FEATURES OF YOUR HYUNDAI
1- 20
o Front airbags are not intended to deploy in side-impact, rear-impact or rollover crashes. In addition, airbags will not de-ploy in frontal crashes below the deploy-ment threshold speed.
o The driver should sit back as far as pos- sible while still maintaining control of thevehicle. If you are sitting too close to theairbag, it can cause death or serious injurywhen it inflates.
o No objects should be placed over or near the airbag modules on the steering wheel,instrument panel, and the frontpassenger's panel above the glove box,because any such object could causeharm if the vehicle is in a crash severeenough to cause the airbags to deploy.
o If the airbags deploy, they must be re- placed by an authorized Hyundai dealer.
B240A02GK
Rear impact
Side Impact Rollover
B240A01GK
Driver's Airbag
B240A01GK-GAT SUPPLEMENTAL RESTRAINT
(AIRBAG) SYSTEM (SRS) (If Installed) Your Hyundai is equipped with a Supplemental Restraint (Airbag) System. The indications of thesystem's presence are the letters "SRS AIRBAG" embossed on the ornament in the steeringwheel and the passenger's side front panel padabove the glove box. The Hyundai SRS consists of airbags installed under the pad covers in the center of the steeringwheel and the passenger's side front panel abovethe glove box. The purpose of the SRS is toprovide the vehicle's driver and/or the front pas-senger with additional protection than that of-fered by the seat belt system alone, in case of afrontal impact of sufficient severity.
NOTE: Be sure to read information about the SRS onthe labels provided on the backside of thesun visor and in the glove box. WARNING:
o As its name implies, the SRS is designed
to work with, and be supplemental to, thedriver's and the passenger's three pointseat belt systems and is not a substitutefor them. Therefore, your seat belts mustbe worn at all times while the vehicle is inmotion. The airbags deploy only in certainfrontal impact conditions severe enoughto cause significant injury to the vehicleoccupants.
o The SRS is designed to deploy the airbags only when an impact is sufficiently severeand when the impact angle is less than 30°from the forward longitudinal axis of thevehicle and will not deploy in side, rear orrollover impacts. Additionally, the airbagswill only deploy once. Thus, seat beltsmust be worn at all times.
o Front airbags are not intended to deploy in light collisions in which protection canbe provided by the seat belt alone.

FEATURES OF YOUR HYUNDAI 1- 21
B240B01GK-GAT SRS Components and Functions The SRS consists of the following components: - Driver's Airbag Module - Passenger's Airbag Module- SRS Service Reminder Indicator (SRI)- SRS Control Module (SRSCM) The SRSCM continually monitors all elements while the ignition is "ON" to determine if a frontalor near-frontal impact is severe enough to re-quire airbag deployment. The SRS service reminder indicator (SRI) on the instrument panel will blink for about 6 secondsafter the ignition key is turned to the "ON" positionor after the engine is started, after which the SRIshould go out.
o Do not tamper with or disconnect SRS
wiring, or other components of the SRSsystem. Doing so could result in injury,due to accidental firing of the airbags orby rendering the SRS inoperative.
o Do not install a child restraint system in the front passenger seat position. A childrestraint system must never be placed inthe front seat. The infant or child could beseverely injured or killed by an airbagdeployment in case of an accident.
o Do not allow children to ride in the front passenger seat. If older children (teenag-ers and older) must ride in the front seat,make sure they are always properly beltedand that the seat is moved back as far aspossible.
o For maximum safety protection in all types of crashes, all occupants including thedriver should always wear their seat beltswhether or not an airbag is also providedat their seating position to minimize therisk of severe injury or death in the eventof a crash. Do not sit or lean unnecessarilyclose to the airbag while the vehicle is inmotion.
o The SRS airbag system must deploy very rapidly to provide protection in a crash. Ifan occupant is out of position because ofnot wearing a seat belt, the airbag mayforcefully contact the occupant causingserious or fatal injuries.
B240B01L
The airbag modules are located both in the center of the steering wheel and in the frontpassenger's panel above the glove box. Whenthe SRSCM detects a considerable impact to thefront of the vehicle, it will automatically deploy theairbags. CAUTION: Do not install or place any accessories (drinkholder, cassette holder, sticker, etc) on thefront passenger's panel above the glove boxin a vehicle with a passenger's air bag. Suchobjects may become dangerous projectilesand cause injury if the passenger's air baginflates.
B240B02L
Upon deployment, tear seams molded directly into the pad covers will separate under pressurefrom the expansion of the airbags. Further open-ing of the covers then allows full inflation of theairbags.

FEATURES OF YOUR HYUNDAI 1- 23
WARNING:
o The side impact airbag is supplemental to
the driver's and the passenger's seat beltsystems and is not a substitute for them.Therefore your seat belts must be worn atall times while the vehicle is in motion. Theairbags deploy only in certain side impactconditions severe enough to cause sig-nificant injury to the vehicle occupants.
o For best protection from the side impact airbag system and to avoid being injuredby the deploying side impact airbag, bothfront seat occupants should sit in an up-right position with the seat belt properlyfastened. The driver's hands should beplaced on the steering wheel at the 9:00and 3:00 o'clock positions. Thepassenger's arms and hands should beplaced on their laps.
o Do not use any accessory seat covers.
o Use of seat covers could prevent or re- duce the effectiveness of the system.
o Do not install any accessories on the side or near the side impact airbag.
o Do not use excessive force on the side of the seat.
o Do not place any objects over the airbag or between the airbag and yourself.
o Do not place any objects (an umbrella, bag, etc.) between the front door and thefront seat. Such objects may become dan-gerous projectiles and cause injury if thesupplemental side impact airbag inflates.
Your Hyundai is equipped with a side impactairbag in each front seat. The purpose of theairbag is to provide the vehicle's driver and/or thefront passenger with additional protection thanthat offered by the seat belt alone. The sideimpact airbags are designed to deploy only dur-ing certain side-impact collisions, depending onthe crash severity, angle, speed and point ofimpact. The side impact airbags are not de-signed to deploy in all side impact situations.
B990B04Y-AAT Side Impact Airbag
B990B02Y
o To prevent unexpected deployment of the
side impact airbag that may result in per- sonal injury,avoid impact to the side airbagsensor when the ignition key is on.
B240C02Y-GAT SRS Care The SRS is virtually maintenance-free and there are no parts you can safely service by yourself.The entire SRS system must be inspected by anauthorized Hyundai dealer 10 years after thedate that the vehicle was manufactured. Any work on the SRS system, such as removing, installing, repairing, or any work on the steeringwheel must be performed by a qualified Hyundaitechnician. Improper handling of the SRS sys-tem may result in serious personal injury.
YT10355A

FEATURES OF YOUR HYUNDAI
1- 24 o Do not tamper with or disconnect SRS
wiring, or other components of the SRS system. Doing so could result in injury,due to accidental firing of the airbags orby rendering the SRS inoperative.
o If components of the airbag system must be discarded, or if the vehicle must be
scrapped, certain safety preca utions must
be observed. Your Hyundai dealer knowsthese precautions and can give you the
necessary information. Failure to followthese precautions and procedures could
increase the risk of personal injury.
o If you sell your vehicle, be sure to inform the new owner of these important pointsand make certain that this manual is trans-ferred to the new owner.
o If your car was flooded and has soaked carpeting or water on flooring, youshouldn't try to start engine; have the car
towed to authorized Hyundai dealer.
WARNING:
o Do not install a child restraint system in
the front passenger seat position.
A child restraint system must never be placed in the front seat. The infant or childcould be severely injured by an airbagdeployment in case of an accident.
o Extreme Hazard! Do not use a reward facing restraint on a seat protected by anairbag in front of it!
o Modification to SRS components or wir- ing, including the addition of any kind ofbadges to the pad covers or modifications
to the body structure, can adversely affectSRS performance and lead to possibleinjury.
o For cleaning the airbag pad covers, use only a soft, dry cloth or one which hasbeen moistened with plain water. Solventsor cleaners could adversely affect theairbag covers and proper deployment ofthe system.
o No objects should be placed over or near the airbag modules on the steering wheel,instrument panel, and the frontpassenger's panel above the glove box,because any such object could cause harmif the vehicle is in a crash severe enoughto cause the airbags to inflate.
o If the airbags inflate, they must be re- placed by an authorized Hyundai dealer.

FEATURES OF YOUR HYUNDAI 1- 25
B250A01GK-GAT INSTRUMENTS AND CONTROLS
1. Head Light Leveling Device (If installed)
2. Traction Control System (If installed)
3. Panel Brightness Control Knob(Rheostat Switch) (If installed)
4. Multi-Function Light
5. Windshield Wiper/Washer Switch
6. Front Fog Light Switch (If installed)
7. Rear Fog Light Switch (If installed)
8. Hazard Warning Switch
9. Digital Clock
10. Front Seat Warmer (If installed)
11. Passenger's Air Bag (If installed)
12. Passenger's side Drink Holder
13. Hood Release Lever
14. Fuse Box Relay
15. Steering Wheel Tilt Lever
16. Horn and Driver's Airbag
17. Cruise Control Switch (If installed)
18. Heating and Cooling Controls
19. Ashtray
20. Cigarette Lighter
21. Shift Lever
22. Audio System (If installed)
23. Multi Guage (If installed)
24. Parking Brake Lever
25. Glove Box
26. Center Console
CAUTION:When installing a container of liquid air freshener inside the vehicle, do not place it near theinstrument cluster nor on the instrument panel surface. If there is any leakage from the airfreshener onto these areas (Instrument cluster, instrument panel or air ventilator), it may damagethese parts. If the liquid from the air freshener does leak onto these areas, wash them with waterimmediately. HGK001A
12
3
4 5
67 8 9
10
11 12
13 14 15 16 1718 1920 21 2223 24 25 26

FEATURES OF YOUR HYUNDAI 1- 35
HGK046
B350A01O-AAT Tailgate Wiper And Washer Switch
1. :The washer fluid will be sprayed onto the
rear window and the wiper operates while the rear window wiper barrel is placed inthis position.
2.OFF3.INT :To use the intermittent wiper feature,
place the rear window wiper barrel in the"INT" position.
4.ON :When the point indicates "ON", the rear
window wiper operates continuously.
To use the windshield washer, pull the wiper/ washer lever toward the steering wheel. Whenthe washer lever is operated, the wipers auto-matically make two passes across the wind-shield. The washer continues to operate until thelever is released. NOTE:
o Do not operate the washer more than 15 seconds at a time or when the fluid reser-voir is empty.
o In icy or freezing weather, be sure the wiper blades are not frozen to the glassprior to operating the wipers.
o In areas where water freezes in winter, use windshield washer antifreeze.
B350B01O-AAT Windshield Washer Operation
HGK044
B350C01S-AAT Adjustable Intermittent Wiper Opera- tion
To use the intermittent wiper feature, place the wiper switch in the "INT" position. With the switchin this position, the interval between wipes can bevaried from 2 to 10 seconds by turning theinterval adjuster barrel.
HGK043
Mist Wiper Operation
HGK045
If a single wipe is desired in mist, push the windshield wiper and washer control lever up-wards.

FEATURES OF YOUR HYUNDAI 1- 47
B610A01S-GAT HORN
HGK141
Press the pad on the steering wheel to sound the horn.
Working Zone
B540D02HP-DAT LUGGAGE NET (If Installed) Some objects can be kept in the net of the luggage compartment.Use the luggage net on the floor or at the back ofthe luggage compartment to prevent objectsfrom sliding. CAUTION: To prevent damage to the goods or the ve-hicle, care should be taken when carryingfragile or bulky objects in the luggage com-partment. WARNING: Avoid eye injury. DO NOT overstretch. AL-WAYS keep face and body out of recoil path.DO NOT use when strap has visible signs ofwear or damage.B600A01HP-AAT STEERING WHEEL TILT LEVER (If installed) To adjust the steering wheel:
1. Pull the lever toward you and hold it to unlock.
2. Raise or lower the steering wheel to the desired position.
3. After adjustment, release the lever. WARNING: Do not attempt to adjust the steering wheelwhile driving as this may result in loss ofcontrol of the vehicle and serious injury ordeath.
HGK127
HGK241
A Type
B Type

FEATURES OF YOUR HYUNDAI
1- 48 B660C03E-AAT To Cancel the Cruise Speed To disengage the cruise control system, Pull the control switch toward the steering wheel to "CAN-CEL" position.Additionally, the following actions will disengagethe system :
o Depress the brake pedal.
o Depress the clutch pedal (Manual transaxle).
o Shift the selector lever to "N" position (Auto-
matic transaxle).
o Decrease the vehicle speed lower than the memorized speed by 20 km/h (12 mph).
o Decrease the vehicle speed to less than 40 km/h (25 mph).
o Release the main switch.
WARNING: To avoid accidental cruise control engage-ment, keep the cruise control main switch offwhen not using the cruise control.
B660C01GK
B660B01E-GAT To Set the Cruise Speed
B660B01GK
1. Push in the cruise control main switch on the end of the barrel. The "CRUISE" indicator light in the instrument cluster will be illumi-nated. This turns the system on.
2. Accelerate to the desired cruising speed above 40 km/h (25 mph).
3. Push the control switch downward to "SET (COAST)" and release it.
4. Remove your foot from the accelerator pedal and the desired speed will automatically bemaintained.
5. To increase speed, depress the accelerator pedal enough for the vehicle to exceed thepreset speed. When you remove your footfrom the accelerator pedal, the vehicle willreturn to the speed you have set.
B660A01S-GAT CRUISE CONTROL (If Installed)
Main switch
The cruise control system provides automatic speed control for your comfort when driving onfreeways, tollroads, or other noncongested high-ways. This is designed to function above ap-proximately 40 km/h (25 mph). B660A01GK
