2004 DODGE DURANGO windshield wipers

NHeadlights, Parking Lights, Panel Lights.....106
NIlluminated Entry.....................107
NDaytime Running Lights (Canada Only).....107
NLights-On Reminder...................107
NFog Lights Ð If Equipped...............107
mMultifunction Control Lever...............108
NTurn Signals.........................108
NPassing Light........................109
NHigh Beam / Low Beam Select Switch......109
NWindshield Wipers....................110
NWindshield Washers...................111
mTraction Control Switch Ð If Equipped.......112
mTilt Steering Column....................113mDriver Adjustable Pedals Ð If Equipped......114
NAdjustment.........................115
mElectronic Speed Control Ð If Equipped......116
NTo Activate..........................116
NTo Set At A Desired Speed...............116
NTo Deactivate........................116
NTo Resume Speed.....................117
NTo Vary The Speed Setting...............117
NTo Accelerate For Passing...............118
mOverhead Console......................119
NCourtesy/Reading Lights................120
mCompass/Temperature Mini-Trip Computer....120
NUS/M Button........................120
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
3

Windshield Wipers
The wipers and washers are operated by a switch in the
multifunction control lever. Turn the end of the handle to
select the desired wiper speed.
Intermittent Wiper System
The intermittent feature of this system was designed for
use when weather conditions make a single wiping cycle,
with a variable pause between cycles, desirable. For
maximum delay between cycles, rotate the control knob
into the upper end of the delay range.
The delay interval decreases as you rotate the knob until
it enters the LO continual speed position. The delay can
be regulated from a maximum of about 15 seconds
between cycles, to a cycle every 2 seconds. The delay
intervals will double in duration when the vehicle speed
is 10 mph (16 km) or less.
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Sudden loss of visibility through the windshield
could lead to an accident. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with defroster before and during wind-
shield washer use.
NOTE:If the front wiper is operating when the ignition
is turned off, the wiper will automatically return to the
9Park9position. When the vehicle is restarted, the wipers
will resume operation.
Windshield Washers
To use the washer, push in on the washer knob on the end
of the multifunction control lever and hold while spray is
desired. If the washer knob is depressed while in the
delay range, the wiper will operate for several seconds
after the washer knob is released. It will then resume the
intermittent interval previously selected. If the washer
knob is pushed, for a period greater than 1 second, while
in the OFF position, the wiper will wipe approximately
three wipes, after the wash knob is released.
To prevent freeze-up of your windshield washer system
in cold weather, select a solution or mixture that meets or
exceeds the temperature range of your climate. This
rating information can be found on most washer fluid
containers.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3

Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
Windshield Washers
The fluid reservoir should be checked for fluid level at
regular intervals. When freezing weather is anticipated,
flush out the water in the reservoir by operating thesystem. Fill the reservoir with windshield washer anti-
freeze (not radiator antifreeze), and operate the system
for a few seconds to flush out the residual water.
To prevent freeze-up of your windshield washer system
in cold weather, select a solution or mixture that meets or
exceeds the temperature range of your climate. This
rating information can be found on most washer fluid
containers.
WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
After the engine has warmed, operate the defroster for a
few minutes to reduce the possibility of smearing or
MAINTAINING YOUR VEHICLE 305
7

Daytime Running Lights................... 107
Dealer Service.......................... 291
Defroster, Rear Window................... 195
Defroster, Windshield................63,182,187
Delay Wipers........................... 110
Diagnostic System, Onboard................ 289
Dimmer Switch, Headlight................. 147
Dipsticks
Automatic Transmission................. 316
Oil (Engine).......................... 292
Power Steering........................ 303
Disarming, Theft System................... 25
Disc Brakes............................ 313
Disposal
Used Coolant......................... 308
Door Ajar Light......................... 151
Door Locks............................. 13
Door Opener, Garage..................... 126
Drive Belts............................ 297Drive Shaft Universal Joints................ 304
Electric Remote Mirrors.................... 72
Electrical Power Outlets................... 135
Electronic Speed Control................... 116
Emergency, In Case of
Freeing Vehicle When Stuck............... 221
Jacking............................. 275
Overheating.......................... 310
Towing............................. 282
Emission Control System Maintenance......... 340
Emission Related Components.............. 311
Engine
Air Cleaner.......................... 298
Block Heater......................... 202
Break-In Recommendations................ 62
Compartment......................287,288
Coolant..........................308,337
Cooling............................. 306
INDEX 373
10

Windshield Defroster................63,182,187
Windshield Washers................ 110,111,305
Fluid............................ 110,305
Windshield Wiper Blades.................. 305
Windshield Wipers....................... 110Wiper Blade Replacement.................. 305
Wiper, Rear............................ 194
Wipers, Intermittent...................... 110
Wrecker Towing......................... 282
386 INDEX
