DRIVING YOUR HYUNDAI
2- 12 C160G01A-GAT To Keep Locks from FreezingTo keep the locks from freezing, squirt an ap- proved de-icer fluid or glycerine into the keyopening. If a lock is covered with ice, squirt it withan approved de-icing fluid to remove the ice. Ifthe lock is frozen internally, you may be able tothaw it out by using a heated key. Handle theheated key with care to avoid injury. NOTE: The proper temperature for using the immo-bilizer key is from -40°C to 80°C. If you heatthe immobilizer key over 80°C to open thefrozen lock, it may cause damage to thetransponder in its head. C160H01A-AAT Use Approved Anti-Freeze in Window Washer System To keep the water in the window washer system from freezing, add an approved anti-freeze solu-tion in accordance with instructions on the con-tainer. Window washer anti-freeze is availablefrom Hyundai dealers and most auto parts out-lets. Do not use engine coolant or other types ofanti-freeze as these may damage the finish.
C160B01A-GAT Snowy or Icy ConditionsTo drive your vehicle in deep snow, it may be necessary to use snow tires or to install tirechains on your tires. If snow tires are needed, itis necessary to select tires equivalent in size andtype to the original equipment tires. Failure to doso may adversely affect the safety and handlingof your car. Speeding, rapid acceleration, sud-den brake applications, and sharp turns arepotentially very hazardous practices. Duringdeceleration, use engine braking to the fullestextent. Sudden brake applications on snowy oricy roads may cause skids to occur. You need tokeep sufficient distance between the vehicle infront and your vehicle. Also, apply the brakegently. It should be noted that installing tire chainson the tire will provide a greater driving force, butwill not prevent side skids. NOTE: Tire chains are not legal in all provinces.Check province laws before fitting tire chains. C160C01A-AAT Use High Quality Ethylene Glycol Coolant Your Hyundai is delivered with high quality ethyl- ene glycol coolant in the cooling system. It is theonly type of coolant that should be used becauseit helps prevent corrosion in the cooling system,lubricates the water pump and prevents freezing.Be sure to replace or replenish your coolant in
C160D01F-AAT Check Battery and Cables Winter puts additional burdens on the battery system. Visually inspect the battery and cablesas described in Section 6 (See page 6-18). Thelevel of charge in your battery can be checkedby your Hyundai dealer or a service station. C160E01A-AAT Change to "Winter Weight" Oil if Necessary In some climates it is recommended that a lower viscosity "winter weight" oil be used during coldweather. See Section 9 for recommendations. Ifyou aren't sure what weight oil you should use,consult your Hyundai dealer. C160F01F-GAT Check Spark Plugs and Ignition Sys- tem Inspect your spark plugs as described in Section 6 (See page 6-8) and replace them if necessary.Also check all ignition wiring and components tobe sure they are not cracked, worn or damagedin any way.
accordance with the maintenance schedule inSection 5. Before winter, have your coolant test-ed to assure that its freezing point is sufficient forthe temperatures anticipated during the winter.

WHAT TO DO IN AN EMERGENCY 3-3
5. If the water pump drive belt is broken or
engine coolant is leaking out, stop the engine immediately and call the nearest Hyundaidealer for assistance.
WARNING:Do not remove the radiator cap when theengine is hot. This can allow coolant to beblown out of the opening and cause seriousburns.
6. If you cannot find the cause of the overheat- ing, wait until the engine temperature has returned to normal. Then, if the engine cool-ant has been lost, carefully add coolant to thereservoir (page 6-8) to bring the fluid level inthe reservoir up to the halfway mark.
7. Proceed with caution, keeping alert for fur- ther signs of overheating. If overheating hap-pens again, call a Hyundai dealer for assis-tance.
CAUTION:Serious loss of engine coolant indicates thereis a leak in the cooling system and this shouldbe checked as soon as possible by a Hyundaidealer. 2. The spare tire should only be used temporari-
ly and should be returned to the luggagecompartment as soon as the original tire canbe repaired or replaced.
3. Continuous use at speeds of over 80 km/h (50 mph) is not recommended.
4. As the temporary spare tire is specifically designed for your car, it should not be used onany other vehicle.
5. The temporary spare tire should not be used on any other wheels, nor should standardtires, snow tires, wheel covers or trim ringsbe used with the temporary spare wheel. Ifsuch use is attempted, damage to theseitems or other car components may occur.
6. The temporary spare tire pressure should be checked once a month while the tire is stored.
D040A01GK-GAT TEMPORARY SPARE TIREThe following instructions for the temporary spare tire should be observed:
1. Check inflation pressure as soon as practical
after installing the spare tire, and adjust to the specified pressure. The tire pressure shouldbe periodically checked and maintained atthe specified pressure while the tire is stored.
Spare Tire Pressure CAUTION:
o Do not use snow chains with your tempo-
rary spare tire.
o Do not use more than one temporary spare tire at a time.
D040B01A-AAT Handling the Spare Tire
HGK190
Remove the installation bolt to remove the spare tire. To replace the spare tire in its storagecompartment, tighten the bolt firmly with yourfingers until there is no more play in the spare tire.
Tire Size Inflation Pressure T125/70R 16420 kPa (60 psi)

CONSUMER INFORMATION 8-1
8. CONSUMERINFORMATION
I010A01A-GAT
VEHICLE IDENTIFICATION
NUMBER (VIN) The vehicle identification number (VIN) is the
number used in registering your car and in all legal matters pertaining to its ownership, etc. It can be found on the identification plate at-
tached to the engine side of the firewall be-tween the engine and passenger compartment. I010B01A-AAT
Engine Number
I010B01GK
The engine number is stamped on the engine
block as shown in the drawing.
I020A01A-AAT TIRE INFORMATIONThe tires supplied on your new Hyundai are
chosen to provide the best performance for normal driving. I030A02GK-AAT
RECOMMENDED INFLATION PRES- SURES
The tire label located on the driver's side of the
center pillar outer panel gives the tire pressures recommended for your vehicle.
HGK220
HGK092
8
DOHC V6
These pressures were chosen to provide the
most satisfactory combination of ride comfort, tire wear and stability under normal conditions.Tire pressures should be checked at leastmonthly. Proper tire inflation pressures shouldbe maintained for these reasons: 6.0Jx156.5Jx16 7.0Jx17
4Tx16 TIRE
SIZE
RIM
SIZE PRESSURE, kPa (PSI)
195/65R15 205/55R16 215/45R17
T125/70R16 REAR
210(30)210(30)210(30)420(60) FRONT
210(30) 230(33) 240(35)420(60)
UP TO 2
PERSONS UP TO
MAX. LOAD
REAR
210(30) 230(33) 230(33)420(60)
FRONT210(30)210(30) 220(32) 420(60)

CONSUMER INFORMATION
8-2
o Lower-than-recommended tire pressures
cause uneven tread wear and poor han- dling.
o Higher-than-recommended tire pressures increase the chance of damage from im-pacts and cause uneven tread wear.
CAUTION: Always observe the following:
o Check pressures when the tires are cold. That is, after the car has been parked for at least three hours and hasn't been driv-en more than 1.6 km or one mile sincestarting up.
o Check the pressure of your spare tire each time you check the pressure ofother tires. I050A02GK-GAT
TIRE CHAINS
Tire chains, if necessary, should be installed onthe front wheels. Be sure that the chains areinstalled in accordance with the manufacturer'sinstructions. Refer to the following information. I060A02GK-GAT
TIRE ROTATION
I040A01S-GAT
SNOW TIRES If you equip your car with snow tires, they should be the same size and have the sameload capacity as the original tires. Snow tiresshould be installed on all four wheels; other-wise, poor handling may result. Snow tires should carry 28 kPa (4 psi) more air pressure than the pressure recommended forthe standard tires on the tire label on the driveside center pillar outer panel, or up to themaximum pressure shown on the tire sidewall whichever is less. Do not drive faster than 120 km/h (75 mph)when your car is equipped with snow tires. Tires should be rotated every 10,000 km (6,000miles). If you notice that tires are wearing un-evenly between rotations, have the car checkedby a Hyundai dealer so the cause may becorrected.After rotating, adjust the tire pressures and besure to check wheel nut torque. WARNING: Do not mix bias-ply and radial-ply tires un- der any circumstances. This may cause dan-gerous handling characteristics.
I060A01GK
To minimize tire and chain wear, do not contin-ue to use tire chains when they are no longerneeded. WARNING:
o When driving on roads covered with snow or ice, drive at less than 30 km/h (20 mph).
o Use tire chains less than 10mm (0.39 in.) for 16" and 17" tires.
o Avoid sudden stop and turns.
o Tighten firmly to avoid contact with the verticle body, if you have noise caused by chaws contacting the body, removethe chains for damage protection. 15", 16" Tire
Tire size
195/65 R 15 205/55 R 16 215/45 R 17
Snow Chain Thickness Max. 15 mm Max. 10 mmMax. 10 mm
17" Tire

CONSUMER INFORMATION 8-3
1.6 mm (0.06 in.)HGK248
I090A01S-GAT
WHEN TO REPLACE TIRES
Wear indicator
I070A01A-AAT
TIRE BALANCING A tire that is out of balance may affect handling
and tire wear. The tires on your Hyundai were balanced before the car was delivered but mayneed balancing again during the years you ownthe car.
Whenever a tire is dismounted for repair, it
should be rebalanced before being reinstalled
on the car. I080A01A-AAT
TIRE TRACTION
Tire traction can be reduced if you drive on
worn tires, tires that are improperly inflated oron slippery road surfaces. Tires should be re-placed when tread wear indicators appear. Toreduce the possibility of losing control, slowdown whenever there is rain, snow or ice on theroad.
The original tires on your car have tread wearindicators. The tread wear indicators appearwhen the tread depth is 1.6 mm (0.06 in.). Thetire should be replaced when these appear as asolid bar across two or more grooves of thetread. Always replace your tires with those ofthe recommended size. If you change wheels,the new wheel's rim width and offset must meetHyundai specification. I100A01FC-GAT
SPARE TIRE AND TOOLS
Your Hyundai is delivered with the following: Spare tire and wheel Wheel nut wrench, Wrench bar, Spanner, DriverJack
HGK189
I060A02GK
WARNING: When rotating the 215/45 R17 tires, the tires
must be mounted following the "ROTATION" direction marked on the sidewall of the tires.
If rotating the tires from the left side to the
right side and from the right side to the leftside, separate the wheel from the tire andthen remount them. WARNING:
o Driving on worn-out tires is dangerous! Worn-out tires can cause loss of brakingeffectiveness, steering control and trac-
tion. When replacing tires, never mix ra-dial and bias-ply tires on the same car. Ifyou replace radial tires with bias-ply tires,they must be installed in sets of four.
o Using tires and wheels of other than the recommended sizes may cause unusualhandling characteristics that may causedeath, serious injury or property dam-age.
Sidewall
Tire rotation direction

8
CONSUMER INFORMATION
3
I030A01GK-EAT TYRE PRESSURES In modern high-speed motoring, cor- rect tyre pressures are vitally impor- tant. Incorrect tyre pressures can af- fect vehicle safety by causing re-duced adhesion, steering response and tyre failure through overheating. The tyre pressure must only be checked when the tyres are cold. Thecorrect tyre pressures are indicated on the label affixed to the drivers door pillar and below.
Tyre pressures should be increased
by 3 psi when the vehicle is drivenfully laden or under conditions of sus-tained high speed motoring.
6.0Jx15 6.5Jx167.0Jx17 4Tx16 TIRE SIZE
RIM
SIZE PRESSURE, kPa (PSI)
REAR
210(30) 210(30) 210(30)420(60) FRONT
210(30)230(33)240(35) 420(60)
UP TO 2 PERSONS UP TO M
AX.LOAD
REAR
210(30) 230(33)230(33) 420(60)
FRONT
210(30) 210(30)220(32)420(60)
195/65R15 205/55R16215/45R17
T125/70R16
HGK6003-E
TYRE
ZI010C1-E TYRE INFORMATION The tyres supplied on your new Hyundai are chosen to provide the best performance for normal driving.

8CONSUMER INFORMATION
4
!
I050A01GK-EAT TYRE CHAINS Tyre chains should be installed on the front wheels. Be sure that the chains are installed in accordance with the manufacturer's instructions. Refer tothe following information.
To minimize tyre and chain wear, do
not continue to use tyre chains whenthey are no longer needed. WARNING:
o When driving on roads covered with snow or ice, drive at lessthan 30 km/h (20 mph).
o Use a tyre chains less than 10mm to 16", 17" tyre.
o Avoid sudden stop and turn.
o Tighten firmly not to hear con- tact sound, if it still sounds,remove the chains for damage protection.
Tire size
205/55 R 16 215/45 R 17 Snow Chain
Thickness
Max. 10 mmMax. 10 mmSI030A2-E SNOW TYRES If it is desired to fit snow tyres to the vehicle, it must be ascertained that the original size and load carrying capacity are met by the replacementtyres. When using snow tyres, the vehicle should not be driven at speeds in excess of 60 MPH.
