2004 DODGE STRATUS COUPE cruise control

Cruise/speed control lever
Pull the cruise/speed control lever up and hold it. Your
speed will then gradually increase. When you reach your
desired speed, release the switch. Your cruising speed is
now set.
To increase your speed in small amounts, pull the cruise/
speed control lever up for less than 1 second and release
it. Each time you pull the lever up, your vehicle will go
about 1 mph (1.6km/h) faster.
Accelerator
Press the accelerator pedal to reach your desired speed.
Pull the cruise/speed control lever down for a moment,
then release it.
To decrease the set speed
There are 2 ways to reduce the set speed.
I10A1530I10A1550
192 STARTING AND DRIVING

Cruise/speed control lever
Pull the cruise/speed control lever down and hold it
while driving at the set speed, and you will slow down
(coast) gradually. When your desired low speed is
reached, release the lever.
To slow down in small amounts, press the cruise/speed
control lever down for less than 1 second and release it.
Each time you press the lever down, your vehicle will
slow down by about 1 mph (1.6km/h).
Brake pedal
Press the brake pedal (which disengages the cruise/
speed control), then pull the cruise/speed control lever
down momentarily to set a new desired cruise speed.
I10A1540I10A1110
STARTING AND DRIVING 193
5

To accelerate for passing
Press the accelerator pedal as you would normally. When
you release the pedal, the cruise/speed control will
return to your set speed.
To deactivate
The cruise/speed control can be turned off as follows:
1. Push the main switch (A) at the end of the lever (Main
switch OFF).
2. Pull the cruise/speed control lever (B) toward you.
The cruise/speed control can be turned off automatically
in any of the following ways:
I10A1520I10A1510
194 STARTING AND DRIVING

3. By slightly tapping the brake pedal or pressing down
on it to slow your speed.
4. By pressing the clutch pedal down (for vehicles with
manual transaxle).
5. By moving the selector lever to ªNº (for vehicles with
automatic transaxle).
6. When your speed slows to 10 mph (15km/h) or more
below the set speed because of a hill, etc.
7. When your speed slows to 25mph (40km/h) or less.
WARNING
²For vehicles with automatic transaxles, although
the cruise/speed control can be turned off by
moving the selector lever to the ªNº position,
never move the selector lever to the ªNº position
while driving. You would have no engine braking
and could cause a serious accident.
To resume the set speed
If the speed memory has not been erased, resume the
previously set speed by pulling the cruise/speed control
lever up while driving at a speed of 25 mph (40km/h) or
higher.
Under either of the following conditions, however, using
the switch does not allow you to resume the previously
set speed. In these situations, repeat the speed setting
I10A1530
STARTING AND DRIVING 195
5

cover of the instrument panel (driver 's side). Always use
a fuse of the same capacity for replacement.
Passenger compartment fuse location
Fuse location table
No. Symbol Electrical system Capacity
1
Audio 20A
2
ÐÐÐ
3
Sunroof 20A
4
SOCKETAccessory socket 15A
5
Rear window defogger 30A
6
Heater 30A
7
ÐÐÐ
8
ÐÐÐ
9
SOCKETAccessory socket 15A
10
Door lock 15A
11
Rear window wiper 15A
12
ÐÐÐ
13
Relay 7.5A
14
R/C MIRElectric remote-controlled outside mirror 7.5A
15
ÐÐÐ
16
Cigarette lighter 15A
No. Symbol Electrical system Capacity
17
Engine Control 7.5A
18
Windshield wiper 20A
19
Door mirror heater 7.5A
20
Relay 7.5A
21
CRUISECruise control 7.5A
22
Back up light 7.5A
23
Gauge 7.5A
24
Engine control 10A
30A
25
ÐSpare fuse 20A
15A
10A
ISome fuses may not be installed on your vehicles,
depending on the vehicle model or specifications.
IThe table above shows the main equipment corre-
sponding to each fuse.
288 EMERGENCIES

Cassette Tape and Player Maintenance....... 224
Cassette Tape Player..................219,221
CD Player.........................219,227
Center console......................... 215
Center console box...................... 213
Charging system warning light..........107,114
Check engine/malfunction indicator
lamp.............................107,115
Child restraint.......................... 76
Clean Air Gasoline...................... 145
Cleaning
Exterior of your car................... 254
Interior of your car.................... 253
Clock................................ 216
Compact spare tire...................267,367
Contract, Service....................... 374
Coolant (engine)....................... 322
Cruise control (for non-turbo)
Indicator.........................107,113
Cruise control (for turbo)
Indicator.........................107,113
Cup holder........................... 212Customer Arbitration Board............... 375
Customer Assistance.................... 372
Dealer Service......................... 372
Defroster (rear window).................. 125
Diagnostic System, Onboard............... 314
Dimmer control........................ 122
Disc brake pads........................ 329
Dome light........................... 305
Dome light/Reading light................ 129
Door hinges, rear hatch hinges, hood lock
release mechanism and safety catch......... 330
Door Opener, Garage.................... 132
Door-ajar warning light...............107,112
Doors
Lock............................... 26
Power door locks...................... 34
Drive belt............................ 333
Driving, alcohol and drugs................ 201
Driving speed
Automatic transaxle................... 157
Manual transaxle..................... 169
INDEX 383
