GAUGES, METERS AND SERVICE REMINDER INDICATORS
70
MULTI-INFORMA TION DISPLAY
13PY018

1MODEº button2º button
3º button4RESETº button
The multi-information display provides various
information, including clock, outside temperature, and
your vehicle's driving condition.
When the ignition switch is on, the last previously used mode
displayed just before the ignition switch is off will appear.
If the electrical power source has been disconnected from the
multi-information display, the display will automatically be set
to the initial mode.
When the instrument panel lights are turned on, the brightness
of the display will be reduced.
You can adjust the brightness of the display. To adjust the
brightness, see ADJUSTING THE BRIGHTNESS OF THE
DISPLAYº below.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
71 ADJUSTING THE BRIGHTNESS OF THE DISPLAY
The key must be in the ACCº or ONº position. To adjust the
brightness of the display, push and hold the MODEº button for
more than 2 seconds. ILLº will appear on the display.
To increase the brightness Ð Push the
º button.
To decrease the brightness Ð Push the
º button.
You can adjust the brightness to 3 levels (when the tail lights
are off) or 6 levels (when the tail lights are on).
After adjusting, the display automatically return to the previous
display.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
Clock
The digital clock indicates the time when the key is in the
ACCº or ONº position.
To reset the time, push and hold the MODEº button for 2
seconds. ILLº will appear on the display. Then push the
MODEº button once. The time will blink.
To reset the hour Ð Push the
º button.
To reset the minutes Ð Push the
º button.
To adjust the time to the nearest hour, push the RESETº
button. For example, if the RESETº button is depressed when
the time is between 1:01 Ð 1:29, the time will change to 1:00.
If the time is between 1:30 Ð 1:59, the time will change to 2:00.
If the electric power source has been disconnected, the time
display will automatically be set to 1:00.

EXTERIOR EQUIPMENT
105
2. To remove the fuel tank cap, turn the cap
counterclockwise by 90 degrees (to the pressure point
1), and then turn it an additional 30 degrees (to point2). Pause slightly before removing it.
It is not unusual to hear a slight swoosh when the cap is
opened.
15PY017
3. The removed cap can be stored on the back side of the
fuel filler door.
Position the cap so that the hooks point to the left and right or
up and down, and set it in the receptacle on the back side of
the door.
