2004 MERCEDES-BENZ CLK-CLASS run flat

Contents
Maintenance...................................... 302
Clearing the service indicator ...... 302
Service term exceeded ................ 302
Calling up the service indicator .... 303
Resetting the service indicator..... 303
Vehicle care ....................................... 304
Cleaning and care of vehicle ........ 304
Practical hints.................................. 311
What to do if …? ................................. 312
Lamps in instrument cluster ......... 312
Lamp in center console................. 319
Messages in the display ................ 320
Where will I find...? ............................. 343
First aid kit.................................... 343
Vehicle tool kit .............................. 343
Minispare wheel............................ 346
Unlocking/locking in an emergency... 348
Unlocking the vehicle.................... 348
Locking the vehicle ....................... 349
Changing batteries in
the SmartKey/ SmartKey
with KEYLESS-GO* ....................... 350
Fuel filler flap ................................ 352
Manually unlocking
the gear selector lever .................. 352
Opening/closing in an emergency ..... 353
Operating roll bars manually ......... 353
Soft top emergency operation ...... 355Replacing bulbs .................................. 372
Bulbs............................................. 372
Replacing bulbs for front lamps .... 374
Side marker lamp bulb.................. 377
Replacing bulbs for rear lamps ..... 378
Replacing wiper blades ...................... 379
Removing wiper blades ................. 379
Installing wiper blades .................. 379
Flat tire............................................... 380
Preparing the vehicle .................... 380
Mounting the Minispare wheel...... 380
Battery ............................................... 385
Disconnecting the battery ............ 386
Removing the battery ................... 386
Charging and reinstalling battery .. 386
Reconnecting the battery ............. 387
Jump starting...................................... 388
Towing the vehicle.............................. 390
Towing the vehicle ........................ 390
Installing towing eye bolt .............. 392
Fuses.................................................. 394
Fuse box in
passenger compartment ............... 394
Fuse box in engine compartment . 395
Auxiliary fuse box in trunk ............ 396
ProCarManuals.com

100 Controls in detailLocking and unlockingClosing the trunk
1Handle
Lower trunk lid by pulling firmly on
handle1.

Close trunk lid with hands placed flat
on it.
Trunk lid opening/closing system*
Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.41 ft
(1.65 m) is required to open the trunk lid.
The switch for opening and closing the
trunk is located on the driver’s door.
1Remote trunk lid opening switch
2Remote trunk lid closing switch
Press remote trunk lid opening
switch1 until the trunk lid begins to
open.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.
Warning!
G
Only drive with the trunk closed. Among oth-
er dangers, such as your view being blocked,
exhaust fumes may enter the vehicle
interior.iDo not place the SmartKey in the open
trunk. You may lock yourself out.iVehicles with KEYLESS-GO*:
To prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO* is
recognized inside the vehicle or in the
trunk.
ProCarManuals.com

247 Controls in detail
Loading
aStrap
Tighten strapa by pulling at the loose
end (arrow) until the skis in the ski sack
are tightly secured.bHook
cEye

Connect hookb to eyec located on
center tunnel in front of rear seat
bench.

Tighten strap by pulling at the loose
end (arrow).Unloading and folding

Loosen both straps.

Disconnect hookb from eyec.

Unload skis.

Close flap8 in trunk.

Fold and flatten ski sack lengthwise.

Place folded ski sack inside recess of
backrest.

Fasten velcro strap

Close ski sack compartment cover.
ProCarManuals.com

347 Practical hints
Where will I find...?
In the case of a flat tire, you may tempo-
rarily use the Minispare wheel when ob-
serving the following restrictions:

Do not exceed a vehicle speed of
50 mph (80 km/h).


Drive to the nearest tire repair facility
to have the flat tire repaired or re-
placed as appropriate.


Do not operate vehicle with more than
one Minispare wheel mounted.
More information can be found in the
“Technical data” section (
page 403).
Minispare wheel bolts
1Wheel bolt for light alloy rims
2Wheel bolt for Minispare wheel or other
steel rims (located in trunk with spare
wheel)
!To prevent damage, always disengage
trunk floor handle from upper edge of
trunk and lower trunk floor before clos-
ing the trunk lid.Warning!
G
The dimensions of the Minispare wheel are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a Minispare wheel
mounted.
The Minispare wheel should only be used
temporarily, and should be replaced with a
regular road wheel as quickly as possible.
!Wheel bolts2 must be used when
mounting the Minispare wheel. The use
of any wheel bolts other than wheel
bolts2 for the Minispare will physical-
ly damage the vehicle's brakes.Warning!
G
Make sure to use the original length wheel
bolts when remounting the original wheel af-
ter it has been repaired.
ProCarManuals.com

380 Practical hintsFlat tire
Flat tirePreparing the vehicle
Park the vehicle as far as possible from
moving traffic on a hard surface.

Turn on the hazard warning flashers.

Engage the steering wheel lock in the
straight ahead position and set the
parking brake.

Move the gear selector lever toP.

Have any passenger exit the vehicle at
a safe distance from the roadway.
Mounting the Minispare wheelIn case of a flat tire, you may temporarily
use the spare wheel when observing the
following restrictions:


Do not exceed a vehicle speed of
50 mph (80 km/h).


Drive to the nearest tire repair facility
to have the flat tire repaired or re-
placed as appropriate.


Do not operate the vehicle with more
than one spare wheel mounted.
Prepare the vehicle as described on
(
page 380).

Take the wheel wrench and the jack
out of the trunk (
page 346).

Take the Minispare wheel and wheel
bolts out of the trunk (
page 346).
Warning!
G
The dimensions of the Minispare wheel are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a Minispare wheel
mounted.
The spare wheel should only be used tempo-
rarily, and should be replaced with a regular
road wheel as quickly as possible.
ProCarManuals.com

383 Practical hints
Flat tire
Mounting the new wheel
1Wheel bolt for light alloy rims
2Wheel bolt for Minispare wheel or other
steel rims (located in trunk with spare
wheel)
Clean contact surfaces of wheel and
wheel hub.

Guide the spare wheel onto the align-
ment bolt and push it on.

Insert wheel bolts and tighten them
slightly.
!Wheel bolts2 must be used when
mounting the Minispare wheel. The use
of any wheel bolts other than wheel
bolts 2 for the Minispare will physical-
ly damage the vehicle's brakes.
!To avoid paint damage, place wheel flat
against hub and hold it there while in-
stalling first wheel bolt.Warning!
G
Always replace wheel bolts that are dam-
aged or rusted.
Never apply oil or grease to wheel bolts.
Damaged wheel hub threads should be re-
paired immediately. Do not continue to drive
under these circumstances! Contact an au-
thorized Mercedes-Benz Center or call
Roadside Assistance.
Incorrect wheel bolts or improperly tight-
ened wheel bolts can cause the wheel to
come off. This could cause an accident.
Make sure to use the correct wheel bolts.
ProCarManuals.com

384 Practical hintsFlat tire
Unscrew the alignment bolt, install last
wheel bolt and tighten slightly.Lowering the vehicle

Lower vehicle by turning crank coun-
terclockwise until the full weight of the
vehicle is resting on the ground.

Remove the jack.
1 - 5 Wheel bolts

Tighten the five wheel bolts evenly, fol-
lowing the diagonal sequence illustrat-
ed (1 to 5), until all bolts are tight.
Observe a tightening torque of 80 lb-ft
(110 Nm).

Before storing the jack in the trunk, it
should be fully collapsed, with handle
folded in.
Warning!
G
Only use genuine equipment
Mercedes-Benz wheel bolts. Other wheel
bolts may come loose.
Do not tighten the wheel bolts when the ve-
hicle is raised. Otherwise the vehicle could
tip over.
Warning!
G
Have the tightening torque checked after
changing a wheel. The wheels could come
loose if they are not tightened to a torque of
80 lb-ft (110 Nm).
ProCarManuals.com

393 Practical hints
Towing the vehicle
Towing eye bolt CLK 55 AMG
Towing eye bolt in front bumper
The cover for the threaded bore in the front
bumper is identical to the cover on the
models CLK320/CLK500.
To remove and to reinstall cover,see “Tow-
ing eye bolt CLK 320/CLK 500”
(page 392)Towing eye bolt in rear bumper
1Cover on right side of rear bumper
2Recess in the cover
To remove cover:

Insert flat, blunt object as a lever in re-
cess 2 on the edge of cover 1.

Loosen cover 1 from the bumper us-
ing lever, to reveal threaded hole for
towing eye bolt.
The towing eye bolt is supplied with the
tool kit (located in the compartment
underneath the trunk floor).

Screw towing eye bolt to its stop and
tighten with lug wrench.To reinstall cover:

Hook right-hand side of the cover into
opening.

Slide cover as far as it will go in the di-
rection of the arrow3.

Gently press left-hand side of cover in
direction of the arrow4.
The hooks on the left-hand side en-
gage.iWhen closing the cover, make sure the
cover’s check strap does not get
caught.
