2004 Lexus GX470 engine

CHASSIS
580
NOTICE
When jacking up or installing tire chains, be sure to turn
off the rear height control air suspension with the HEIGHT CONTROL OFFº switch and stop the engine.Otherwise, the vehicle height may change because ofthe automatic leveling function resulting in accident.

ELECTRICAL COMPONENTS
584
SPECIFICATIONS
Ð FUSE LOCATIONS
64PY003

1Engine compartment
2Driver's side instrument panel
Ð FUSES

Engine compartment

ELECTRICAL COMPONENTS
595
NOTICE
Make sure the engine and all accessories are turnedoff before performing maintenance.
When checking the battery, remove the ground cable
first and reinstall it last.
Be careful not to cause a short circuit with tools.
Take care no solution gets into the battery when washing it.
If the battery is disconnected or run down
The power windows and moon roof may not operate
automatically and the jam protection function will not function
correctly after you reconnect, replace or recharge the battery.
In any of these cases, you should normalize the power
windows and moon roof. To normalize the power windows and
moon roof, see pages 50 and 107.
Checking battery condition
Check the battery condition by the indicator color.
1BLUE Ð Good condition.
2WHITE Ð Charging necessary. Have the battery
checked by your Lexus dealer.
3RED Ð Have the battery checked by your Lexus dealer.

ELECTRICAL COMPONENTS
597
BATTERY RECHARGINGPRECAUTIONS
During recharging, the battery is producing hydrogen
gas.
Therefore, before recharging:
1. If recharging with the battery installed on the vehicle, be
sure to disconnect the ground cable.
2. Make sure the power switch on the recharger is off when
connecting the charger cables to the battery and when
disconnecting them.
CAUTION
Always charge the battery in an unconfined area. Do
not charge the battery in a garage or closed room
where there is not sufficient ventilation.
 Only do a slow charge (5 A or less). Charging at a
quicker rate is dangerous. The battery may explode
causing personal injuries.
NOTICE
Never recharge the battery while the engine is running.
Also, make sure all accessories are turned off.

ELECTRICAL COMPONENTS
598
CHECKING AND REPLACING THEBLADE TYPE FUSES
The engine compartment fuse box is located under the left
side engine compartment cover. Before checking the
engine compartment fuses, remove the cover. (For
details, see Removing the engine compartment coversº
on page 526.)

Engine compartment 1 Pull-out tool 2 Spare fuses

Driver's side instrument panel
1. Turn the ignition switch off and open the fuse box lid.
Determine which fuse may be causing the problem. The lid of
the fuse box shows the name of the circuit for each fuse.

ELECTRICAL COMPONENTS
600It is a good idea to purchase a set of spare fuses and keep them
in your vehicle for emergencies.
If the new fuse immediately blows out, there is a problem with
the electrical system. Have your Lexus dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher amperage rating, or any
other object, in place of a fuse. This may cause
extensive damage and possibly a fire.
CHECKING THE CARTRIDGE TYPE
FUSES
The engine compartment fuse box is located under the left
side engine compartment cover. Before checking the
engine compartment fuses, remove the cover. (For
details, see Removing the engine compartment coversº
on page 526.)

Engine compartment

ELECTRICAL COMPONENTS
602
CAUTION
Always use a genuine Lexus fuse or equivalent for
replacement. Never install an ordinary wire Ð even for
a temporary fix. This may cause extensive damage and
possibly a fire.
ADDING WASHER FLUID
If the washer tank becomes nearly empty, add washer
fluid.
You may use plain water as washer fluid. However, in cold
areas where temperatures range below the freezing point, use
washer fluid containing antifreeze. This product is available at
your Lexus dealer and most auto parts stores. Follow the
manufacturer's directions for how much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it may damage your vehicle's paint.

BODY
612Fuel
filler door: Do not apply water (high-pressure car wash,
for example) at or near the fuel tank inlet with the fuel filler door
opened. If the water enters the air vent, you may experience
trouble with refueling or rough engine idling.
Plastic wheel ornaments: The plastic wheel ornaments are
damaged easily by organic substances. If any organic
substance splashes an ornament, be sure to wash it off with
water and check if the ornament is damaged.
CAUTION
Do not attach the heavily damaged plastic wheel
ornament. It may fly off the wheel and cause accidents
while the vehicle is moving.
Aluminum wheels: Use only a mild soap or neutral detergent.
Urethane bumpers and side moldings: Wash carefully. Do
not scrub with abrasive cleaners. The bumper and side
molding faces are soft.
Road tar: Remove with turpentine or cleaners that are marked
safe for painted surfaces.
NOTICE
Do not use organic substances (gasoline, kerosene,
benzine or strong solvents), which may be toxic orcause damage.
