2004 CHRYSLER SEBRING COUPE set clock

Changing the blower speed
The blower may be operated (when the ignition key is in
the ON position) at 4 different speeds. Select the best
speed to fit your needs. When the blower switch is set to
the ``O'' position, all air conditioning functions will stop.
Changing the temperature
Select the desired temperature level by turning the tem-
perature control dial either clockwise or counterclock-
wise. Turning the temperature control dial clockwise
makes the air warmer.
NOTE: When the engine coolant temperature is low, the
temperature of air introduced into the passenger com-
partment does not change even if the temperature control
dial is moved to the high temperature side.
H23A2860H23A2870
FOR PLEASANT DRIVING 235
6

How to use the controls
Heating
Set the mode selection dial to the position shown in the
illustration and set the air selection switch (A) to the
ªoutsideº position.
Adjust the temperature by turning the temperature con-
trol dial clockwise. Select the desired blower speed.
NOTE: When maximum heating is needed, set the
blower speed to the fourth position.
Defrosting or defogging of the windshield and
door windows
CAUTION!
For safety, make sure you have a clear view through
all windows before driving.
To remove frost or fog from the windshield and door
windows, use the mode selection dial (ª
ºorªº).
H03B0710
H03H0320
242 FOR PLEASANT DRIVING

Adjust the temperature by turning the temperature con-
trol dial clockwise or counterclockwise.
Select the desired blower speed.
NOTE: If the outside air is dusty or otherwise contami-
nated, or if maximum cooling performance is desired, set
air selection switch (A) to the recirculation position and
the temperature control dial all the way to the left.
Introduce outside air from time to time for proper
ventilation.
Important operation tips for air conditioning
1. Park the vehicle in the shade whenever possible.
Parking under the hot sun makes the vehicle interior
extremely hot, which requires more time to cool the
interior. If it is necessary to park in the sun, open the
windows for the first few minutes of air conditioning
operation to expel hot air.
2. Close the windows when the air conditioning is in use.
The entry of outside air through open windows will
reduce cooling efficiency.
3. When operating the system, make sure the air intake,
which is located in front of the windshield, is free of
obstructions such as leaves. Leaves collected in the
air-intake plenum may reduce air flow and plug the
plenum water drains.
Air conditioning system refrigerant and lubricant
recommendations
If the air conditioning seems less effective than usual, the
cause might be a refrigerant leak.
Have the system inspected by your authorized dealer.
H04F0980
FOR PLEASANT DRIVING 245
6

Cassette Tape and Player Maintenance....... 222
Cassette Tape Player..................217,219
CD Player.........................217,225
Center console......................... 213
Center console box...................... 211
Charging system warning light..........105,112
Check engine/malfunction indicator lamp . 105,113
Child restraint.......................... 74
Clean Air Gasoline...................... 143
Cleaning
Exterior of your car................... 250
Interior of your car.................... 249
Clock................................ 214
Compact spare tire...................263,361
Contract, Service....................... 368
Coolant (engine)....................... 316
Cruise control (for non-turbo)
Indicator.........................105,111
Cruise control (for turbo)
Indicator.........................105,111
Cup holder........................... 210
Customer Arbitration Board............... 369
Customer Assistance.................... 366Dealer Service......................... 366
Defroster (rear window).................. 123
Diagnostic System, Onboard............... 308
Dimmer control........................ 120
Disc brake pads........................ 323
Dome light........................... 299
Dome light/Reading light................ 127
Door hinges, rear hatch hinges, hood lock
release mechanism and safety catch......... 324
Door Opener, Garage.................... 130
Door-ajar warning light...............105,110
Doors
Lock............................... 26
Power door locks...................... 34
Drive belt............................ 327
Driving, alcohol and drugs................ 199
Driving speed
Automatic transaxle................... 155
Manual transaxle..................... 167
Electric rear window defroster switch........ 123
Emission-control system maintenance........ 307
Engine compartment.................255,305
INDEX 377

Seatback.............................. 58
Seats
Front seats........................... 55
Rear seats............................ 64
SECURITY indicator................48,105,110
Service Assistance...................... 366
Service Manuals........................ 371
Setting the clock........................ 214
Severe maintenance schedule.............. 343
Snow tires............................ 333
Spare tire.......................262,263,361
Spark plugs........................ 311,363
Speedometer.......................104,106
Starting
At extremely cold ambient temperature..... 151
Flooded engine....................... 151
Normal conditions.................... 150
Steering system
Steering lock......................... 149
Tilt lock lever........................ 173
Sun visors............................ 207
Sunroof............................... 45Supplemental Restraint System - Airbag
Maintenance......................... 323
Warning light.....................105,114
Supplemental Restraint System (SRS) - Air bag . . 87
Supplemental Restraint System warning light . . 114
Tachometer........................104,106
Tape Player........................... 217
Temperature Gage, Engine Coolant.......... 275
Theft protection........................ 149
Theft-alarm
SECURITY indicator..............48,105,110
System.............................. 48
Timing belt........................... 328
Tips for driving in various conditions........ 199
Tire chains............................ 333
Ti re s
Compact spare tire.................... 263
Inflation pressure...............328,360,361
Maintenance......................328,331
Quality Grading...................... 373
Rotation............................ 332
Size (tire and wheels).................. 361
INDEX 381
