SWITCHES/LOCKS
Always check the Owner’s Manual for more operating information and safety features
Switches/
Locks
Locks
Quick Tips 2004 Mazda Mazda RX-8 page 10
page 11
5
43
L
R1
2
6
Dual power mirrors
Ignition switch must be in ACC
or ON position
Switch is on driver’s door
To adjust left/right mirror:
Press selector switch (1) left/right,
press switch (2) in direction of
desired movement
Tip: To lock mirrors in place,
move selector to center position
Power window switches
Ignition switch must be in ON
position
Front windows controlled from
the driver’s armrest; passenger
door has a separate switch
Driver’s window
One-touch-down: Push down
AUTO switch (3) firmly and
release, window goes down
all the way; pull switch back
briefly to stop; press lightly
and hold for normal operationPassenger window switch
Press button (4) down and hold to
open; pull back and hold to close
Power window lockout switch
Press button (5) down until clicks,
only driver’s window operates;
press again and passenger
windows function again
Power door locks
Master front door lock
switches
To lock/unlock all doors:
Press bottom/top of switch (6)
To lock doors without key: With
door open, press bottom of door
lock switch, exit car, close doors
To unlock: Use key to unlock driver’s
front door, rotate key to counter-
clockwise position for morethan
one second to unlock other doors
Manual door locks
Lock button
To lock: Press front of button
(1) toward door handle
To unlock: Pull front of button
away from door handle
Tip: Doors can be locked with
key in ignition (chime sounds
to alert you to key in ignition)Remote
keyless
entry
system
Functions
only with
ignition in
OFF position
To lock doors: Press
button (4); pressing again
within 5 seconds causes doors
to relock and horn to beep
To unlock: Press (5) for driver’s
door; press again within 5 seconds
to unlock other doors
To open trunk: Press (3)
Panic alarm: Press (2); horn
sounds and turn signals flash;
to stop, press (2) again or turn
ignition to ON position
If trunk fails to open: See Trunk
Tab, then Remote trunk-lid
release lock-outKey
Operates ignition and all locks
Tip: Use key number plate to
purchase new key; store in
safe place
Immobilizer system
Prevents engine from running
unless coded key used; see
Owner’s Manual
2
3
LOCK
UN
LOCK4
5
1
*Denotes optional equipment
CLIMATE CONTROLS
Always check the Owner’s Manual for more operating information and safety features
Climate
Controls
Trunk
Quick Tips 2004 Mazda Mazda RX-8 page 18
page 19
Trunk
To open: Use key, remote
trunk-lid release or remote
keyless entry fob
Remote trunk-lid release,
see Driver’s View
Remote trunk-lid
release lock-out
Switch in ON position,
remote trunk release
functions normal; OFF position
disables system; located in glove box
1. Instant Mobility System
emergency flat tire
repair kit (IMS)
†,
see Getting Started2. Jack/jack handle
3. Lug wrench
Tire economy and tips
Check pressure regularly when
tires are cold, maintain correct
front-end alignment and tire
balance; rotate tires at the mileage
shown in the Maintenance
Guide; see Owner’s Manual
for rotation chart
Tire pressure
P225/55R16 94V,
P225/45R18 91W
Front/rear: 32psi cold
Tips: Correct tire pressure ensures
safe handling and ride comfort
If you experience pull/drift while
driving, possible causes may
be road crown, tire pressure,
or wheel alignment
The suspension is sport-tuned
with firmer ride for optimum
handling and responseTire chains*
†Tire chains can damage
aluminum wheels; use on
steel wheels only
Tips: Use only SAE class “S”
chains, install only on rear
tires; install as tightly as
possible and retighten
after driving 1/4 -1/2 miles;
chains may affect handling
Never exceed 30 mph with
tire chains
132
1. Air flow selections
= air to dash
= air to dash and floor
= air to floor
= air to floor and
windshield
2. Fan control
Rotate knob between 0 (OFF)
and 4 (HIGH)
3. Temperature control
Cooler/warmer = rotate knob
counterclockwise/clockwise
4. A/C= air conditioner
Press to turn on/off
5. Air intake control
= recirculate inside air;
use for maximum cooling
= fresh air
WARNING: Do not use
position in cold
weather, windows may
fog and hamper vision
6. Rear window defogger
Press on/off; shuts off with
ignition; also operates heated
side mirrors*
Control positions for
maximum defrost
Fan to maximum, temperature to
maximum hot, selectedTips: To help prevent windshield
fogging in humid weather,
select before starting engine
To prevent moisture buildup,
never drive with system off
Objects placed under the
front seats may interfere
with air flow to the rear
7. Front windshield
defogger
A/C switches ON and air
intake switches to fresh air
A/C01
2
3
4MODE
4231
756
*Denotes optional equipment†See Owner’s Manual
Luggage
compartment
internal safety
release
Allows you to escape
should you become locked in trunk
Slide illuminated release lever in
direction of arrow; lever will glow
if it has been exposed to light
Located on interior trunk lid
OFF ONTRUNK OPENER
