2004 CHRYSLER PT CRUISER engine

8
7/115 POWERTRAIN WARRANTY
The following powertrain components are covered for 7 years or 115,000 kilometres, whichever occurs first, measured from thevehicleÕs original warranty start date. A $100 deductible per repairvisit applies after the 3-year or 60,000-kilometre basic warrantyexpires (whichever occurs first)
Vehicles placed in Police, Taxi, Limousine, Postal or Ambulance
service are excluded from the 7-year or 115,000-kilometrepowertrain warranty and are covered only under the 3-year or60,000-kilometre basic warranty. ¥ Engine Ð Cylinder block and all internal parts; cylinder head
assemblies; timing case, timing chain, timing belt, gears and sprockets; vibration damper; oil pump; water pump and housing;intake and exhaust manifolds; flywheel with starter ring gear; coreplugs; valve covers; oil pan; turbocharger housing and internalparts; turbocharger wastegate actuator; supercharger; serpentinebelt tensioner; seals and gaskets for listed components only. ¥
Transmission Ð Transmission case and all internal parts; torque
converter; drive/flex plate; transmission range switch;transmission control module; bell housing; oil pan; seals andgaskets for listed components only.
Note: Manual transmission clutch parts are not covered at any time .
¥ Front-Wheel Drive Ð Transaxle case and all internal parts; axle
shaft assemblies; constant velocity joints and boots; differentialcover; oil pan; transaxle speed sensors; transaxle solenoidassembly; PRNDL position switch; transaxle electronic controller;torque converter; seals and gaskets for listed components only.
Note: Manual transmission clutch parts are not covered at any time.
¥ All-Wheel Drive (AWD) Ð Power transfer unit and all internal
parts; viscous coupler; axle housing and all internal parts;constant velocity joints and boots; drive shaft and axle shaftassemblies; differential carrier assembly and all internal parts;output ball bearing; output flange; end cover; overrunning clutch;vacuum motor; torque tube; pinion spacer and shim, seals andgaskets for listed components only.
7/115 POWERTRAIN WARRANTY
2004 Passenger Car, Minivan & Pacifica
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 8

2004 Passenger Car, Minivan & Pacifica
12
WHAT IS NOT COVERED
WHA
T IS NOT COVERED
DAMAGE FROMMISUSE ORACCIDENT
The warranties in this booklet do not cover repairs required due to fire, accidents, abuse, negligence, objects striking your vehicle,carrying corrosive materials (such as chemicals, acids andfertilizers), misuse (such as driving over curbs, overloading,spinning wheels, etc.), racing or participating in a racing event,improper disconnection of components, modifying the exhaustsystem, tampering or making adjustments which do not complywith DaimlerChrysler specifications.
Disconnecting, tampering with or changing the reading of the
odometer will void your warranties. D AMAGE FROMTHEENVIRONMENT
The warranties in this booklet do not cover fading or deterioration caused by exposure to the elements, or repairs required due toairborne fallout, acid rain, chemicals, tree sap, insects, bird or insectdroppings, salt, sand, gravel, road hazards, hail, windstorms,lightning, floods or any other event of nature. Road salt, car washes, scuffs and scratches, and everyday
abrasion from sand and dirt can affect the appearance of a vehicleÕs wheels (steel, chrome and aluminum) and other undercarriageparts. Some surface corrosion with use is normal; it is not a defectand is not covered by any warranty. N ORMAL MAINTENANCE ANDWEAR
The warranties in this booklet do not cover normal maintenance services, such as oil and filter changes, generallubrication, tire rotation, engine tune-ups and replacing sparkplugs. Required maintenance services are described in detail inyour OwnerÕs Manual and herein. The warranties also do notcover light bulbs and fuses, worn wiper blades, clutch discs, brakerotors, pads, linings or drums, windshield and rear window,wheel alignment and wheel balancing (unless they are defective,
see page 7).
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 12

2004 Passenger Car, Minivan & Pacifica
16
OTHER THINGS YOU SHOULD KNOW
OTHER THINGS YOU SHOULD KNOW
O
PTIONAL SERVICE CONTRACT
DaimlerChrysler Canada has a service contract specially designed for most new vehicles, to cover repair costs beyond your vehicleÕswarranty. Protection is available for almost every operating part ofyour vehicle, and at reasonable cost.
DaimlerChrysler Canada stands fully behind its service
contracts. Be sure that the contract you buy is a genuineDaimlerChrysler service contract. We are notresponsible for
other companiesÕ contracts. See page 24 for details on available Service Contracts. A PPEARANCE ITEMS
Defects or damage to sheet metal, paint, trim and other appearance items are normally found and corrected during new-vehicleinspection. For your protection, if you find any such defect ordamage, you should tell your Selling Dealer immediately, because ifthe problem worsens due to use and exposure, repairs will not becovered by any warranty. P
RODUCTION CHANGES
DaimlerChrysler Canada and its dealers reserve the right to make changes in vehicles built and/or sold at any time without incurringany obligations to make the same or similar changes on vehicleswhich were built and/or sold previously. E XCHANGE PAR TS
To reduce the amount of time your vehicle is out of service due to repairs, DaimlerChrysler may offer exchange service on some parts. Mopar or Autopar ¨brand exchange parts may be new,
remanufactured, reconditioned or repaired, but all meetDaimlerChrysler standards and are warranted the same as newparts. Examples of parts that may be serviced by exchange includeengines, transmissions, instrument clusters, radios, tape and CDplayers, speedometers and various electronic modules.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 16

2004 Passenger Car, Minivan & Pacifica25
1.
POWER TRAIN PLANS
Plan 737 complements the powertrain factory warranty by eliminating the deductible and providing a car rental allowance.Plan 738 provides additional distance coverage. Major components covered are: ¥ engine ¥ transmission ¥ front-wheel drive ¥ rear-wheel drive¥ four-wheel drive (4x4) ¥ all-wheel-drive vehicles Maximum terms available on new vehicles registered in Canada only.
P LAN CODE TERM DEDUCTIBLE
Plan 737 7 years or 115,000 km* $0
Plan 7387 years or 160,000 km* $0
*Whichever comes first. Measured from the warranty start date (the original in-service date of the vehicle) and from zero metrage.
NOTE: Purchase price of contract plans varies. See dealer for further details. 2.
ÒG OLD Ó PLANS
Each plan provides full mechanical repair protection to non-powertrain (Gold) components. Plans 705, 706 and 708 also provide fullmechanical protection against powertrain component repairs beyondyour vehicleÕs 7-year or 115,000-kilometre powertrain warrantycoverage. Contracts are available with or without a deductible. Major components covered are: ¥ steering ¥ air conditioning ¥ engine cooling and fuel ¥ frontsuspension ¥ rear suspension ¥ electrical ¥ hydraulic brakecomponents ¥ anti-lock brakes Maximum terms available on new vehicles registered in Canada only.
P LAN CODE TERM DEDUCTIBLE
Plan 701 4 years or 80,000 km* $0
Plan 7023 years or 80,000 km* $0
Plan 7034 years or 100,000 km* $0
Plan 7045 years or 100,000 km* $0
Plan 7055 years or 120,000 km* $0
OPTIONAL DAIMLERCHRYSLER CANADA SERVICE CONTRACTS
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 25

2004 Passenger Car, Minivan & Pacifica
26
ÒG
OLD Ó PLANS (CONT ÕD )
P LAN CODE TERM DEDUCTIBLE
Plan 706 6 years or 140,000 km* $0
Plan 7077 years or 115,000 km* $0
Plan 7087 years or 160,000 km* $0
Plan 7114 years or 80,000 km* $100
Plan 7123 years or 80,000 km* $100
Plan 7134 years or 100,000 km* $100
Plan 7145 years or 100,000 km* $100
Plan 7155 years or 120,000 km* $100
Plan 7166 years or 140,000 km* $100
Plan 7177 years or 115,000 km* $100
Plan 7187 years or 160,000 km* $100
*Whichever comes first. Measured from the warranty start date (the original in-service date of the vehicle) and from zero metrage.
NOTE: Purchase price of contract plans varies. See dealer for further details. 3.
ÒG OLD PLUS Ó PLANS
The most complete protection available for your new vehicle is one of three ÒGold PlusÓ Service Contracts which combines the benefitsof ÒGoldÓ
¥ Mechanical repair coverage for non-powertrain components
plus the most important vehicle maintenance function ¥ Engine oil and oil filter changes (every three months, or 5,000 kilometres)
plus ¥ Tire rotation every other service(every six months or 10,000 kilometres)
plus ¥ ÒPeace-of-MindÓ motoring with Tire Road HazardProtection which provides full, or pro rata, replacementof the original four tires, or their repair
plus ¥ Rental car allowance for same-day warranty repairs Ð yourvehicle need not be kept overnight before eligibility for the
rental allowance is met.
OPTIONAL DAIMLERCHRYSLER CANADA SERVICE CONTRACTS
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 26

MAINTENANCE Scheduled maintenance must be completed to provide the best vehicle
performance and reliability . The limited warranties in the warranty booklet DO NOT COVER repairs
required due to improper maintenance. W e strongly suggest you keep track of scheduled maintenance and
keep receipts or other documents. Use only recommended Mopar lubricants and genuine Mopar parts.
NOTE: WHERE TIME (MONTHS) AND METRAGE ARE INDICA TED, FOLLOW THE INTERVAL
THA T OCCURS FIRST .
AT EACH STOP FOR FUEL
¥ Check the engine oil level about 5 minutes after
a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground willimprove the accuracy of the oil level reading.
Add oil only when the level is at or below the
ADD or MIN mark.
¥ Check the windshield washer solvent and add if required.
ONCE A MONTH
¥ Check the tire pressure and look for unusualwear or damage.
¥ Inspect the battery and clean and tighten theterminals as required.
¥ Check the fluid levels of coolant reservoir , brake
master cylinder , power steering and transmission
and add as needed.
¥ Check all the lights and all other electrical itemsfor correct operation.
¥ Check rubber seals on each side of the radiatorfor proper fit (all except Pacifica ).
¥ Check and clean wiper blades. Replace if required.
VISUAL INSPECTIONS Ð
INSPECT FOR SIGNS OF COMPONENT
DETERIORA TION AND PHYSICAL DAMAGE.
There are two maintenance schedules contained in your OwnerÕ s Manual. Schedule
ÒBÓ best describes operating conditions inCanada and is the recommended serviceschedule. For your convenience, the scheduledmaintenance intervals outlined in this bookletfollow the Severe Service Schedule as describedin your OwnerÕ s Manual. Schedule ÒBÓ is for
vehicles that are operated under one or more ofthe following conditions: day or night tempera -
tures are below 0 ¡C; stop and go driving;
extensive engine idling; driving in dustyconditions; short trips of less than 16.2 km; more than 50% of your driving is at sustainedhigh speeds during hot weather
, above 32¡C;
trailer towing; taxi, police, or delivery service(commercial service); off-road or desert driving;if equipped for and operating with E-85(ethanol) fuel. Schedule ÒAÓ is for vehicles thatare not operated under any of the conditionslisted under Schedule ÒB.Ó
The performance of all scheduled servicework is required to maintain your vehicle ingood operating condition. DaimlerChryslerCanada Inc. reserves the right to denywarranty coverage if the vehicle has not beenproperly maintained. While we do not insistthat such work be performed by factory-authorized dealers, we strongly recommendthat an authorized Chrysler , Jeep
¨or Dodge
dealer perform this work.
INTRODUCTION
2004 Car_Minivan Maint Cover 7/11/03 2:03 PM Page 4

5,000 km
Maint enance Service
Sc hedule ÒBÓ
Odometer Reading
Date
Dealer copy.
Remove and attach to Repair Order 26-92-01-01 3N.
Maint enance Service Sc hedule ÒBÓ
5,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
lInspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M, Pacifica and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 31

Maintenance Service Sc hedule ÒBÓ
5,0 00 km
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde,Intrepid, 300M, Pacifica and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
