2004 HONDA INSIGHT spare tire

Tire Size Cold Tire Pressurefor Normal Driving
Front:
Rear:
Thecompactsparetirepressureis:
For convenience, the recommended
tire sizes and cold air pressures are
on a label on the driver’s doorjamb.
For additional technical information,
see page .
Use a gauge to measure the air
pressure at least once a month. Even
tires that are in good condition may
lose one to two psi (10 to 20 kPa, 0.1
to 0.2 kgf /cm ) per month.
Remember to check the spare tire at
thesametime.
Check the pressure in the tires when
they are cold. This means the vehicle
has been parked f or at least three
hours, or driven less than 1 mile (1.6
km).
Add or release air, if needed, to
match the recommended cold tire
pressuresonthispage. If you check the pressure when the
tires are hot [driven f or several miles
(kilometers)], you will see readings
4
to6psi(30to40kPa,0.3to0.4
kgf /cm ) higher than the cold
reading. This is normal; do not
release air to match the cold
pressure.
Tubeless tires have some ability to
self -seal if they are punctured. You
should look closely f or punctures if a
tire starts losing pressure.
Youshouldgetyourowntire
pressure gauge and use it whenever
you check your tire pressures. This
will make it easier f or you to tell if a
pressure loss is due to a tire problem
and not due to a variation between
gauges. 196
Tires
Maint enance155
P165/65R14 78S
38 psi (260 kPa)
35 psi (240 kPa)
60 psi (420 kPa)

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .164
....................
Changing a Flat Tire .165
.............
If the Engine Won’t Start . 171
................................
Jump Starting .173
..............
If the Engine Overheats . 175
.........
Low Oil Pressure Indicator . 177
..........
Charging System Indicator . 178
.......
Malf unction Indicator Lamp . 178
...............
Brake System Indicator . 180
......................
Emergency Towing .181
......
If Your Vehicle Gets Stuck . 182
..............................................
Fuses .183
..............................
Fuse Locations .186
Taking Care of the Unexpected
T aking Care of t he Unexpect ed163

Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced
and put it back on your vehicle as
soon as you can.
Check the compact spare tire
inf lation pressure every time you
check the other tires. It should be
inf lated to:Follow these precautions:
Never exceed 50 mph (80 km/h)
under any circumstances.
This tire gives a harsher ride and
less traction on some road sur-
f aces. Use greater caution while
driving.
Do not mount snow chains on it.
Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel. Replace the tire when you can see
the tread wear indicator bars. The
replacement should be the same size
and design tire, mounted on the
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire.
Compact Spare Tire
T aking Care of t he Unexpect ed164
INDICATOR LOCATION MARK
TREAD WEAR INDICATOR BAR
60 psi (420 kPa)

If you have a f lat tire while driving,
stop in a saf e place to change it.
Drive slowly along the shoulder until
you get to an exit or an area that is
far away from the traffic lanes.Park the vehicle on f irm, level and
non-slippery ground. Put the
transmission in Reverse (5-speed
manual) or Park (CVT). Apply the
parking brake.
Open the hatch. Raise the cargo
area f loor by lif ting up on the back
edge.
Remove the storage box from the
cargo area well.
Take the tool kit f rom the spare
tire well. Remove the jack (in the
jack cover) f rom the inside of the
spare tire.
Unscrew the wing bolt, and take
the spare tire out of its well.
Turn on the hazard warning
indicators, and turn the ignition
switch to LOCK (0). Have your
passenger get out of the vehicle
while you change the tire.
2.
3. 1.
4.
5.
6.
CONT INUED
Changing a Flat T ire
T aking Care of t he Unexpect ed165
FLOOR BOARDTOOL KIT
STORAGE BOX
SPARE TIRE
JACK
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.

Bef ore mounting the spare tire,
wipeanydirtoff themounting
surface of the wheel and hub with
a clean cloth. Wipe the hub
carefully;itmaybehotfrom
driving.Put on the spare tire. Put the
wheel nuts back on f inger-tight,
then tighten them in a crisscross
pattern with the wheel wrench
until the wheel is f irmly against
the hub. Do not try to tighten
them f ully.Lower the vehicle to the ground
and remove the jack.
8.
9.10.
Changing a Flat T ire
T aking Care of t he Unexpect ed168
HUB

Place the flat tire face down in the
spare tire well.
Remove the spacer cone f rom the
wing bolt, turn it over, and put it
back on the bolt.
Securetheflattirebyscrewing
the wing bolt back into its hole.Store the jack and tool kit back in
the spare tire well.
Install the storage box in the cargo
area well.
Lower the cargo area f loor, then
close the hatch. Store the center cap in the spare
tire well. Make sure it does not get
scratched or damaged.
15.
16. 17.
14. 19.
20. 18.
Changing a Flat T ire
T aking Care of t he Unexpect ed170
WING BOLT SPACER CONE
Loose items can fly around the
interior in a crash and could
seriously injure the occupants.
Store the wheel, jack, and tools
securely before driving.

µµµ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Î
Î
T echnical Inf ormation
Specif ications
193
Air Conditioning
Lights
12 Volt Battery Alignment
Tires
Fuses
HFC-134a (R-134a)
17.6 19.4 oz (500 550 g) SP-10
12 V 60/55 W (HB2) 0.00 in (0.0 mm)
0.12 in (3.0 mm)
0°1°
2°
P165/65R14 78S
T115/70D14 88M
12 V 21 W
12 V 5 W
12 V 12 V
21/5 W
21 W
12 V 18 W
12 V
12 V 5W
5W
12 V
12 V
5W
3.4 W
12V 27Ah/5HR 30 Ah/5 HR
12 V
Refrigerant type
Charge quantity
Lubricant type
Headlights (HI/LO)
Front turn signal lights
Front parking lights
Side marker lights
Rear turn signal lights
Brake/Taillights
Back-up lights
Trunk light
License plate light
Interior light
Capacity
Toe-in
Camber
Caster
Size
Pressure
Interior
Under-hood
See page
187or the fuse label
attached to the inside of the fuse
box door under the dashboard.
See page 188or the fuse box
cover.
Front
Rear
Front
Rear
Front
Front/Rear
Spare
Front
Rear
Spare
38 psi (260 kPa)
35 psi (240 kPa)
60 psi (420 kPa)
U.S. model M/T
CVT

Î
.................................
