STEERING WHEEL AND MIRRORS
216When the outside air temperature is low, it may take a little
longer for the mirror to darken in response to the detection of
headlights.
CAUTION
Do not adjust the mirror while the vehicle is moving.
Doing so may cause the driver to mishandle the vehicle
and an accident may occur resulting in death or serious
injuries.
To ensure correct functioning of the anti-glare mirror
sensors located on both sides of the mirror, do not touch
or cover the sensors with your finger or a piece of cloth,
etc.
Compass
The compass indicates the direction in which the vehicle
is heading. The illustration shown above indicates the
vehicle is heading north.
Push the COMPº switch to turn the compass system on
and off.
If the ignition switch was turned off with the system on, the
system will automatically turn back on when the ignition switch
is turned on.

STEERING WHEEL AND MIRRORS
218If the direction is not indicated or the system does not operate
properly, contact your Lexus dealer.

Compass sensor
NOTICE
Do not put magnets or a metal object on or near the
inside rear view mirror of the vehicle. Doing this may
cause malfunction of the compass sensor in the mirror.

AUDIO
356The power outlet is not designed for the following electric
appliances even though their power consumption is
under 115 VAC/100W. These appliances may not operate
properly.
Appliances with high initial peak wattage: Cathode-ray
tube type televisions, compressor-driven refrigerators,
electric pumps, electric tools, etc.
Measuring devices which process precise data: Medical
equipment, measuring instruments, etc.
Other appliances requiring an extremely stable power
supply: Microcomputer-controlled electric blankets, touch
sensor lamps, etc.
Certain electrical appliances may cause radio noise.
Headphone input jacks
To use the jack, push the lid.
You can enjoy the rear seat entertainment system with
commercial headphones.
To use the headphones, connect them to the jack.
The key must be in the ACCº or ONº position.

STARTING AND DRIVING
415
CAUTION
Do not overestimate the anti-lock brake system:
Although the anti-lock brake system assists in
providing vehicle control, it is still important to drive
with all due care and maintain a moderate speed and
safe distance from the vehicle in front of you, because
there are limits to the vehicle stability and effectiveness
of steering wheel operation even with the anti-lock
brake system on.
If tire grip performance exceeds its capability, or if
hydroplaning occurs during high speed driving in the
rain, the anti-lock brake system does not provide
vehicle control.
Anti-lock brake system is not designed to shorten the
stopping distance: Always drive at a moderate speed
and maintain a safe distance from the vehicle in front of
you. Compared with vehicles without an anti-lock
brake system, your vehicle may require a longer
stopping distance in the following cases:
Driving on rough, gravel or snow-covered roads.
Driving with tire chains installed.
Driving over the steps such as the joints on the road.
Driving on roads where the road surface is pitted or
has other differences in surface height.
Install all 4 tires of specified size at appropriate
pressure: The anti-lock brake system detects vehicle
speeds using the speed sensors for respective wheels'
turning speeds. The use of tires other than specified
may fail to detect the accurate turning speed resulting
in a longer stopping distance.

STARTING AND DRIVING
419
NOTICE
Do not use liquid sealants for a flat tire as air pressure
sensors will be damaged.
When the tires must be repaired or replaced, have
them repaired or replaced by the nearest Lexus
dealer or authorized tire dealer. The tire pressure
sensors will be affected by the installation or removal
of tires.
The tire pressure warning system is not to be used as
a substitute for regular inspections. Be sure to check
the air pressure in the tires on a regular basis.
When the tires must be replaced, replace the
grommets for air pressure sensors as well.
If the warning light blinks:
The tire pressure warning system may be malfunctioning.
Contact your Lexus dealer.System malfunction
The tire pressure warning system does not function
properly under certain circumstances. In the following
cases, the low tire pressure warning light may not come
on even if the tire inflation pressure is low, or it may come
on when the tire inflation pressure is actually normal.
Electric devices or facilities using similar radio wave
frequencies are nearby.
A radio set to similar frequencies is in use.
A lot of snow or ice covers the vehicle, in particular, around
the wheels or wheel housings.
The tires are not equipped with an air pressure sensor.
Tire chains are used.

STARTING AND DRIVING
420Non-genuine Lexus wheels are used.
Although the tires are equipped with air pressure sensors,
the selector switch (see page 425) is set to other tire setting.
CAUTION
The use of non-genuine wheels will cause the air
pressure sensors to transmit the electronic code in
different manner, resulting in the system failure.
The use of different type of tires with genuine wheels
may also cause the malfunction of the system.
CAUTION
When the tire pressure monitoring system warning light
is lit, one or more of your tires is significantly
under-inflated. You should stop and check your tires as
soon as possible, and inflate them to the proper
pressure as indicated on the vehicle's tire information
placard. Driving on a significantly under-inflated tire
causes the tire to overheat and can lead to tire failure.
Under-inflation also reduces fuel efficiency and tire
tread life, and may affect the vehicle's handling and
stopping ability. Each tire, including the spare, should
be checked monthly when cold and set to the
recommended inflation pressure as specified in the
vehicle placard and owner's manual.

STARTING AND DRIVING
424
Replacing tires and wheels
When replacing the wheels, be sure to install air pressure
sensors on the wheels.
There are 3 ways to set up the air pressure sensors:
(a) Remove the sensor from the old wheel and install it to the
new wheel.
(b) Keep the same wheel with air pressure sensor and replace
only the tire.
(c) Use a new wheel and sensor.
You have to register an ID code for a new sensor. Up to 2 sets
of codes can be registered. As one ID for the originally installed
sensor is registered at MAINº of the selector switch, use the
2ndº position to register an ID for the new sensor.
You do not need to re-register the ID code for any other
replacements. For the use of the originally installed tires, put
the selector switch at MAINº and for the use of tires set
purchased later, put the switch at 2ndº. For the sensor
selector switch, see page 425.CAUTION
Have the tires, wheels or sensors replaced and ID
codes registered by a Lexus dealer. If you need
sensors, purchase from a Lexus dealer.
The use of non-genuine wheels will cause the air
pressure sensors to transmit the electronic code in
different manner, resulting in the failure of the
system.

STARTING AND DRIVING
425
Selector switch

1Main position22nd position
The selector switch is located in the lower part of the
driver's side instrument panel.
The ID code is given in the sensor. To activate the air
pressure warning system, it is necessary to register the ID
code of the sensor on the selector switch in the vehicle.
2 sets of ID codes can be registered. The code of the tires
originally installed on the vehicle is registered on the switch at
MAINº. Have a new tires set with new air pressure sensors
registered at 2ndº by Lexus dealer.
ID codes should be registered by Lexus dealer. Once
registered, change the setting position each time you purchase
tires and wheels. Re-registration is not required.
When purchasing new tires, consult your Lexus dealer.
CAUTION
When the tires whose ID code is registered at MAINº
are used, the system does not work properly with the
selector switch set at 2ndº. If the tires whose ID code
is registered at 2ndº are stored nearby, the system will
detect their tire pressure (and vice versa).
