2004 Hyundai Coupe windshield wipers

FEATURES OF YOUR HYUNDAI 1- 35
HGK046
B350A01O-AAT Tailgate Wiper And Washer Switch
1. :The washer fluid will be sprayed onto the
rear window and the wiper operates while the rear window wiper barrel is placed inthis position.
2.OFF3.INT :To use the intermittent wiper feature,
place the rear window wiper barrel in the"INT" position.
4.ON :When the point indicates "ON", the rear
window wiper operates continuously.
To use the windshield washer, pull the wiper/ washer lever toward the steering wheel. Whenthe washer lever is operated, the wipers auto-matically make two passes across the wind-shield. The washer continues to operate until thelever is released. NOTE:
o Do not operate the washer more than 15 seconds at a time or when the fluid reser-voir is empty.
o In icy or freezing weather, be sure the wiper blades are not frozen to the glassprior to operating the wipers.
o In areas where water freezes in winter, use windshield washer antifreeze.
B350B01O-AAT Windshield Washer Operation
HGK044
B350C01S-AAT Adjustable Intermittent Wiper Opera- tion
To use the intermittent wiper feature, place the wiper switch in the "INT" position. With the switchin this position, the interval between wipes can bevaried from 2 to 10 seconds by turning theinterval adjuster barrel.
HGK043
Mist Wiper Operation
HGK045
If a single wipe is desired in mist, push the windshield wiper and washer control lever up-wards.

DO-IT-YOURSELF MAINTENANCE 6-11
G090A01A-GAT
FILLING THE WASHER RESERVOIR The washer fluid reservoir supplies fluid to the windshield washer system. A good quality washer fluid should be used to fill the washer reservoir. The fluid level should bechecked more frequently during inclementweather or whenever the washer system is inmore frequent use. The capacity of the washer reservoir is 3.0 liters (3.2 U.S. quarts). CAUTION:
o Radiator antifreeze (engine coolant) should not be used in the washer system because it will damage the car's finish.
o The washer should not be operated if the washer reservoir is empty. This can dam-age the washer fluid pump.
HGK217
G080A02A-AAT WINDSHIELD WIPER BLADES The wiper blades should be carefully inspected from time to time and cleaned to remove accu-mulations of road film or other debris. To cleanthe wiper blades and arms, use a clean spongeor cloth with a mild soap or detergent and water.If the wipers continue to streak or smear theglass, replace them with Genuine HyundaiReplacement Parts or their equivalent. CAUTION:
o Do not operate the wipers on dry glass.
This can result in more rapid wear of the wiper blades and may scratch the glass.
o Keep the blade rubber out of contact with petroleum products such as engineoil, gasoline etc.HEF119
Transaxle lubricant in the manual transaxle should
be checked at those intervals specified in the vehicle maintenance schedule in Section 5. Recommended Oil
Use only HYUNDAI GENUINE PARTS MTF
75W/90 (API GL-4) in the manual transaxle.Manual Transaxle Oil Capacity
5 speed : 2.15L (2.27 U.S. quarts) 6 speed : 2.2L (2.32 U.S. quarts) WARNING: It is always better to check the transaxle oil
level when the engine is cool or cold. If the engine is hot, you should exercise great caution to avoid burning yourself on hot engine or exhaust parts. G100A02GK-GAT
CHECKING THE TRANSAXLE OIL (MANUAL)
G110A01E
Filler plug
Drain plug

1
CONTROLS AND EQUIPMENT
53
NOTE:
o Do not operate the washers for
more than 15 seconds continu- ously or when the fluid reservoiris empty.
o In icy or snowy weather, ensure
that the wiper blades are not fro-zen to the glass prior to operat- ing the wipers.
o In areas where water freezes in winter, use windshield washerantifreeze.
Mist Wiper Operation B350C01S-AAT ADJUSTABLE INTERMITTENT WIPER OPERATION(Not all models) To use the intermittent wiper feature, place the wiper switch in the "INT" position. With the switch in this posi- tion, the interval between wipes can bevaried from 2 to 10 seconds by turning the interval adjuster barrel.
HGK2081-E
HGK2084-E
HGK2083-E
If a single wipe is desired in mist, move the windscreen wiper and washer con-trol lever up.B390A01E-EAT Rear Window Wiper and Washer (Not all models)
1. : The rear window wiper starts to operate three times after the washer fluid sprays onto the rear window.
2.OFF 3.INT: The interval between wipes op- erates every 5 seconds inter-mittently.
4.ON : The rear window wiper starts
to operate continuously.
5. : The washer fluid will be sprayed onto the rear window and thewiper operates whilst the rearwindow wiper barrel is placed in this position.
