2004 DODGE SPRINTER check engine

250 MAINTENANCE SCHEDULES
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S8
MA INTENA NCE - WITH A SSYST MA INTENA NCE
COMPUTERASSYST provides you with information on the best
possible timing for maintenance work.
NOTE: The engine manufacturer strongly
recommends the use of synthetic engine oils, such as
Mobil 1 SAE 0W-40.
When the next maintenance service is due, this will be
indicated in the multi-function display with the
symbol
9 Oil service
9 Maintenance service - displayed in km/miles
or days.
9
If the display shows the number of days, the symbol
È will also appear in the multi-function display.
You should have the maintenance performed within
the stated period/distance.
The service indicator will be reset by your Sprinter
Dealer after an oil service and/or maintenance service
has been performed.
REGULA R CHECK-UPSTo maintain the safe operation of your vehicle, it is
recommended that you perform the following tasks on
a regular basis (i.e., weekly or whenever the vehicle is
refueled). Check:
 Engine oil level
 Brake system, clutch mechanism – fluid level
 Battery – acid level
 Windshield washer system and headlamp cleaning
system – fluid level
 Mechanical assemblies (e. g. ,engine, transmission,
etc.) – check for leaks
 Condition of tires and tire pressures
 All exterior lights
Freightliner-all.book Pag e 250 Monday, December 1, 2003 2:54 PM

MAINTENANCE SCHEDULES 251
8M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
SPECIAL MAINTENANCE REQUIREMENTSIf bodies built by manufacturers other than
DaimlerChrysler Corporation are fitted to the vehicle, the
maintenance requirements and lubrication intervals
specified by the body manufacturer must be adhered to,
in addition to all standard maintenance requirements.Brake FluidOnly use brake fluids approved by the manufacturer
(DOT 4 plus). Information about brake fluids is
available from your Sprinter Dealer.CoolantHave the corrosion inhibitor/antifreeze concentration
in the coolant checked before the onset of winter (once
a year in countries with high prevailing temperatures).
Have the coolant renewed every five years or 100,000
miles.Dust Filter for Heating/Ventilation ReplacementThe dust filter and the tailgate interior filter are
renewed during routine maintenance service.
However, if operating conditions are dusty, these
filters should be renewed more frequently.
ENGINE OIL CHA NGE A ND FILTER
REPLACEMENTIn a minimum, change the engine oil and oil filter once
a year - even if the vehicle mileage per year is extremly
low. For standard oil service schedules, please see the
chapter oil service and maintenance service.Once a YearSelect the viscosity of the engine oil (SAE classes)
according to the outside air temperature.
Only use engine oil approved by DaimlerChrysler
Corporation if following the ASSYST system
guidelines.
Information is available from your Sprinter Dealer.
If the fuel used has a sulphur content exceeding 0.05 %
by weight, the service intervals should be split in half.
If the sulphur content of the fuel used is between 0.3%
and 0.8% by weight, the service intervals should be
split in half (i.e. every 5,000 miles instead of every
10,000 miles).
Freightliner-all.book Pag e 251 Monday, December 1, 2003 2:54 PM

252 MAINTENANCE SCHEDULES
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S8
SCOPE OF WORK FOR MA INTENA NCE SERVICE
Oil ServiceOil change
Engine:
Oil change and filter replacement
Check fluid levels of the following system, refill as
necessary.
If fluid is lost, trace and eliminate cause – as a separate
order.
Power-assisted steering
Lubrication work:
Trailer tow hitch (original equipment)
Maintenance
ASSYST maintenance computer resetFunction check
Signalling system,
warning and indicator lamps
Headlamps, exterior lighting
Windscreen wipers,
windscreen washer system
Check for leaks and damage.
Check for abrasion points and ensure that
lines are correctly routed!
All assemblies:
Engine, transmission, transfer case, front axle, rear
axle, steering, power steering pump
All lines and hoses, sensor cables
Rubber boots on front axle drive shafts,
rubber boots on front axle suspension ball joints, shock
absorbersFreightliner-all.book Pag e 252 Monday, December 1, 2003 2:54 PM

MAINTENANCE SCHEDULES 253
8M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Check fluid levels for the following systems, correct
as necessary.
Should there be a loss of fluid which cannot be
explained by regular use, trace and eliminate
the cause.
Engine cooling system
Check corrosion inhibitor/antifreeze,
refill as necessary.
Hydraulic brake system
Battery
Windscreen washer system
Engine
Fuel filter renewal
Air cleaner with maintenance indicator:
Check degree of contamination.
Air cleaner filter element renewed as
necessary.Chassis and body
Trailer coupling:
Check operation, play and retaining fixtures
Secondary rubber springs:
Visual check
Tire pressures:
Correct as necessary, including spare tyre
Check thickness of brake pads
Brake test
Check condition of brake disks. Brake disks renewal as
necessary
– as a separate order
Check condition of steering mechanism
Heating/ventilation dust filter renewal
Freightliner-all.book Pag e 253 Monday, December 1, 2003 2:54 PM
