Contents
Maintenance ...................................... 282
Clearing the service indicator ...... 282
Service term exceeded ................ 282
Calling up the service indicator .... 283
Resetting the service indicator..... 283
Vehicle care ....................................... 284
Cleaning and care of vehicle ........ 284
Practical hints.................................. 291
What to do if …? ................................. 292
Lamps in instrument cluster ......... 292
Lamp in center console................. 298
Messages in the display ................ 299
Where will I find...? ............................. 329
First aid kit .................................... 329
Vehicle jack, vehicle tool kit,
luggage bowl, spare wheel ............ 329
Unlocking/locking in an emergency... 331
Unlocking the vehicle.................... 331
Locking the vehicle ....................... 332
Replacing batteries in
the SmartKey/ SmartKey with
KEYLESS-GO* ............................... 332
Fuel filler flap ................................ 334
Opening/closing in an emergency ..... 335
Sliding/pop-up roof ...................... 335
Replacing bulbs .................................. 336
Bulbs ............................................. 336
Replacing bulbs for front lamps .... 338
Replacing bulbs for rear lamps ..... 340Replacing wiper blades ...................... 341
Removing wiper blades ................. 341
Installing wiper blades .................. 342
Flat tire............................................... 343
Preparing the vehicle .................... 343
Mounting the spare wheel ............ 343
Battery ............................................... 348
Disconnecting the battery ............ 349
Removing the battery ................... 349
Charging and reinstalling the
battery .......................................... 349
Reconnecting the battery ............. 350
Jump starting...................................... 351
Towing the vehicle.............................. 353
Installing towing eye bolt .............. 355
Fuses.................................................. 356
Fuse boxes in passenger
compartment ................................ 356
Fuse boxes in engine
compartment ................................ 357
Emergency engine shut-down ....... 358

283 Operation
Maintenance
Calling up the service indicator
Switch on ignition.
The standard display of the control sys-
tem appears (
page 129).

Press button k or j on the mul-
tifunction steering wheel until FSS indi-
cator with the service symbol 9 or
´ and the service deadline appears
in the multifunction display.
Resetting the service indicator
In the event that the service on your vehi-
cle is not carried out by an authorized
Mercedes-Benz Center, you can reset the
service indicator yourself.
Switch on ignition.
The standard display of the control sys-
tem appears (
page 129).

Press button k or j on the mul-
tifunction steering wheel until the FSS
indicator with the service symbol 9
or ´ and the service deadline ap-
pears in the multifunction display.

Press reset button on the instrument
cluster for about three seconds.
This message appears in the multifunc-
tion display:SERVICE INTERVAL...
RESET WITH
R BUTTON FOR 3 SEC.


To confirm, press reset button until you
hear a signal.
The service indicator now displays the
reset interval.
iIf the battery is disconnected, the days
of disconnection will not be included in
the count shown by the service indica-
tor. To arrive at the true service dead-
line, you will need to subtract these
days from the days shown in the ser-
vice indicator.
Do not confuse the service indicator
with the engine oil level indicator :.
iIf the service indicator was inadvertent-
ly reset, have a Mercedes-Benz Center
correct it.
Only reset if the proper service has
been performed. Resetting the system
without performing proper service as
called for by the FSS will cause the FSS
to incorrectly determine the next ser-
vice interval which will result in engine
damage not covered by the
Mercedes-Benz Limited Warranty.

286OperationVehicle careEngine cleaning
Prior to cleaning the engine compartment
make sure to protect electrical compo-
nents and connectors from the intrusion of
water and cleaning agents.
Corrosion protection, such as MB Anticor-
rosion Wax, should be applied to the en-
gine compartment after every engine
cleaning. Before applying, all control link-
age bushings and joints should be lubricat-
ed. The poly-V-belt and all pulleys should
be protected from any wax.
Vehicle washing
Do not use hot water or wash your vehicle
in direct sunlight. Only use a mild car wash
detergent, such as Mercedes-Benz ap-
proved Car Shampoo.
Thoroughly spray the vehicle with a dif-
fused jet of water. Direct only a very weak
spray towards the ventilation intake. Use
plenty of water and rinse the sponge and
chamois frequently. Rinse with clear water and thoroughly dry
with a chamois. Do not allow cleaning
agents to dry on the finish.
Due to the width of the vehicle, fold in ex-
terior rear view mirrors prior to running the
vehicle through an automatic car wash to
prevent damage to the mirrors.
In the winter, thoroughly remove all traces
of road salt as soon as possible.
When washing the underbody, do not for-
get to clean the inner sides of the wheels.Ornamental moldings
For regular cleaning and care of very dirty
chrome-plated parts, use a chrome clean-
er.
Headlamps, tail lamps, side markers,
turn signal lenses

Use a mild car wash detergent, such as
Mercedes-Benz approved Car Sham-
poo, with plenty of water.
To prevent scratches, never apply strong
force and use only a soft, non-scratchy
cloth when cleaning the lenses. Do not at-
tempt to wipe dirty lenses with a dry cloth
or sponge.
iVehicles with KEYLESS-GO*:
If a door handle is hit by a strong jet of
water, and a SmartKey with
KEYLESS-GO* is in close proximity, i.e.
within approx. 3 ft. (approx. 1 m), the
vehicle could be inadvertently locked
or unlocked.

291 Practical hints
What to do if …?
Where will I find...?
Unlocking/locking in an emergency
Opening/closing in an emergency
Replacing bulbs
Replacing wiper blades
Flat tire
Battery
Jump starting
Towing the vehicle
Fuses

329 Practical hints
Where will I find...?
Where will I find...?
First aid kit
The first aid kit is stored in the rear center
armrest.
1Arm rest
2Lid
Fold rear arm rest down1.

Press handle upwards.

Fold lid2 up.

Remove first aid kit.Vehicle jack, vehicle tool kit, luggage
bowl, spare wheel
The spare wheel, the vehicle tool kit and
the luggage bowl are stored in the com-
partment underneath the trunk floor.
1Vehicle jack
2Vehicle tool kit
3Luggage bowl
4Spare wheel

Lift up trunk floor cover and engage
trunk floor handle in upper edge of
trunk.
You can now remove the tools and ac-
cessories.
The vehicle tool kit includes:


One interchangeable slot/Phillips
screwdriver


One towing eye bolt


One wheel bolt wrench with socket
wrench


One alignment bolt


One pair of gloves


One fuse extractor


One fuse chart for the main fuse box


Spare fuses
iCheck expiration dates and contents
for completeness at least once a year
and replace missing/expired items.
!To prevent damage, always disengage
trunk floor handle from trunk edge and
lower trunk floor before closing the
trunk lid.

356 Practical hintsFuses
FusesYour vehicle’s electrical fuses are located
in various fuse boxes:

In the dashboard on the passenger side


In the rear passenger compartment un-
der the right rear seat


In the engine compartment on the driv-
er’s side


In the engine compartment on the pas-
senger side
The following implements are located in
the vehicle tool kit in the trunk
(
page 329):


The fuse chart. The amperages of the
fuses are also given there.


Spare fuses


Special fuse extractor
Fuse boxes in passenger compartment
There are two fuse boxes in the passenger
compartment. One fuse box is located in
the dashboard on the front passenger side.
An additional fuse box is located under the
right rear seat.
Fuse box in dashboard
1Cover
iOnly install fuses that have been tested
and approved by Mercedes-Benz and
that have the specified amperage rat-
ing.
Never attempt to repair or bridge a
blown fuse. Have the cause determined
and remedied by an authorized
Mercedes-Benz Center.

357 Practical hintsFuses
Opening
Open the passenger door.

Using the flat of your hand, press on
the middle of the cover1.
The edge of cover1 lifts up slightly
from the dashboard.

Insert flat, blunt object into the edge of
the cover as a lever.

Loosen cover1 from the dashboard
using lever.

Using your hands, pull cover1 in the
direction of the arrow and remove.
Closing

Press cover1 back onto the dash-
board.Fuse box in the rear passenger
compartment
1Cover
Opening

Pull cover1 away from fuse box in di-
rection of arrow.

Remove cover rearward.
Closing

Press cover back on until it engages.
Fuse boxes in engine compartment
There are two fuse boxes located in the en-
gine compartment on both the driver’s and
front passenger side in front of the firewall
(dividing wall between engine compart-
ment and passenger compartment).
1Fuse box cover, driver’s side
2Slide
!Do not use sharp objects such as a
screw driver to open the fuse box in the
dashboard, as this could damage it.

358 Practical hintsFuses1Fuse box cover, front passenger side
2Slide
Opening
Push both slides2 to the Πsym-
bol.

Remove cover1.Closing

Replace cover1 and press it down by
hand.

Push both slides 2 to the ‹ sym-
bol.
Emergency engine shut-down
If the engine can no longer be stopped us-
ing the SmartKey or the KEYLESS-GO*
start/stop button, the engine can be
turned off by withdrawing two fuses.
For easy removal of fuses, use the fuse ex-
tractor (supplied with vehicle tool kit) to
pull out the fuses marked on the fuse chart
as “ENGINE EMERGENCY STOP”.
The fuse chart is also located in the vehicle
tool kit (
page 329).
!The cover must fit properly and the
slide must be positioned at the ‹
symbol, as moisture or dirt may impair
the functionality of the fuses.
