STARTING AND DRIVING
387
To allow proper operation of your vehicle's
ventilation system, keep the inlet grilles in front of the
windshield clear of snow, leaves, or other
obstructions.
 If you smell exhaust fumes in the vehicle, drive with
the windows open and the back door closed. Have
the cause immediately located and corrected.

DRIVING TIPS
457
Do not use your parking brake when there is a possibility
it could freeze.
When
parking, put the transmission into Pº and block the front
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.
Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of the thi ngs you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.
DINGHY TOWING
Your vehicle is not designed to be dinghy towed (with four
wheels on the ground) behind a motorhome.
NOTICE
Do not tow your vehicle with four wheels on the ground. This may cause serious damage to your vehicle.

IN CASE OF AN EMERGENCY
530
NOTICE
You must provide the Lexus Link operator with yourLexus Link PIN (Personal Identification Number) orpersonal security word, before they lock/unlock yourvehicle. However, the Lexus Link System will not beable to lock or unlock your vehicle if it has been parkedfor 48 hours or more after the ignition is turned off.Upon subscription expiration, all Lexus Link services
(i.e. automatic notification, emergency call functions,service call functions) are deactivated.
If you must break a window to get in, we suggest breaking the
smallest side window because it is the least expensive to
replace. Be extremely cautious to avoid glass cuts.

MAINTENANCE
537
DOES YOUR VEHICLE NEEDREPAIRING?
Be on the alert for changes in performance and sounds, and
visual tip-offs that indicate service is needed. Some important
clues are:

Engine missing, stumbling, or pinging

Appreciable loss of power

Strange engine noises

A fluid leak under the vehicle (However, water dripping from
the air conditioning after use is normal.)

Change in exhaust sound (This may indicate a dangerous
carbon monoxide leak. Drive with the windows open and
have the exhaust system checked immediately.)

Flat-looking tires, excessive tire squeal when cornering,
uneven tire wear

Vehicle pulls to one side when driving straight on a level
road

Strange noises related to suspension movement

Loss of brake effectiveness, spongy feeling brake pedal,
pedal almost touches floors, vehicle pulls to one side when
braking

Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Lexus
dealer as soon as possible. It probably needs adjustment or
repair.
CAUTION
Do not continue driving with the vehicle unchecked. It
could result in serious vehicle damage and possibly
personal injury.

CHASSIS
588
Glossary of tire terminology
Tire related termMeaning
Accessory weightthe combined weight (in excess of those standard items which may be rep\
laced)
of automatic transmission, power steering, power brakes, power windows, \
power
seats, radio, and heater, to the extent that these items are available as
factory-installed equipment (whether installed or not)
Cold tire inflation
pressuretire inflation pressure when the vehicle has been parked for at least 3 \
hours or
more, or it has not been driven more than 1.5 km or 1 mile under that co\
ndition
Curb weightthe weight of a motor vehicle with standard equipment including the maxi\
mum
capacity of fuel, oil, and coolant, and, if so equipped, air conditionin\
g and
additional weight optional engine
Intended outboard
sidewall(a) the sidewall that contains a whitewall, bears white lettering or bearsmanufacturer, brand, and/or model name molding that is higher or deeper
than the same molding on the other sidewall of the tire, or
(b) the outward facing sidewall of an asymmetrical tire that has a particula\
r side that must always face outward when mounted on a vehicle
Maximum inflation
pressurethe maximum cold inflation pressure to which a tire may be inflated and \
it is
shown on the sidewall of the tire
Maximum loaded
vehicle weightthe sum of Ð
(a) curb weight;
(b) accessory weight;
(c) vehicle capacity weight; and
(d) production options weight
Normal occupant
weight68 kg (150 lb.) times the number of occupants specified in the second \
column of
Table 1 that follows

ELECTRICAL COMPONENTS
606
13MIR
HEATER10Outside rear view mirror
defogger
14STOP10
Stop lights, high m ounted
stoplight, shift lock control
system, vehicle stability control
system, electronic m odulated
suspension, rear height control
air suspension, multiport fuel
injection system/sequential
multiport fuel injection system
15AC115V
INV15Power outlet (115 VAC)
16FR FOG15Front fog lights
17OBD7.5On- board diagnosis system
18HEAD
(LO RH)10Right-hand headlight (low beam)
19HEAD
(LO LH)10Left-hand headlight (low beam)
No.FUSEAMPERECIRCUIT
20HEAD
(HI RH)10Right-hand headlight (high
beam)
21HEAD
(HI LH)10Left-hand headlight (high beam)
22EFI NO.210Multiport fuel injection
system/sequential multiport fuel
injection system
23HEATER NO.27.5Air conditioning system
24DEFOG30Rear window defogger

ELECTRICAL COMPONENTS
607
25AIRSUSNO.210Rear height control air
suspension
26SEAT
HEATER20Seat heaters
27DOME10
Ignition switch light, interior
lights, personal lights, foot
lights, running board lights,
door courtesy lights, inside
door handle lights,
multi- information display
28RADIO NO.120Audio system, navigation
system
No.FUSEAMPERECIRCUIT
29ECU-B10
Multiplex communication
system, vehicle stability control
system, wireless remote
control system, inside rear
view mirror, air conditioning
system, electronic modulated
suspension, driving position
memory system, power
windows, moon roof, rear view
monitor system
30ECU-B NO.210Theft deterrent system
31ABS
MTR40
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
32AM230Starting system, all components
in IGNº, SRSº, GAUGEº and
ST2º fuses

ELECTRICAL COMPONENTS
608
33ABSSOL50
Anti- lock brake system,
vehicle stability control system,
active traction control system,
brake assist system
No.FUSEAMPERECIRCUIT
34ALT-S7.5Charging system
35MAYDAY7.5Lexus Link System
36HORN10Horns
37TRN-HAZ15Turn signal lights
38ETCS10Electronic throttle control system
39EFI20Multiport fuel injection
system/sequential multiport fuel
injection system
40D FR P/W20Power window
41DR/LCK25Power door lock
42TOWING30Towing converter
43RADIO NO.230Audio system, navigation
system
44IGN10
Multiport fuel injection
system/sequential multiport fuel
injection system, vehicle
stability control system
45SRS10SRS airbag system
46GAUGE7.5Gauges and meters
47ST27.5Multiport fuel injection
system/sequential multiport fuel
injection system
No.FUSEAMPERECIRCUIT
