2004 CHRYSLER PT CRUISER engine

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
163,0 00 km
Maint
enance Service Sc hedule ÒBÓ
163,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M, Pacifica, and Minivan only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
Dealer copy.
Remove and attach to Repair Order 26-92-34-01 3N.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 97

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible, Concorde,Intrepid, 300M, Pacifica, and Minivan only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
163,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 98

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
168,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-35-01 3N.
Maint enance Service Sc hedule ÒBÓ
168,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, PT Cruiser, SRT-4, and SX 2.0 only).
l Replace the engine air cleaner filter, if required (Pacifica, Minivan, Concorde, Intrepid, and 300M only).
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and 3.3L/3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Check and retention accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel drive power transfer unit fluid.*
l Change the all-wheel-drive overrunning clutch and rear carrier fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses, and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is used for trailer tow, taxi, police
or other types of commercial service.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 99

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible, PT Cruiser, SRT-4, and SX 2.0 only).
l Replace the engine air cleaner filter, if required (Pacifica, Minivan,Concorde, Intrepid, and 300M only).
l Inspect and replace, if required, the make-up air filter located insidethe air cleaner (PT Cruiser and SX 2.0 only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica and3.3L/3.8L Minivan only).
l Adjust the drive belt tension (Concorde, Intrepid, and 300M only).
l Check and retention accessory drive belts (2.7L Sebring, SebringConvertible only).
l Check and retention power steering pump belt (2.4L Minivan only).
l Check the generator belt, replace if necessary (2.4L Minivan only).
l Change the all-wheel drive power transfer unit fluid.*
l Change the all-wheel-drive overrunning clutch and rear carrier fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
*All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if thevehicle is used for trailer tow, taxi, police or other types of commercial service.
Maint enance Service Sc hedule ÒBÓ
168,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 100

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
173,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-36-01 3N.
Maint enance Service Sc hedule ÒBÓ
1 73,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M, Pacifica, and Minivan only).
l Replace the air conditioning filter (Pacifica and Minivan, if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (all models).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 101

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible, Concorde,Intrepid, 300M, Pacifica, and Minivan only).
l Replace the air conditioning filter (Pacifica and Minivan,if equipped).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (all models).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plugcondition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
1 73,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 102

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
178,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-37-01 3N.
Maint enance Service Sc hedule ÒBÓ
1 78,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible, Concorde, Intrepid, 300M, Pacifica, and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 103

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate, as required, all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible, Concorde,Intrepid, 300M, Pacifica, and Minivan only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition (if equipped).
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
1 78,0 00 km
2004 Car_Minivan Maint Book 7/24/03 12:42 PM Page 104
