6OWNER MAINTENANCE
32
G290B01GK-EAT
Adjustment After Headlight As- sembly Replacement
If the vehicle has had front body
repair and the headlight assembly has been replaced, the headlight aim- ing should be checked using an aim-ing screen as shown in the illustra- tion. Turn on the headlight switch.
1. Adjust headlights so that main axis of light is parallel to centre line of the body and is aligned with point"P" shown in the illustration.
2. Dotted lines in the illustration show centre of headlights. SPECIFICATION:
"H" Horizontal centre line of headlights from ground: Low Beam: 26.7 in. (679mm) High Beam: 26.5 in. (672mm) "W" Distance between each headlight cen- tre : Low Beam: 47.3 in. (1,202mm) High Beam: 38.0 in. (966mm) "L" Distance between the headlights and the wall that the lights are tested against : 118.11 in. (3,000 mm)
1. Keep all tyres inflated to the cor-
rect pressure.
2. Place the vehicle on level ground and press the front bumper & rearbumper down several times. Placevehicle at a distance of 118.1 in. (3m) from the test wall.
3. See that the vehicle is unloaded (except for full levels of coolant, engine oil and fuel, and spare tyres,jack, and tools).
4. Clean the head lights lens and turn on the headlight.
5. Open the bonnet.
6. Draw the vertical line (through the centre of each headlight beam pat- tern) and the horizontal line (through the centre of each headlight beampattern) on the aiming screen.And then, draw a parallel line at1.18 in. (30 mm) under the hori- zontal line.
7. Adjust each cut-off line of the low beam to the parallel line with aphillips screwdriver - VERTICAL AIMING.
8. Adjust each cut-off line of the low beam to the each vertical line witha phillips screwdriver - HORIZON- TAL AIMING. L
G290B01JM-D
W
H
H Cut-off line"P"
Vertical lineHorizontal line
Ground line
1.18 in.

6
OWNER MAINTENANCE
33REPLACING LIGHT BULBS
G260A03A-EAT In the event of bulb failure being experienced, ensure that the relative lighting circuit is turned off prior toattempting to replace the bulb. The illustrations on the following page will assist in locating and removing thevarious bulbs. Ensure that the re- placement bulb has the same cap configuration and wattage as the origi-nal.See page 6-40 for the wattage de-scriptions.
CAUTION:
Keep the lamps out of contact withpetroleum product, such as oil, gasoline, etc.
!
HGK5025
G270A01GK-EAT Headlight and Front Turn Signal Light
1. Allow the bulb to cool. Wear eye protection.
2. Open the engine bonnet.
3. Always grasp the bulb by its plastic base, avoid touching the glass.
HGK5024
5. Turn the plastic cover counterclock- wise and remove it.
4. Disconnect the power cord from the bulb base in the back of the headlight. HGK5023
6. Disconnect the connector from thebulb base in the back of the head- light.

6OWNER MAINTENANCE
34
!WARNING:
This halogen bulb contains gas
under pressure and if impacted could shatter, resulting in flying fragments. Always wear eye pro-tection when servicing the bulb. Protect the bulb against abrasions or scratches and against liquidswhen lighted. Turn the bulb on only when installing in a head- light. Replace the headlight if dam-aged or cracked. Keep the bulb out of the reach of children and dispose of the used bulb with care.
11.To replace the front turn signal
light bulb, remove from the bulbholder and install the new bulb. HGK5036
tic base with the headlight hole.Reattach the bulb spring and re-connect the connector.
9. Use the protective cap and carton
to promptly dispose of the old bulb.
10.Check for proper headlight aim.
G270A03O
8. Remove the protective cap fromthe replacement bulb and install the new bulb by matching the plas-
7. Push the bulb spring to remove the
headlight bulb.
HGK5027
HGK5026

6
OWNER MAINTENANCE
35
G270B01GK-GAT
Rear Combination Light (Without woofer speaker)
1. Open the hatchback door. HGK5037
(1)
(2)
(3)
3. Remove the nut (8mm) with a span-
ner. HGK50424. To detach the rear combination
light hit it strongly by hand. HGK5043
HGK5041
2. To remove the cover of the rear luggage trim, turn the knob by hand to the counterclockwise.

6OWNER MAINTENANCE
36
1. Open the hatchback door. HGK5039
HGK5040
3. Extract the mounting screws
(10mm) around the woofer speaker with a spaner.
4. Disconnect the power cord from the woofer speaker.
HGK5038
G275B01GK-EAT
Rear Combination Light (With woofer speaker)
HGK5037
(1)
(2)
(3)
2. Take off the luggage board.
5. To replace the rear combination light (stop/tail light, turn signal light, back-up light) take it out from the bulb holder by turning it counter-clockwise. (1) Stop/Tail light (2) Back-up light (3) Turn signal light
6. Install the new bulb. HGK5044-1
(1)
(2) (3)

6
OWNER MAINTENANCE
37
HGK5041
5. To remove the cover of the rear luggage trim, turn the knob by hand to the counterclockwise.
HGK5042
6. Remove the nut (8mm) with a wrench.G270C01GK-EAT Luggage Compartment Light
1. Open the hatchback door.
HGK5045HGK5044-1 (1)
(2) (3) back-up light, side mark light), take it out from the bulb holder by turn-ing it counterclockwise. (1) Stop/Tail light (2) Back-up light (3) Turn signal light
9. Install the new bulb.
HGK5043
7. To detach the rear combination light hit it strongly by hand.
8. To replace the rear combination light (stop/tail light, turn signal light,

6OWNER MAINTENANCE
38
G270G01GK-AAT
Map Light
1. Remove the cover with a flat-blade
screwdriver.
2. Replace with a new bulb.
HGK5047
HGK5048 HGK2112-E
2. Open the glove box and remove the mounting screws on the upside of the glove box.
G270H01GK-GAT
Glove Box Illuminated Light
1. Remove the mounting screws on the downside of the glove box. HGK2111-E
HTB284
2. Remove the cover with a flat-blade
screwdriver.
3. Disconnect the power cord. HGK5046
4. Replace with a new bulb.

6
OWNER MAINTENANCE
39
3. Remove the glove box by pulling
strongly.
CAUTION:
Be careful not to damage the glove
box when pulling the glove box.
!
HGK5052-E
HTB284
HGK5053-E
Clip
Power Cord
4. Disconnect the power cord.
5. Remove the glove box illuminated light by pushing the clip.
6. Replace with a new bulb.
