TOWING A DISABLED VEHICLE
Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for the purpose, following equip-
ment manufacturer's instructions. Use of safety chains is
mandatory. Attach a tow bar or other towing device to
the main structural members of the vehicleÐnot to
bumpers or associated brackets. State and local laws
applying to vehicles under tow must be observed.
4-Wheel- Drive Vehicles
CAUTION!
To avoid damage to the transfer case while towing,
always use one of the following methods.
The manufacturer recommends towing with all wheels
off the ground. Acceptable methods are to tow vehicle on
a flatbed or with one end of vehicle raised and the
opposite end on a towing dolly.
2±Wheel- Drive Vehicles
Provided that the transmission is operable, tow with the
transmission in Neutral and the ignition key in the OFF
position along with the front wheels raised and the rear
wheels on the ground. Speed must not exceed 30 mph (50
km/h) and distance must not exceed 15 miles (25 km).
If the vehicle is to be towed more than 15 miles (25 km)
the vehicle must be towed with the rear wheels raised
and the front wheels on the ground. It may also be towed
on a flatbed or with the front wheels raised and the rear
wheels on a dolly.
WHAT TO DO IN EMERGENCIES 315
6

WARNING!
Do not open the high pressure fuel system with the
engine running. Engine operation causes high fuel
pressure. High pressure fuel spray can cause serious
injury or death.
Priming if the engine has run out of fuel
1. Add a substantial quantity of fuel to the tank 5 to 10
gallons (19L to 38L).
2. Crank the engine for 1 to 2 seconds. If the engine does
not start, then release the key or starter button back to the
RUN position (do not turn the key back to the OFF
position). The electric fuel transfer pump will continue to
run and purge air from the system for about 25 seconds.
After 25 seconds, attempt to start the engine again.
3. Start the engine using the Normal Starting Procedure.4. Repeat the procedure if the engine does not start.
CAUTION!
Do not engage the starter motor for more than 15
seconds at a time. Allow two minutes between the
cranking intervals.
NOTE:The engine may run rough until the air is forced
from all the fuel lines.
CAUTION!
Diesel fuel will damage black top paving surfaces.
Drain the filter into an appropriate container.
MAINTAINING YOUR VEHICLE 335
7

Glass Cleaning.......................... 365
GVWR............................... 269
Hands-Free Phone........................ 79
Hazard Warning Flasher................... 296
Head Restraints.......................... 93
Headlights..........................101,367
High Beam........................... 104
High Beam/Low Beam Select Switch........ 104
Lights On Reminder.................... 102
Passing............................. 104
Switch.............................. 101
Heated Mirrors....................78,191,195
Heated Seats............................ 96
Heater............................... 187
High Beam/Low Beam Select Switch.......... 104
Hitches
Trailer Towing........................ 275
Hoisting.............................. 309Homelink Transmitter.................... 120
Hood Release........................... 97
Hoses.............................348,350
Hub Caps............................. 306
Hydraulic Clutch Fluid.................... 351
Ignition.............................14,204
Key ............................... 11,14
Lock................................ 14
Infant Restraint........................55,56
Inflation Pressure Tires.................... 259
Inside Rearview Mirror.................... 75
Instrument Cluster....................142,143
Instrument Panel and Controls.............. 141
Instrument Panel Lens Cleaning............. 365
Interior Appearance Care.................. 364
Intermittent Wipers...................... 105
Introduction............................. 4
INDEX 417
10

Jack Location........................... 298
Jack Operation.......................... 300
Jump Starting.......................... 310
Key, Replacement........................ 12
Key, Sentry............................. 11
Key-In Reminder......................... 11
Keyless Entry System...................... 22
Keys................................ 11,16
Lane Change and Turn Signals.............. 103
Lap Belts.............................. 42
Lap/Shoulder Belts....................... 34
LATCH (Lower Anchors and Tether for CHildren) . 59
Lights...............................70,99
Airbag............................55,144
Anti-Lock Warning..................146,242
Battery Saver......................... 100
Brake Warning........................ 147Bulb Replacement...................... 367
Cap Top Clearance..................... 375
Center Mounted Stop................... 373
Check Engine......................... 143
Courtesy/Reading..................... 113
Cruise.............................. 147
Daytime Running...................... 102
Dual Wheel Assembly Rear............... 376
Fog .............................102,378
Four-Wheel Drive Indicator............... 230
Hazard Warning Flasher................. 296
Headlights........................... 101
High Beam........................104,144
High Beam Indicator.................... 144
High Beam/Low Beam Select............. 104
Instrument Cluster..................... 143
Intensity Control....................... 100
Interior...........................99,113
Lights On Reminder.................... 102
418 INDEX

Low Washer Fluid..................... 149
Passing............................. 104
Seat Belt Reminder..................... 145
Service.............................. 367
Side Marker.......................... 378
Transfer Case......................... 230
Transmission Warning................150,281
Turn Signal..................103,144,367,371
Warning (Instrument Cluster Description)..... 143
Limited-Slip Differential................237,352
Loading Vehicle......................... 269
Tires ............................... 247
Locks................................. 16
Child Protection........................ 21
Door................................ 16
Ignition.............................. 14
Keys................................ 11
Power Door........................... 17
Steering Wheel......................... 14Lower Anchors and Tether for CHildren (LATCH) . 59
Lubricants............................. 356
Lubrication, Body....................... 340
Lug Nuts............................. 305
Lumbar Support......................... 94
Maintenance........................... 322
Maintenance Procedures................... 325
Maintenance Schedule.................... 384
Schedule9A9......................... 396
Manual, Service......................... 408
Manual Transmission...............222,224,352
Fluid Level Check...................... 352
Lubricant Selection..................352,381
Mirrors................................ 75
Automatic Dimming..................... 76
Electric Powered....................... 77
Outside.............................. 76
Rearview............................. 75
INDEX 419
10

Passing Light........................... 104
Pedals, Adjustable....................... 108
Phone, Cellular.......................... 79
Phone, Hands-Free....................... 79
Pickup Box............................ 133
Placard, Tire and Loading Information......... 247
Power
Distribution Center..................... 366
Door Locks........................... 17
Mirrors.............................. 77
Outlet.............................. 126
Seats................................ 95
Steering..........................242,339
Windows............................. 31
Power Steering Fluid..................... 381
Pregnant Women and Seat Belts.............. 44
Pretensioners
Seat Belts............................. 42
Programmable Electronic Features.........121,125Programming Transmitters..............121,125
Radial Ply Tires......................... 255
Radiator Cap........................... 343
Radio........................152,158,168,175
Radio Operation......................152,168
Radio Remote Controls.................... 181
Rear Axle............................. 351
Rear Wheel Bearings..................... 356
Reclining Front Seats...................... 93
Recommended Fluids, Lubricants and Genuine
Parts............................... 380
Recreational Towing...................... 286
Shifting into Transfer Case Neutral (N)....286,288
Shifting out of Transfer Case Neutral (N) . . . 287,290
Refrigerant............................ 339
Relays and Flashers...................... 366
Reminder, Seat Belt....................... 43
Remote Keyless Entry..................... 22
INDEX 421
10

Remote Sound System Controls.............. 181
Replacement Tires....................... 257
Reporting Safety Defects................... 407
Restraint, Head.......................... 93
Restraints, Child.......................55,62
Rotation, Tires.......................... 261
Safety Checks Inside Vehicle................. 70
Safety Checks Outside Vehicle............... 70
Safety Defects, Reporting.................. 407
Safety Information, Tire................... 243
Safety Tips............................. 68
Seat Belt Maintenance.................... 365
Seat Belt Reminder....................... 43
Seat Belts..........................33,34,70
Adjustable Upper Shoulder Anchorage........ 41
And Pregnant Women................... 44
Child Restraint.......................55,67
Extender............................. 44Front Seat............................ 34
Pretensioners.......................... 42
Reminder............................ 145
Seats...............................91,92
Adjustment........................... 91
Child............................... 67
Folding Floor......................... 130
Heated.............................. 96
Lumbar Support........................ 94
Power............................... 95
Reclining............................. 93
Security Alarm.......................29,147
Selection of Coolant...................... 380
Sentry Key............................. 11
Service Assistance....................... 402
Service Contract......................... 404
Service Information...................... 322
Service Manuals........................ 408
Setting the Clock........................ 151
422 INDEX
