AXLES
SUSPENSION
STEERING
FEATURES OF ELECTRIC POWER STEERING
Engines: HFX KFV NFU 8HX
Steering assistance
Supplier:KOYO.
The steering assistance is rpovided by the assistance motor
(12),
controlled by the ECU.
Power delivered to the assistance motor
(12)depends on:
Speed of the vehicle.
Torque applied on the steering wheel.Only one ECU version, whatever the engine type.
The electric power steering ECU is linked to the following connectors:
(6)Assistance motor supply.
(13)Electric power steering ECU supply.
(14)Control signals.
After changing the electric power steering ECU, it is necessary to
perform a configuration.
B3EP13KCB3EP13LC
C2
Electric power steering ECU
Downloaded from www.Manualslib.com manuals search engine 378
AXLES
SUSPENSION
STEERING
FEATURES OF ELECTRIC POWER STEERING
Engines: HFX KFV KFU NFU 8HX 8HW 8HV 8HY
Steering assistance
Supplier:KOYO.
The steering assistance is rpovided by the assistance motor
(12), controlled
by the ECU.
Power delivered to the assistance motor
(12)depends on:
Speed of the vehicle.
Torque applied on the steering wheel.
Electric power assisted steering ECU.
Only one ECU version, whatever the engine type.
The electric power steering ECU is linked to the following connectors:
(6)Assistance motor supply.
(13)Electric power steering ECU supply.
(14) Control signals.
After changing the electric power steering ECU, it is necessary to
perform a configuration
(see corresponding operation).
B3EP13KCB3EP13LC
C3 C3 PLURIEL
