2004 CHRYSLER SEBRING CONVERTIBLE key

HAZARD WARNING FLASHER
The flasher switch is on top of the steering column,
just behind the steering wheel. Depress the switch
and both cluster indicators and all front and rear direc-
tional signals will flash. Depress the switch again to turn
Hazard Warning Flashers off.
Do not use this emergency warning system when the
vehicle is in motion. Use it when your vehicle is disabled
and is creating a safety hazard for other motorists.If it is necessary to leave the vehicle to go for service, the
flasher system will continue to operate with the ignition
key removed and the vehicle locked.
NOTE:With extended use, the flasher may wear down
your battery.
IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
²On the highways Ð Slow down.
²In city traffic Ð While stopped, put transaxle in
neutral, but do not increase engine idle speed.
NOTE:There are steps that you can take to slow down
an impending overheat condition. If your air conditioner
is on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
control to maximum heat, the Mode control to floor, and
174 WHAT TO DO IN EMERGENCIES

TOWING THIS VEHICLE BEHIND ANOTHER
VEHICLE (Flat towing with all four wheels on the
ground)
Automatic Transaxle
Your vehicle may be towed under the following condi-
tions: The gear selector must be in NEUTRAL, the
distance to be towed must not exceed 15 miles (25 km),
and the towing speed must not exceed 25 mph (40
km/h). If the transaxle is not operative, or if the vehicle
is to be towed more than 15 miles (25 km), the vehicle
must be towed with the front wheels off the ground.
Manual Transaxle
If your vehicle is equipped with a manual transaxle, it
may be towed at any legal highway speed, for any
distance, if the transaxle is in neutral.
All Transaxles
CAUTION!
If the vehicle being towed requires steering, the
ignition switch must be in the OFF position, not in
the LOCK or ACCESSORY positions.
If it is necessary to use the accessories while being towed
(wipers, defrosters, etc.), the key must be in the ON
position, not the ACCESSORY position. Make certain the
transaxle remains in NEUTRAL.
186 WHAT TO DO IN EMERGENCIES

EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle's emissions control system.
Failure to pass could prevent vehicle registration.
For states which have an I/M (Inspection and
Maintenance) requirement, this check verifies the
following: the MIL (Malfunction Indicator Lamp)
is functioning and is not on when the engine is running,
and that the OBD (On Board Diagnostic) system is ready
for testing.
Normally, the OBD system will be ready. The OBD
system maynotbe ready if your vehicle was recently
serviced, if you recently had a dead battery, or a battery
replacement. If the OBD system should be determined
not ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition key actuated test
which you can use prior to going to the test station. To
check if your vehicle's OBD system is ready, you must do
the following:
1. Insert your ignition key into the ignition switch.2. Turn the ignition to the ON position, but do not crank
or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
4. As soon as you turn your key to the ON position, you
will see your MIL symbol come on as part of a normal
bulb check.
5. Approximately 15 seconds later, one of two things will
happen:
a. The MIL will flash for about 10 seconds and then
return to being fully illuminated until you turn off
the ignition key or start the engine. This means that
your vehicle's OBD system isnot readyand you
shouldnotproceed to the I/M station.
b. The MIL will not flash at all and will remain fully
illuminated until you turn off the ignition key or
start the engine. This means that your vehicle's OBD
system isreadyand you can proceed to the I/M
station.
192 MAINTAINING YOUR VEHICLE

Multi-Purpose Lubricant, NLGI Grade 2, should be ap-
plied sparingly to all pivot and sliding contact areas.
External Lock Cylinders
Lubricate the external lock cylinders twice a year, prefer-
ably in the fall and spring. Apply a small amount of
lubricant, such as Mopar Lock Cylinder Lubricant di-
rectly into the lock cylinder (avoid excess lubricant).
Insert the key into the lock cylinder and rotate from the
unlocked to the locked position; without adding more
lubricant. Repeat this procedure three or four times. Wipe
all the lubricant off the key with a clean cloth, to avoid
soiling clothing.
If you use a lubricant that cannot be dispensed directly
into the lock cylinder, apply a small amount of the
lubricant to the key. Insert the key into the lock cylinder,
then proceed as described above, to distribute the lubri-
cant within the lock cylinder. Pay attention to trunk
hinges, especially during cold weather, to ensure ease of
trunk operation.
Other Body Mechanisms
The following body mechanisms should be inspected
and, if necessary, all pivot and sliding contact areas of
these components should be lubricated with the lubricant
specified as follows:
Engine Oil
²
Door hinges
²Hood hinges
²Trunk hinges
Smooth White Body Lubricant - Such as Mopar
Spray White Lube:
²
Hood hinge springs and links
²Lock cylinders
²Parking brake mechanism
²Trunk latches
²Ash tray
204 MAINTAINING YOUR VEHICLE

Cooling System
Inspection
WARNING!
²When working near the radiator cooling fan, dis-
connect the fan motor lead or turn the ignition key
to the OFF position. The fan is controlled by both
the temperature of the engine cooling system and
the pressure in the air conditioning system and
can start at any time the ignition key is in the ON
position.
²You or others can be badly burned by hot coolant
or steam from your radiator. If you see or hear
steam coming from under the hood, don't open
the hood until the radiator has had time to cool.
Never try to open a cooling system pressure cap
when the radiator or cap is hot.
Coolant Checks
Check coolant protection every 12 months (before the
onset of freezing weather, where applicable). If coolant isdirty or rusty in appearance, the system should be
drained, flushed and refilled with fresh coolant.
Check the front of the radiator for any accumulation of
bugs, leaves, etc. Clean the radiator by gently spraying
water from a garden hose at the back of the core.
Check the recovery bottle tank tubing for condition and
tightness of connections at the bottle. Inspect the entire
system for leaks.
Do not remove the cap when the cooling system is hot.(2.7L Engine Shown)
MAINTAINING YOUR VEHICLE 207
7

About Your Brakes...................... 142
Adding Engine Coolant (Antifreeze)......... 208
Adding Fuel.......................... 164
Aiming Headlights...................... 232
Air Cleaner, Engine..................... 198
Air Conditioning....................... 122
Air Conditioning, Operating Tips........... 126
Air Conditioning Refrigerant.............. 202
Air Conditioning System..............122,201
Air Pressure, Tires...................... 153
Airbag................................ 29
Airbag Deployment...................... 32
Airbag Light.....................32,34,43,87
Airbag Maintenance...................... 34
Alarm, Panic........................... 17
Alarm System........................19,92
Alignment and Balance.................. 158
Alterations/Modifications, Vehicle............ 6
Antifreeze Disposal..................... 209
Antifreeze (Engine Coolant)............... 208
Capacities........................... 232
Anti-Lock Brake System.................. 142
Anti-Lock Warning Light.................. 90Anti-Theft Security Alarm................. 19
Appearance Care....................... 216
Automatic Dimming Mirror................ 56
Automatic Door Locks.................... 14
Automatic Transaxle...............135,186,213
Filter.............................. 215
Fluid and Filter Changes................ 215
Fluid Level Check..................... 214
Interlock System....................10,136
Reset Mode......................... 137
Selection Of Lubricant................. 214
Shifting............................ 137
Special Additives..................... 215
Autostick............................. 160
Auxiliary Power Outlet................... 78
Ball Joints............................ 203
Battery............................... 200
Emergency Starting.................... 181
Gas Caution......................183,201
Heater............................. 134
Jump Starting........................ 181
Keyless Transmitter Replacement.......... 18
260 INDEX

Capacities........................... 232
Fog Light Service....................... 229
Fog Lights..........................67,229
Freeing A Stuck Vehicle.................. 185
Fuel
Adding............................. 164
Filler Cap........................... 164
Filter.............................. 198
Gauge.............................. 87
Hoses.............................. 213
Light............................... 92
Tank Capacity........................ 232
Fuses................................ 223
Garage Door Opener..................... 73
GasCap .............................. 164
Gas Gauge............................. 87
Gasoline, Reformulated.................. 162
Gasoline/Oxygenate Blends............... 162
Gauges
Coolant Temperature................... 89
Fuel................................ 87
Tachometer.......................... 87Voltmeter............................ 88
Gearshift............................. 137
Glass Cleaning......................... 220
Hazard Warning Flasher.................. 174
Head Restraints......................... 62
Headlights............................ 226
Aiming............................. 232
Bulb Replacement..................... 226
Cleaning............................ 219
High Beam........................... 88
Switch.............................. 66
Time Delay........................... 67
Heater............................... 122
High Beam Indicator..................... 88
Homelink Transmitter.................... 73
Hood Prop............................ 63
Hood Release.......................... 62
Hoses............................. 211,213
Ignition
Key ................................. 9
Lock................................ 9
264 INDEX

Illuminated Entry....................... 12
Immobilizer............................ 10
Infant Restraint......................... 35
Inside Rearview Mirror................... 56
Instrument Cluster..................84,85,86
Instrument Panel and Controls.............. 83
Instrument Panel Cover.................. 220
Instrument Panel Lens Cleaning............ 220
Interior Fuses.......................... 223
Interior Lighting........................ 64
Interior Lights.......................... 64
Introduction............................ 4
Jack Location.......................... 176
Jack Operation......................... 176
Jump Starting......................... 181
Key, Programming....................... 11
Key, Sentry............................ 10
Key-In Reminder........................ 10
Keyless Entry System..................... 15
Keys.................................. 9Lap/Shoulder Belts...................... 23
LATCH
(Lower Anchors and Tether for CHildren) . . . 37,38
Leaks, Fluid............................ 43
Lights................................ 64
Airbag..........................32,43,87
Anti-Lock Warning..................... 90
Brake Warning.....................91,141
Bulb Replacement..................... 225
Check Engine......................... 88
Daytime Running...................... 66
Dimmer Switch, Headlight.............66,67
Exterior Check........................ 43
Fog ...........................67,89,229
Front Replacement.................228,229
Headlight Switch...................... 66
Illuminated Entry...................... 12
Instrument Cluster..................... 66
Interior.............................. 64
License............................. 231
Lights On Reminder.................... 67
Low Fuel............................ 92
Map Reading......................... 64
INDEX 265
10
