2004 CHRYSLER CONCORDE keyless

feature selected. Pressing the STEP button when in this
display will select “Yes” or “No.”
Headlamp Delay
When this feature is selected the driver can choose, when
exiting the vehicle, to have the headlamps remain on for
30, 60, or 90 seconds, or not remain on. Pressing the STEP
button when in this display will select 30, 60, 90, or OFF.
Headlamp On With Wipers (Available with Auto
Headlights Only)
When this feature is selected and the headlight switch
has at least once been moved to the AUTO position, the
headlights will turn on when the wipers are turned on.
The headlights will also turn off when the wipers are
turned off if they were turned on in this way. Pressing the
STEP button when in this display will select “Yes” or
“No.”
NOTE:Turning the headlights on during the daytime
causes the instrument panel lights to dim. To increase the
brightness, refer to “Lights” in this section.
Service Interval
When this feature is selected a service interval between
2,000 (3 200 km) and 6,000 miles (9 600 km) in 500 mile
(800 km) increments may be selected. Pressing the STEP
button when in this display will select distances between
2,000 (3 200 km) and 6,000 miles (9 600 km) in 500 mile
(800 km) increments.
Reset Service Distance (Displays Only if Service
Interval was Changed)
When this feature is selected the current accumulated
service distance can be reset to the newly selected service
interval. Pressing the STEP button when in this display
will select “Yes” or “No.”
Easy Exit Seat
When this feature is selected the driver’s seat moves
rearward two inches (55 mm) or to the farthest rearward
position if this distance is less than two inches (55 mm)
when the key is removed from the ignition switch so that
the driver can more easily exit the vehicle. The seat will
return to the memorized seat location (if REMOTE LINK
TO MEMORY is set to YES) when the remote keyless
entry transmitter is used to unlock the door. Pressing the
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91
3

STEP button when in this display will select “Yes” or
“No.”
Tilt Mirrors Down
When this feature is selected, and the vehicle is placed in
reverse, the driver’s exterior mirror will tilt downward to
improve visibility of rear wheel area. Once reverse is
disengaged, the driver’s exterior mirror will return to it’s
original position. Pressing the STEP button when inthis
display will select “YES” or “NO”.
Train Remote
NOTE:
As a safety feature, successful training of at least
one transmitter will erase all previously trained transmit-
ters.
When this feature is selected the driver can choose to
train up to four remote keyless entry transmitters. Press-
ing the STEP button when in this display will select“YES” or “NO”. When “YES” is selected and the MENU
button is pressed; the EVIC will display “PRESS RE-
MOTE LOCK & UNLOCK THEN PRESS UNLOCK”,
followed by a chime to indicate the training sequence can
commence. You have approximately 30 seconds to train
up to four transmitters; after each transmitter is trained a
chime will sound indicating that the training was suc-
cessful. If remote link to memory is “YES,” the first
transmitter trained will be associated with memory set-
ting 1 and the second transmitter trained will be associ-
ated with memory setting 2. Additional transmitters will
not be associated with a memory setting. When you have
finished training the transmitters, press the MENU but-
ton again and the EVIC will display “TRAIN DONE, x
TRAINED”. (Where x = 1,2,3, or 4) If no transmitters are
trained within approximately 30 seconds the EVIC will
display “TRAIN TIMEOUT”.
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

About Your Brakes...................... 157
ABS (Anti-Lock Brake) System............. 112
Accident Damage....................... 221
Adding Engine Coolant (Antifreeze)......... 211
Adding Fuel.......................... 170
Air Cleaner, Engine..................... 202
Air Conditioning....................137,140
Air Conditioning Controls.............137,140
Air Conditioning, Operating Tips........... 146
Air Conditioning Refrigerant.............. 205
Air Conditioning System................. 204
Air Pressure, Tires...................159,161
Airbag................................ 33
Airbag Deployment....................37,38
Airbag Light....................37,41,49,111
Airbag Maintenance...................... 40
Alarm System.......................... 23
Alignment and Balance.................. 167
Antifreeze Disposal..................... 211
Antifreeze (Engine Coolant)............... 211
Anti-Lock Brake System.................. 157
Anti-Lock Warning Light................. 112
Anti-Theft Security Alarm................. 23Appearance Care....................... 220
Auto Down Power Windows............... 25
Automatic Dimming Mirror................ 56
Automatic Door Locks.................... 16
Automatic Headlights..................67,70
Automatic Off, Interior Lights.............. 65
Automatic Temperature Control............ 140
Automatic Transaxle..................153,217
Fluid and Filter Changes................ 219
Fluid Level Check..................... 218
Reset Mode......................... 154
Selection Of Lubricant................. 217
Shifting............................ 154
Special Additives..................... 219
Backfire, Engine........................ 202
Ball Joints............................ 207
Battery............................182,203
Emergency Starting.................... 182
Gas Caution......................182,203
Jump Starting........................ 182
Keyless Transmitter Replacement.......... 22
Location.........................183,203
262 INDEX

Homelink Transmitter..................76,81
Hood Release.......................... 64
Hook, Coat............................ 55
Hoses............................214,217
Ignition
Key ................................ 12
Lock............................... 13
Illuminated Entry....................... 14
Infant Restraint......................... 42
Instrument Cluster................107,108,109
Instrument Panel and Controls..........105,106
Instrument Panel Cover.................. 223
Instrument Panel Lens Cleaning............ 223
Interior Fuses.......................... 225
Interior Lights.......................65,226
Intermittent Wipers...................... 70
Introduction............................ 4
Jack Operation......................... 178
Jump Starting......................... 182
Key, Sentry............................. 9Key-In Reminder........................ 12
Keyless Entry System..................... 18
Keys.................................. 9
Knee Bolster........................... 33
Lap/Shoulder Belts...................... 28
LATCH
(Lower Anchors and Tether for CHildren)..... 45
Leaks, Fluid............................ 50
Light Bulbs........................226,227
Lights
Airbag.........................37,49,111
Anti-Lock........................... 112
Automatic Off......................65,66
Back-Up............................ 231
Battery Saver.......................65,66
Brake Warning.................... 112,156
Center Mounted Stop.................. 231
Check Engine........................ 111
Courtesy/Reading..................... 66
Cruise...........................73,110
Daytime Running...................... 68
Dimmer Switch, Headlight............... 69
INDEX 267
10

Seats............................... 59
Steering............................ 158
Steering, Checking.................... 205
Sunroof............................. 87
TrunkLid ............................ 25
Windows............................ 25
Pregnant Women and Seat Belts............. 32
Programmable Electronic Features.....77,80,82,86
Programming Transmitters........20,77,80,82,86
Radial Ply Tires........................ 162
Radiator Cap.......................... 212
Radio.......................... 114,121,126
Radio Operation.....................134,136
Radio Remote Controls.................. 133
Rear Window Defroster.................. 139
Reclining Front Seats..................... 59
Recommended Fluids, Lubricants and Genuine
Parts............................... 233
Reformulated Gasoline................... 168
Refrigerant............................ 205
Reminder, Lights On..................... 67Remote Keyless Entry.................... 18
Remote Trunk Release.................... 25
Replacement Bulbs...................... 226
Replacement Tires...................... 165
Reporting Safety Defects................. 255
Restraint, Head......................... 63
Restraints, Occupant..................... 27
Rotation, Tires......................... 166
Safety Checks Inside Vehicle............... 49
Safety Checks Outside Vehicle.............. 50
Safety, Exhaust Gas...................... 49
Safety Tips............................. 49
Schedule, Maintenance................... 236
Scheduled Maintenance.................. 194
Seat Belt Maintenance................... 223
Seat Belts............................27,28
Adjustable Upper Shoulder Anchorage...... 32
Child Restraint........................ 46
Extender............................ 32
Inspection........................... 49
Reminder........................... 110
270 INDEX
