. 331
Bulbs ............................................ 331
Replacing bulbs for front lamps ... 334
Replacing bulbs for rear lamps..... 335Replacing wiper blades....................... 337
Removing wiper blades ................. 337
Installing wiper blades .................. 338
Flat tire ............................................... 339
Preparing the vehicle .................... 339
Sealing tires with TIREFIT kit 1...... 340
Sealing tires with TIREFIT kit 2...... 345
Mounting the spare wheel ............ 350
Batteries ............................................. 358
Disconnecting the batteries .......... 360
Removing the batteries ................. 361
Charging and reinstalling
batteries ....................................... 361
Reconnecting the batteries ........... 361
Jump starting ...................................... 363
Towing the vehicle .............................. 365
Installing towing eye bolt .............. 368
Fuses .................................................. 369
Main fuse box ............................... 369
Technical data.................................. 371
Spare parts service ............................ 372
Warranty coverage ............................. 373
Loss of Service and Warranty
Information Booklet ...................... 373
Identification labels ............................ 374
Layout of poly-V-belt drive.................. 375
SL 500 .......................................... 375
SL 55 AMG ................................... 375
SL 600 .......................................... 375
Engine ................................................ 376
Rims and tires .................................... 378
Same size tires ............................. 379
Mixed size tires ............................. 380
Spare wheel .................................. 382
Electrical system ................................ 383
Main dimensions ................................ 384
Weights .............................................. 385

85 Safety and Security
Anti-theft systems
Anti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens

a door


the trunk lid


the hood


a storage compartment in the rear


the glove box


the storage compartment under the
armrest
The alarm will stay on, even if the activat-
ing element (a door, for example) is imme-
diately closed.The alarm system will also be triggered
when


someone attempts to raise the vehicle


unlocking and opening the driver’s
door with the mechanical key


someone opens a door from the inside
if the vehicle was locked from the out-
side with the SmartKey


someone opens the trunk lid with the
emergency release buttonArming the alarm system
The alarm system is armed after locking
the vehicle with the SmartKey or
KEYLESS-GO*. The turn signal lamps flash
three times to indicate that the alarm sys-
tem is activated. The ‹ indicator lamp
in the central locking switch (
page 25)
begins to flash after arming the alarm sys-
tem.
iIf the alarm stays on for more than
20 seconds, an emergency call is initi-
ated automatically by the Tele Aid sys-
tem (
page 225) provided Tele Aid
service was subscribed to and properly
activated, and that necessary cellular
service and GPS coverage are avail-
able.
iIf the turn signal lamps do not flash
three times, a door or the trunk lid may
not be properly closed.
Close the respective element and lock
the vehicle again.

225 Controls in detail
Useful features
Emergency calls
An emergency call is initiated
automatically

following an accident in which the
emergency tensioning devices (ETDs)
or airbags have deployed


if the anti-theft alarm or the tow-away
alarm stays on for more than
20 seconds, see “Anti-theft alarm sys-
tem” (
page 85) and
“Tow-away alarm” (
page 86)
An emergency call can also be initiated
manually by opening the cover next to the
inside rear view mirror labeled SOS, then
briefly pressing the button located under
the cover.
For more information, see “Initiating an
emergency call manually” (page 226).Once the emergency call is in progress, the
indicator lamp in the SOS button will begin
to flash. The message
Emergency call –
Connecting call
appears in the multifunc-
tion display. When the connection is estab-
lished, the message
Emergency call –
Call connected
appears in the multifunc-
tion display. All information relevant to the
emergency, such as the location of the ve-
hicle (determined by the GPS satellite loca-
tion system), vehicle model, identification
number and color are generated.
A voice connection between the Response
Center and the occupants of the vehicle
will be established automatically soon af-
ter the emergency call has been initiated.
When a voice connection is established,
the audio system mutes and the message
Tele Aid - Emergency call active
ap-
pears in the multifunction display. The Re-
sponse Center will attempt to determine
more precisely the nature of the accident
provided they can speak to an occupant of
the vehicle.The Tele Aid system is available if


it has been activated and is operation-
al. Activation requires a subscription
for monitoring services, connection
and cellular air time


the relevant cellular phone network
and GPS signals are available and pass
the information on to the Response
CenteriLocation of the vehicle on a map is only
possible if the vehicle is able to receive
signals from the GPS satellite network
and pass the information on to the Re-
sponse Center.

227 Controls in detail
Useful features
Roadside Assistance button •
The Roadside Assistance button• is
located below the center armrest cover.
Press and hold the button (for longer
than two seconds)
A call to a Mercedes-Benz Roadside
Assistance dispatcher will be initiated.
The button will flash while the call is in
progress. The message
Roadside as-
sistance – Connecting call
will ap-
pear in the multifunction display.
When the connection is established, the
message
Roadside assistance –
Call connected
appears in the multifunc-
tion display. The Tele Aid system will trans-
mit data generating the vehicle
identification number, model, color and lo-
cation (subject to availability of cellular
and GPS signals).A voice connection between the Roadside
Assistance dispatcher and the occupants
of the vehicle will be established. When a
voice connection is established the audio
system mutes and the message
Tele Aid
Roadside assistance call active
ap-
pears in the multifunction display.

Describe the nature of the need for as-
sistance.
The Mercedes-Benz Roadside Assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest authorized
Mercedes-Benz Center. For services such
as labor and / or towing, charges may ap-
ply. Refer to the Roadside Assistance Man-
ual for more information.These programs are only available in the
USA:


Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.


Remote Vehicle Diagnostics: This func-
tion permits the Mercedes-Benz
Roadside Assistance dispatcher to
download malfunction codes and actu-
al vehicle data.iThe indicator lamp in the Roadside
Assistance button• remains illumi-
nated in red for approximately ten sec-
onds during the system self-check after
switching on the ignition (together with
the SOS button and the Information
button¡).
See system self-check (
page 224) if
the indicator lamp does not come on in
red or stays on longer than approxi-
mately ten seconds.

228 Controls in detailUseful features
Information button ¡
The Information button¡ is located be-
low the center armrest cover.
Press and hold the button (for longer
than two seconds).
A call to the Customer Assistance Cen-
ter will be initiated. The button will
flash while the call is in progress. The
message
Info – Connecting call
will
appear in the multifunction display.
When the connection is established, the
message
Info – Call connected
appears
in the multifunction display. The Tele Aid
system will transmit data generating the
vehicle identification number, model, color
and location (subject to availability of cel-
lular and GPS signals).
A voice connection between the Customer
Assistance Center representative and the
occupants of the vehicle will be estab-
lished. When a voice connection is estab-
lished the audio system mutes and the
message
Tele Aid – Info call active
appears in the multifunction display. Information regarding the operation of
your vehicle, the nearest Mercedes-Benz
Center or Mercedes-Benz USA products
and services is available to you.
For more details concerning the Tele Aid
system, please visit www.mbusa.com and
use your ID and password (sent to you sep-
arately) to learn more (USA only). If the indicator lamp in the Roadside
Assistance button• is illuminated
continuously and there was no voice
connection to the Response Center es-
tablished, then the Tele Aid system
could not initiate a Roadside Assis-
tance call (e.g. the relevant cellular
phone network is not available). The
message
Roadside assistance –
Call failed
appears in the multifunc-
tion display.
Roadside Assistance calls can be ter-
minated using the ìbutton on the
multifunction steering wheel.
iThe indicator lamp in the Information
button¡ remains illuminated in red
for approx. ten seconds during the sys-
tem self-check after switching on the
ignition (together with the SOS button
and the Roadside Assistance
button•).
See system self-check (
page 224) if
the indicator lamp does not come on in
red or stays on longer than approxi-
mately ten seconds.
If the indicator lamp in the Information
button¡ is illuminated continuous-
ly and no voice connection to the

229 Controls in detail
Useful features
Upgrade Signals
The Tele Aid system processes calls using
the following priority.

Automatic emergency – First priority


Manual emergency – Second priority


Roadside assistance – Third priority


Information – Fourth priority
Should a higher priority call be initiated
while you are connected, an upgrade (al-
ternating) tone will be heard, and the ap-
propriate indicator lamp will flash. If
certain information such as vehicle identi-
fication number or customer information is
not available, the operator may need to re-
transmit.
During this time you will hear a beep and
voice contact will be interrupted. Voice
contact will resume once the retransmis-
sion is completed. Once a call is conclud-
ed, a beep will be heard, and the respective
indicator lamp will stop flashing. The
COMAND system operation will resume. Response Center was established, then
the Tele Aid system could not initiate
an Information call (e.g. the relevant
cellular phone network is not avail-
able). The message
Info Call failed
appears in the multifunction display.
Information calls can be terminated us-
ing the ìbutton on the multifunc-
tion steering wheel.!If the indicator lamps do not start flash-
ing after pressing one of the buttons or
remain illuminated (in red) at any time,
the Tele Aid system has detected a
malfunction or the service is currently
not active, and may not initiate a call.
Visit your Mercedes-Benz Center and
have the system checked or contact
the Response Center at
1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada) as soon
as possible.
!If the indicator lamp continues to flash
or the system does not reset, contact
the Response Center at
1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada), or
Mercedes-Benz Customer Assistance
at 1-800-FOR-MERCedes
(1-800-367-6372) in the USA or
Customer Service at 1-800-387-0100
in Canada.iThe indicator lamp in the respective
button flashes until the call is conclud-
ed. Calls can only be terminated by a
Response Center or Customer Assis-
tance Center representative except
Roadside Assistance and Information
calls, which can also be terminated by
pressing button ì on the multifunc-
tion steering wheel.

231 Controls in detail
Useful features
Stolen vehicle tracking services
In the event your vehicle was stolen:
Report the incident to the police
The police will issue a numbered inci-
dent report.

Pass this number on to the
Mercedes-Benz Response Center along
with your password issued to you when
you subscribed to the service.
The Response Center will then attempt
to covertly contact the vehicle’s Tele
Aid system. Once the vehicle is locat-
ed, the Response Center will contact
the local law enforcement and you. The
vehicle’s location will only be provided
to law enforcement.
Garage door opener
The built-in remote control is capable of
operating up to three separately controlled
devices, for example garage door openers,
gate openers, or other devices compatible
with HomeLink
® or some other systems.
You can program the signal transmitter
buttons.
Remote control integrated into the interior
rear view mirror1Indicator lamp
2 3 4Signal transmitter button
5Hand-held transmitter button
6Hand-held remote control trans-
mitter (not part of the vehicle
equipment)
