ENGINESPECIAL FEATURES TIGHTENING TORQUES (m.daN )
Engines8HV 8HY
Flywheel Clutch
Flywheel 1,7 ± 0,2
Clutch mechanism 2 ± 0,2
Lubrication circuit
Oil pump assembly0,9 ± 0,1
Oil/coolant heat exchanger 1 ± 0,1
Turbocharger lubrication pipe2,2 ± 0,2
Injection circuit
Injector fixing flange nut
Tightening0,4 ±0,1
Angular tightening65° ± 5°
Fuel high pressure pump
Union on diesel injector
Fuel high pressure pump pinion 5 ± 0,5
Union on fuel high pressure pump2,3 ± 0,2
Cooling circuit
Coolant pump1 ± 0,2±
C3

Downloaded from www.Manualslib.com manuals search engine 94
ENGINESPECIAL FEATURES TIGHTENING TORQUES (m.daN )
Engines9HZ 9HY
Lubrication circuit
Oil pump assembly
Pretightening0,5 ± 0,1
Tightening0,9 ± 0,1
Oil/coolant heat exchanger 1 ± 0,2
Turbocharger lubrication pipe3 ± 0,5
Diesel injection circuit
Injector fixing flange nut
Pretightening4 ± 0,1
Angular tightening65° ± 5°
Fuel high pressure common injection rail on engine block 2,2 ± 0,2Union on fuel high pressure common injection rail
Pretightening1,7 ±0,2
Tightening2,2 ±0,2
Diesel injection pump on support2,2 ± 0,2
Union on diesel injector
Pretightening2 ± 0,5
Tightening2,5 ±0,3
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 233
INJECTION
Emission standard Engine type
Injection make
and type
PETROL INJECTION
Air temperature sensor
resistive value (ohms)
C2
M. MARELLI 48P2 SAGEM S2000 BOSCH M.7.4.4.
Fuel pressure (bars)
Overspeed cutoff (rpm)
Injector resistive value (ohms)
Engine coolant temperature
sensor resistive value (ohms)
Idling actuator or stepper
motor resistive value (ohms)
HFX KFV NFU
L4/IFL5 L4/IFL5 IFL5
1.1i 1.4i 1.6i 16V
333
5500 5500 6600
14,5 12,2 14,5
Stepper motor: 53 3 800 at 10°C 2500 at 20° C 800 at 50°C 230 at 90° C
3 800 at 10°C 2500 at 20° C 800 at 50°C 230 at 90° C
C2

Downloaded from www.Manualslib.com manuals search engine 234
INJECTION
Emission standard Engine type
Injection make
and type
PETROL INJECTION
C3 C3 PLURIEL
Air temperature sensor
resistive value (ohms)
C3 PLURIEL
C3
M. MARELLI
48P2M. MARELLI
6LP SAGEM
S2000BOSCH
M.7.4.4.SAGEM
S2000BOSCH
M.7.4.4.
Fuel pressure (bars)
Overspeed cutoff (rpm)
Injector resistive value (ohms)
Engine coolant temperature
sensor resistive value (ohms)
Idling actuator or stepper
motor resistive value (ohms)
HFX
K’L4INFL4/IFL5 L5 K’L4INFL4/IFL5 L4 L4/IFL5 IFL5
1.1i 1.4i 1.4i 16V 1.6i 16V
1.6i 16V
1.4i
KFU
KFV NFU KFV NFU
3,53,5
3,5
3,5 3,5 3,5
14,5 14,5 14,5
12,214,5 14,5
5500
5800
5500
5500
5500 5800
Stepper motor:53 3800 at 10° C 2 500 at 20° C 800 at 50° C 230 at 90° C
3800 at 10° C 2 500 at 20° C 800 at 50° C 230 at 90° C

Downloaded from www.Manualslib.com manuals search engine 235
INJECTION
Emission standard Engine type
Injection make
and type
PETROL INJECTION
XSARA XSARA PICASSO
Air temperature sensor
resistive value (ohms)
XSARA PICASSO
XSARA 2
SAGEM
S2000M. MARELLI
6LP BOSCH
M.7.4.4.BOSCH
M.7.4.4.SAGEM
S2000M. MARELLI
6LP
Fuel pressure (bars)
Overspeed cutoff (rpm)
Injector resistive value (ohms)
Engine coolant temperature
sensor resistive value (ohms)
Idling actuator or stepper
motor resistive value (ohms)
KFW
L4/IFL5/L5 L4/IFL5 L4/IFL5 L4 IFL5L4/IFL5
1.4i 1.6i 16V 2.0i 16V 1.6i
2.0i 16V
1.8i 16V
RFN
NFU NFV 6FZ RFN
3,53,5
3
3 3,5 3,5
14,5 14,5 14,5
14,512,2 14,5
5500
5700
6000
5800
5500 6000
Stepper motor:53 3800 at 10° C 2 500 at 20° C 800 at 50° C 230 at 90° C
3800 at 10° C 2 500 at 20° C 800 at 50° C 230 at 90° C

Downloaded from www.Manualslib.com manuals search engine 244
INJECTION
SAFETY REQUIREMENTS: HDi DIRECT INJECTION SYSTEM
Engines: HDi ALL TYPES
CLEANLINESS REQUIREMENTS.
Preliminary operations.
IMPERATIVE: The technician should wear clean overalls.
Before working on the injection system, it may be necessary to clean the apertures of the following sensitive components:(refer to corresponding procedures) Fuel filter.
High pressure fuel pump.
High pressure fuel injection common rail. High pressure fuel pipes
Diesel injector carriers.
IMPERATIVE: After dismantling, immediately block the apertures of the sensitive components with plugs, to avoid the entry of impurities.
Work area.
The work area must be clean and free of clutter.
Components being worked on must be protected from dust contamination.

Downloaded from www.Manualslib.com manuals search engine 245
INJECTION
PROHIBITED OPERATIONS: SIEMENS HDI DIRECT INJECTION SYSTEM
Engines: 8HX 8HW 8HZ
Cleaning.
The use of high pressure cleaners is prohibited.
Do not use compressed air.
Fuel supply circuit.
Required fuel: diesel.
Electric circuit.
Swapping injection ECUs between two vehicles will render it impossible to start either vehicle.
It is forbidden to supply a diesel injector with
12 volts.
High pressure fuel pump.
Do not separate the following components from the high pressure fuel pump (5):
Sealing ring
(a)(no replacement parts).
High pressure outlet connector
(b)(will cause a malfunction).
PS: HDi = High pressure Diesel injection
B1HP1K9C
C2 C3 XSARA

Downloaded from www.Manualslib.com manuals search engine 246
INJECTION
PROHIBITED OPERATIONS: SIEMENS HDI DIRECT INJECTION SYSTEM
Engines: 8HX 8HW 8HZ
Diesel injectors.
WARNING: Diesel and ultrasonic c
leaners are prohibited.
Do not separate the following components from the diesel injector
carrier
(2):
Diesel injector
(f)(no replacement parts).
Electromagnetic element
(c)(no replacement parts).
Do not alter the position of the nut
(d)(malfunction).
Do not separate the connector
(e)from a diesel injector.
It is forbidden to clean the carbon deposits from the diesel injector
nozzle.
B1HP1KACB1HP1KBC
C2 C3 XSARA
