INTRODUCTION
530
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do-it-yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):

Toyota Genuine Motor Oilº or equivalent
See page 546 for details about engine oil selection.
Tools:

Rag or paper towel

Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):

Toyota Super Long Life Coolantº or similar high quality
ethylene glycol based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life hybrid organic acid
technology (Coolant with long-life hybrid organic acid
technology is a combination of low phosphates and organic
acids.)
Toyota Super Long Life Coolantº is a mixture of 50% coolant
and 50% deionized water. This coolant provides protection
down to about -35C (-31F).
Tools:

Funnel (only for adding coolant)
Checking brake fluid
Parts (if level is low):

FMVSS No. 116 DOT 3 or SAE J1703 brake fluid
Tools:

Rag or paper towel

Funnel (only for adding fluid)
Checking power steering fluid
Parts (if level is low):

Automatic transmission fluid DEXRON
II or III
Tools:

Rag or paper towel

Funnel (only for adding fluid)
Checking battery condition
Tools:

Warm water

Baking soda

Grease

Conventional wrench (for terminal clamp bolts)

SECTION 6 ± 2
532
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications533
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 537
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 540
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . .
Facts about engine oil consumption 540
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . .
Used engine oil 541
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine oil level 542
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 547
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Checking the radiator and condenser 549
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Spark plugs 550
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ENGINE
536Ð IGNITION SYSTEM
Spark plug Ð Make DENSO
NGK
Ð Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
Ð ELECTRICAL SYSTEM
Battery Open voltage at 20 C (68F):
Charging rates
12.6 Ð 12.8 V Fully charged
12.2 Ð 12.4 V Half charged
11.8 Ð 12.0 V Discharged
[Voltage that is checked 20 minutes after the key is removed
with all the lights turned off]
5 A max.

ENGINE
541
The amount of engine oil consumed depends on the
viscosity of the oil, the quality of the oil and the way the
vehicle is driven.
More oil is consumed by high-speed driving and frequent
acceleration and deceleration.
A new engine consumes more oil, since its pistons, piston rings
and cylinder walls have not become conditioned.
Oil consumption:
Max. 1.0 L per 1000 km (1.1 qt./600 miles,
0.9 lmp. qt./600 miles)
When judging the amount of oil consumption, keep in
mind that the oil may have become diluted, making it
difficult to judge the true level accurately.
For example, if a vehicle is used for repeated short trips and
consumes a normal amount of oil, the dipstick may not show
any drop in the oil level at all, even after 1000 km (600 miles)
or more. This is because the oil is gradually becoming diluted
with fuel or moisture, making it appear that the oil level has not
changed.
The diluting ingredients evaporate out when the vehicle is then
driven at high speeds, as on an expressway, making it appear
that oil is excessively consumed after driving at high speeds.
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum level so
that oil function will not be impaired. Therefore, it is essential
that the oil level be checked regularly. Lexus recommends that
the oil level be checked every time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to serious engine trouble due to insufficient oil.
For detailed information on oil level check, see Checking the
engine oil levelº described below.USED ENGINE OIL

ENGINE
542
CAUTION
Used engine oil contains potentially harmful
contaminants which may cause skin disorders such
as inflammation or skin cancer, so care should be
taken to avoid prolonged and repeated contact with
it. To remove used engine oil from your skin, wash
thoroughly with soap and water.
 Dispose of used oil and used oil filters only in a safe
and acceptable manner. Do not dispose of used oil
and used oil filters in household trash, in sewers or
onto the ground. Call your Lexus dealer or a service
station for information concerning recycling or
disposal.
 Do not leave used oil within the reach of children.
CHECKING THE ENGINE OIL LEVEL
With the engine at operating temperature and turned off,
check the oil level on the dipstick.
1. To get a correct reading, the vehicle should be on a level
ground. After turning off the engine, wait a few minutes for the
oil to drain back into the bottom of the engine.
2. Pull the dipstick out, hold a rag under the end and wipe it
clean.
3. Reinsert the dipstick and push it in as far as it will go, or the
reading will not be correct.

ENGINE
544
If the oil level is below or only slightly above the low line,
add engine oil of the same type as already in the engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. We recommend that you use a funnel
when adding oil. The approximate quantity of oil needed to
raise the level between low line and full line on the dipstick is
indicated below for reference.
When the level reaches within the correct range, return the filler
cap and turn the cap clockwise until you hear a click.
Oil quantity. L (qt., lmp. qt.) 1.5 (1.6, 1.3)

ENGINE
545
NOTICE
Be careful not to spill engine oil on the vehiclecomponents.
Avoid overfilling, or the engine could be damaged.
Check the oil level on the dipstick once again afteradding the oil.

ENGINE
547
To ensure excellent lubrication performance for your engine,
Toyota Genuine Motor Oilº is available, which has been
specifically tested and approved for all Lexus engines.
Please contact your Lexus dealer for further details about
Toyota Genuine Motor Oilº.
CHECKING THE ENGINE COOLANT
LEVEL

1Reservoir cap2Fº (upper) line
3Lº (lower) line
Look at the see-through coolant reservoir when the
engine is cold. The coolant level is satisfactory if it is
between the Fº and Lº lines on the reservoir. If the level
is low, add the coolant. (For the coolant type, see Coolant
type selectionº described below.)
The coolant level in the reservoir will vary with engine
temperature. However, if the level is on or below the Lº line,
add coolant. Bring the level up to the Fº line.
