Overview - Instruments and controls
1. Instrument cluster!p. 106
2. Ignition switch!p. 1473. Supplemental restraint system-air bag
(For driver 's seat)!p. 89
Horn switch!p. 132
4. Hazard warning flasher switch!p. 123
5. Windshield wiper and washer switch!p. 126
6. Vents!p. 233
7. Supplemental restraint system-air bag
(For front passenger 's seat)!p. 89
8. Audio
9. Rear window defroster switch!p. 125
10. Air conditioning!p. 234
11. Fog light switch (if so equipped)!p. 123
12. Hood release lever!p. 41
13. Instrument panel light dimmer control!p. 124
14. Combination headlight, dimmer and turn-signal
lever!p. 119
15. Cruise control lever!p. 113
16. Accessory socket!p. 209
17. Parking brake lever!p. 167
18. Gearshift or selector lever!p. 151, 156
6 INTRODUCTION

NTuning.............................226
NBalance............................226
NFade..............................226
NTone Control........................226
NMODE Selection......................226
NPTY (Program Type) Selection.............226
NScan Button.........................226
NTo Set The Pushbutton Memory...........227
NTo Change From Clock To Radio Mode......227
NGeneral Information...................227
NOperating Instructions Ð CD Changer......227
NInserting the Compact Disc..............227
NSeek Button.........................228
NFF /Tune/ RW Button..................228
NRandom Play........................228
NRadio/CD Button.....................228NTime Button.........................228
NScan Button.........................228
NLoading The CD Changer...............228
NPlaying Discs........................229
NRemoving Discs From The CD Changer.....229
mSteering wheel remote control switches (if so
equipped)
...........................229
NHow to adjust the volume...............230
NTo listen to the audio system..............230
NTo listen to the radio...................230
NAutomatic tuning the radio...............230
NTo select the preset memory..............230
NTo listen to a tape.....................231
NTo listen to a CD......................231
NHandling of compact discs...............232
mRadio operation and cellular phones........234
FOR PLEASANT DRIVING 207
6

5. Seek down / Rewind APS button / Track down button
6. Volume down button
NOTE:
²Do not push two or more of the steering wheel
remote control switches at the same time.
How to adjust the volume
Volume up button - 2
The volume will increase when this button is pressed.
Volume down button - 6
The volume will decrease when this button is pressed.
To listen to the audio system
Select the desired mode by lightly pressing the Mode
change button (4). Every time the button is pressed, the
mode can be changed.
Radio (AM)!Radio (FM)!Tape!CD
NOTE:
²Tape or CD mode cannot be selected unless a tape or
CD is in the slot.
To listen to the radio
To select AM/FM mode
Mode change button - 4
Select the desired band (AM or FM) by pressing this
button.
Automatic tuning the radio
Seek up button - 1
Seek down button - 5
After pressing these buttons, release the buttons, and
reception of the selected station will begin.
To select the preset memory
Preset change button - 3
When the radio is on and this button is pressed, the
preset station frequencies are sequentially selected each
time the button is pressed; 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 1, 2 etc.
230 FOR PLEASANT DRIVING

(3) In the following circumstances, moisture can form on
compact discs and inside the audio system, prevent-
ing normal operation.
²When there is high humidity (for example, when it
is raining).
²When the temperature suddenly rises, such as right
after the heater is turned on in cold weather.
In this case, wait until the moisture has had time to
dry out.
(4) When the CD player is subjected to violent vibra-
tions, such as during off-road driving, the tracking
may not work.
(5) When storing compact discs, always store them in
their separate cases. Never place compact discs in
direct sunlight, or in any place where the temperature
or humidity is high.(6) Never touch the flat surface of the disc where there
isn't a label. This will damage the disc surface and
could affect the sound quality. When handling a
compact disc, always hold it by the outer edge and
the center hole.
(7) To clean a disc, use a soft, clean, dry cloth. Wipe
directly from the center hole toward the outer edge.H12F090
FOR PLEASANT DRIVING 233
6

cover of the instrument panel (driver 's side). Always use
a fuse of the same capacity for replacement.
Passenger compartment fuse location
Fuse location table
No. Symbol Electrical system Capacity
1
Audio 20A
2
ÐÐÐ
3
Sunroof 20A
4
SOCKETAccessory socket 15A
5
Rear window defogger 30A
6
Heater 30A
7
ÐÐÐ
8
ÐÐÐ
9
SOCKETAccessory socket 15A
10
Door lock 15A
11
Rear window wiper 15A
12
ÐÐÐ
13
Relay 7.5A
14
R/C MIRElectric remote-controlled outside mirror 7.5A
15
ÐÐÐ
16
Cigarette lighter 15A
No. Symbol Electrical system Capacity
17
Engine Control 7.5A
18
Windshield wiper 20A
19
Door mirror heater 7.5A
20
Relay 7.5A
21
CRUISECruise control 7.5A
22
Back up light 7.5A
23
Gauge 7.5A
24
Engine control 10A
30A
25
ÐSpare fuse 20A
15A
10A
ISome fuses may not be installed on your vehicles,
depending on the vehicle model or specifications.
IThe table above shows the main equipment corre-
sponding to each fuse.
288 EMERGENCIES

No. Symbol Electrical system Capacity
1
Fuse (+B) 60A
2
Radiator fan motor 50A
3
Anti-lock braking system 60A
4
Ignition switch 40A
5
Electric window controls 30A
6
Fog lights 15A
7Ð Ð Ð
8
Horn 15A
9
Engine control 20A
10
Air conditioning 10A
11
Stop lights 15A
12
ÐÐ
13
Alternator 7.5A
14
Hazard warning flasher 10A
15
Automatic transaxle 20A
16
Headlights high beam (right) 10A
17
Headlights high beam (left) 10A
18
Headlights low beam (right) 10A
19
Headlights low beam (left) 10A
20
Position lights (right) 7.5A
21
Position lights (left) 7.5A
No. Symbol Electrical system Capacity
22
Dome lights 10A
23
Audio 10A
24
Fuel pump 15A
25
Defroster 40A
²Some fuses may not be installed on your vehicle. Fuse
application depends on the vehicle model, specifica-
tions, or options.
7.5A BROWN
10A RED
15A LIGHT BLUE
20A YELLOW
30A GREEN
40A GREEN
50A RED
60A YELLOW
290 EMERGENCIES
