Contents
Control system .................................. 129
Multifunction display .................... 129
Multifunction steering wheel ........ 130
Menus .......................................... 132
Standard display menu ................ 134
AUDIO menu ................................ 134
NAVI* menu ................................. 136
Distronic* menu........................... 136
Malfunction memory menu .......... 137
Settings menu .............................. 138
Trip computer menu..................... 153
TEL menu* ................................... 155
Automatic transmission ..................... 158
One-touch gearshifting................. 159
Gear ranges ................................. 160
Gear selector lever position ......... 161
Steering wheel gearshift control
(Speedshift) E 55 AMG ................. 162
Program mode selector switch..... 164
Accelerator position ..................... 164
Manual shift program E 55 AMG .. 165
Emergency operation
(Limp Home Mode) ...................... 167Good visibility ..................................... 168
Rear view mirror ........................... 168
Windshield wipers ......................... 169
Headlamp cleaning system* ......... 170
Sun visors ..................................... 170
Rear window sunshade* ............... 172
Roller sunblind* in the rear doors . 172
Rear window defroster .................. 173
Climate control ................................... 174
Setting the temperature................ 178
Adjusting air distribution............... 178
Adjusting air volume ..................... 179
Defrosting ..................................... 179
Air recirculation mode .................. 180
Deactivating the climate
control system .............................. 181
Air conditioning............................. 182
Residual heat and ventilation* ...... 182Automatic climate control* ................ 184
Setting the temperature ............... 188
Adjusting air distribution .............. 189
Adjusting air volume ..................... 190
Maximum cooling MAX COOL ....... 190
Defrosting ..................................... 190
Air recirculation mode .................. 191
Charcoal filter ............................... 192
Deactivating the climate
control system .............................. 193
Air conditioning ............................ 194
Residual heat and ventilation ........ 194
Rear air conditioning..................... 195
Power windows .................................. 197
Opening and closing the windows 197
Synchronizing power windows ...... 200
Sliding / pop-up roof* ......................... 201
Opening and closing the
sliding / pop-up roof ...................... 201
Synchronizing the
sliding / pop-up roof ...................... 204

43 Getting started
Driving
Starting the engine Automatic transmission
Gearshift pattern for automatic
transmissionPPark position with gear selector lever
lock
RReverse gear
NNeutral
DDrive position
More information can be found in the
“Controls in detail” section (
page 160).
Warning!
G
Do not pass belts over sharp edges. They
could tear.
Do not allow the belt to get caught in the
door or in the seat adjustment mechanism.
This could damage the belt.
Never attempt to make modifications to
seat belts. This could impair the effective-
ness of the belts.
Damaged seat belts or belts that were highly
stressed in an accident must be replaced.
Contact an authorized Mercedes-Benz Cen-
ter.
Warning!
G
Inhalation of exhaust gas is hazardous to
your health. All exhaust gas contains carbon
monoxide, and inhaling it can cause uncon-
sciousness and lead to death.
Do not run the engine in confined areas
(such as a garage) which are not properly
ventilated. If you think that exhaust gas
fumes are entering the vehicle while driving,
have the cause determined and corrected
immediately. If you must drive under these
conditions, drive only with at least one win-
dow fully open.

159 Controls in detail
Automatic transmission
One-touch gearshifting
Even with an automatic transmission you
can change the gears manually when the
gear selector lever is in positionD.
Downshifting
Briefly press the gear selector lever to
the left in theD-direction.
The transmission will shift from the current
gear to the next lower gear. This action
simultaneously limits the gear range of the
transmission (
page 160).Upshifting

Briefly press the gear selector lever to
the right in theD+direction.
The transmission will shift from the current
gear to the next higher gear as permitted
by the shift program. This action simul-
taneously extends the gear range of the
transmission.Canceling gear range limit

Press and hold the gear selector lever
in theD+direction until
D reappears in
the multifunction display.
The transmission will shift from the current
gear range directly to gear rangeD.
Shifting into optimal gear range

Press and hold the gear selector lever
in theD-direction.
The transmission will automatically select
the gear range suited for optimal
acceleration and deceleration. This will
involve shifting down one or more gears.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.
iTo avoid overrevving the engine when
the gear selector lever is moved to
theD-direction, the transmission will
not shift to a lower gear if the engine’s
max. speed would be exceeded.

162 Controls in detailAutomatic transmission
Steering wheel gearshift control (Speedshift) E 55 AMG
You can change the gears manually on the
steering wheel or by using the gear
selector lever (
page 159).
Allow engine to warm up under low load
use. Do not place full load on the engine
until the operating temperature has been
reached. Shift into reverse gear only when
the vehicle is stopped.
!Coasting the vehicle, or driving for any
other reason with gear selector lever
inN can result in transmission damage
that is not covered by the
Mercedes-Benz Limited Warranty.Warning!
G
Getting out of your vehicle with the gear
selector lever not fully engaged in positionP
is dangerous. Also, positionP alone is not
intended to or capable of preventing your
vehicle from moving, possibly hitting people
or objects.
Always set the parking brake in addition to
shifting to positionP (
page 51).
When parked on an incline, turn the front
wheels towards the road curb.
Do not park this vehicle in areas where com-
bustible materials such as grass, hey or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could move the
gear selector lever from positionP, which
could result in an accident and/or serious
personal injury.
!Avoid spinning of a drive wheel for an
extended period when driving off on
slippery road surfaces. This may cause
serious damage to the drive train which
is not covered by the Mercedes-Benz
Limited Warranty.

163 Controls in detail
Automatic transmission
The steering wheel gearshift buttons are
located to the left and right of the steering
wheel.
1Left button: downshift
2Right button: upshiftDownshifting

Press button1 on the left side of the
steering wheel.
The gear range is limited when you are not
driving in the manual program mode
(
page 160).
When driving in the manual program mode
(page 165), the transmission will shift
from the current gear to the next lower
gear (
page 166).Upshifting

Press button2 on the right side of the
steering wheel.
The gear range is extended when you are
not driving in the manual program mode
(
page 160).
When driving in the manual program mode
(page 165), the transmission will shift
from the current gear to the next higher
gear (
page 166).
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.iYou cannot shift with the steering
wheel gearshift buttons when the gear
selector lever is in positionP,N orR.
iYou cannot shift with the steering
wheel gearshift buttons when the gear
selector lever is in positionP,N orR.

414 Technical termsMultifunction display
The display field in the instrument clus-
ter used to present information provid-
ed by the control system.
Multifunction steering wheel
Steering wheel with buttons for operat-
ing the control system.
Overspeed range
Engine speeds within the red marking
on the tachometer dial. Avoid this en-
gine speed range, as it may result in se-
rious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.Power train
Collective term designating all compo-
nents used to generate and transmit
motive power to the drive axles, includ-
ing:


Engine


Clutch/torque converter


Transmission


Transfer case*


Drive shaft


Axle shafts/axles
Program mode selector switch
Used to switch the automatic transmis-
sion between standard operationS and
operationC.
E 55 AMG with steering wheel gearshift
control and manual shift program: in
addition to S and C (for sporty S or
comfortable C operation), you can use
M for manual shift program.Remote Vehicle Diagnostics
Transmission of vehicle data and cur-
rent location to the Mercedes-Benz
Customer Assistance Center for sub-
scribers to the Tele Aid service.
Restraint systems
Seat belts, belt tensioners, airbags and
child restraint systems. As indepen-
dent systems, their protective func-
tions complement one another.
RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired detona-
tion (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.

419 Index
Manual shift program mode
(SL 55 AMG Kompressor) 165
Manual shifting 159
One-touch gearshifting 159
Program mode selector switch 164
Selector lever position 158
Starting the engine 43
Winter program mode 164
B
BabySmartTM
Airbag deactivation system 67
Compatible child seats 411
Self-test 68
BabySmartTM airbag deactivation
system 411
Backrest
Folding forward 236
Folding rearward 238
BAS 76, 411
Batteries, SmartKey
Changing 355, 356
Check lamp 90, 94
Checking 91, 96Batteries, SmartKey with KEYLESS-GO*
Changing 355, 356
Checking 91, 96
Batteries, vehicle
Charging 377
Disconnecting 376
Messages in display 320, 324, 325
Reconnecting 377
Removing 377
Service 375
Battery discharged
Jump starting 378
Bi-Xenon headlamps* 411
Block heater* 296
Blocking
Rear window operation 72
Brake assist system (BAS) 411
Brake fluid 279, 328
Brake pads
Message in display 326
Brakes
Warning lamp 312
Break-in period 266Bulbs, replacing
Additional turn signals 359
Fog lamps 359
Front lamps 359, 361
High beam 359
High beam bulb (Bi-Xenon* headlamps
only) 362
High beam bulb (Halogen headlamps
only) 362
High mounted brake lamp 360
License plate lamps 360, 363
Low beam 359
Parking lamps 360, 362
Side marker lamps 359, 363
Standing lamps 360, 362
Tail lamp 360
Tail lamp assemblies 363
Turn signal lamp 359

430 Index
Coolant 330, 331
Coolant level 329
Distronic* 320
Doors 332
Easy-entry/exit feature 327, 347
Fuel reserve tank 335
Hood 335
Lamps 338–??
Parking brake 327
SBC brake system 326, 327
SmartKey 336
SmartKey with KEYLESS-GO* 335
Steering gear oil level 347
Tele Aid 345, 346
Telephone* 346
Tires 342
Trunk 347
Washer fluid 347
Multifunction steering wheel 24, 130,
414
Buttons 130
Navigation system
See separate COMAND operating
instructions 136
Night security illumination 121O
Occupant safety 56
Airbags 57
Children and airbags 58
Children in the vehicle 65
Fastening the seat belt 40
Infant and child restraint systems 65
LATCH child seat anchors 71
Seat belts 40, 60
Oil
Adding 284
Checking level 283
Consumption 282
Filler neck 284
Viscosity 412
Oil level
Checking 283
One-touch gearshifting 159
Canceling gear range limit 159
Downshifting 159
Upshifting 159Opening 358
Ashtray 246
Doors from the inside 97
Fuel filler flap 278
Fuel filler flap manually 357
Glove box 242
Panorama sliding/pop-up roof 206
Panorama sliding/pop-up roof* in an
emergency 358
Roller sunblinds 205
Side windows 198
Sliding/pop-up roof* 201
Sliding/pop-up roof* in an
emergency 358
Sliding/pop-up roof* with
SmartKey 202
Trunk 97
Trunk from the inside 98
Trunk lid with SmartKey 90
Windows 197
Windows with SmartKey 199
