Notice:Ignoring these steps could result in costly
damage to your vehicle that would not be covered
by your warranty.
Trying to start your vehicle by pushing or pulling it
will not work, and it could damage your vehicle.
1. Check the other vehicle. It must have a 12-volt
battery with a negative ground system.
Notice:If the other vehicle’s system is not a 12-volt
system with a negative ground, both vehicles can
be damaged. Only use vehicles with 12-volt systems
with negative grounds to jump start your vehicle.
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren’t touching
each other. If they are, it could cause a ground
connection you don’t want. You wouldn’t be able to
start your vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set
the parking brake rmly on both vehicles involved in
the jump start procedure. Put an automatic
transaxle in PARK (P) or a manual transaxle in
NEUTRAL before setting the parking brake.Notice:If you leave your radio or other accessories
on during the jump starting procedure, they could
be damaged. The repairs would not be covered
by your warranty. Always turn off your radio and
other accessories when jump starting your vehicle.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or in the accessory power outlet. Turn off
the radio and all lamps that aren’t needed. This will
avoid sparks and help save both batteries. And it
could save your radio!
4. Open the hoods and locate the batteries. Find the
positive (+) and negative (−) terminal locations on
each vehicle. SeeEngine Compartment Overview
on page 5-12for more information on location.
{CAUTION:
An electric fan can start up even when the
engine is not running and can injure you. Keep
hands, clothing and tools away from any
underhood electric fan.
5-37

{CAUTION:
Using a match near a battery can cause battery
gas to explode. People have been hurt doing
this, and some have been blinded. Use a
ashlight if you need more light.
Be sure the battery has enough water. You do
not need to add water to the ACDelco
®battery
installed in your new vehicle. But if a battery
has ller caps, be sure the right amount of
uid is there. If it is low, add water to take care
of that rst. If you do not, explosive gas could
be present.
Battery uid contains acid that can burn you.
Do not get it on you. If you accidentally get it
in your eyes or on your skin, ush the place
with water and get medical help immediately.
{CAUTION:
Fans or other moving engine parts can injure
you badly. Keep your hands away from moving
parts once the engine is running.
5. Check that the jumper cables don’t have loose or
missing insulation. If they do, you could get a
shock. The vehicles could be damaged, too.
Before you connect the cables, here are some
basic things you should know. Positive (+) will go to
positive (+) or to a remote positive (+) terminal if
the vehicle has one. Negative (−) will go to a heavy,
unpainted metal engine part or to a remote
negative (−) terminal if the vehicle has one.
Don’t connect positive (+) to negative (−) or you’ll
get a short that would damage the battery and
maybe other parts, too. And don’t connect
the negative (−) cable to the negative (−) terminal
on the dead battery because this can cause sparks.
5-38

Part B: Owner Checks and Services
Listed in this part are owner checks and services
which should be performed at the intervals specied to
help ensure the safety, dependability and emission
control performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any uids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown
in Part D.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel ll.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. SeeEngine Oil on page 5-13for further
details.
Engine Coolant Level Check
Check the engine coolant level and add DEX-COOL®
coolant mixture if necessary. SeeEngine Coolant
on page 5-20for further details.
Windshield Washer Fluid Level Check
Check the windshield washer uid level in the windshield
washer tank and add the proper uid if necessary. See
Windshield Washer Fluid on page 5-31for further details.
At Least Once a Month
Tire Ination Check
Visually inspect your tires and make sure tires are
inated to the correct pressures. Do not forget to check
your spare tire. SeeTires on page 5-46for further details.
Cassette Tape Player Service
Clean cassette tape player. Cleaning should be done
every 50 hours of tape play. SeeAudio System(s)
on page 3-35for further details.
At Least Twice a Year
Restraint System Check
Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages
are working properly. Look for any other loose or
damaged safety belt system parts. If you see anything
that might keep a safety belt system from doing its
job, have it repaired. Have any torn or frayed safety belts
replaced.
6-18

Care of
Safety Belts................................................5-75
Your CD Player...........................................3-68
Your CDs ...................................................3-68
Cassette Tape Player Service...........................6-18
CD Messages................................3-42, 3-51, 3-66
Center Console Storage Area...........................2-34
Chains, Tires..................................................5-60
Charging System Light....................................3-24
Check
Engine Light...............................................3-29
Gages Warning Light...................................3-33
Check Engine Light.........................................3-29
Checking Coolant............................................5-22
Checking Engine Oil........................................5-13
Checking Things Under the Hood......................5-10
Chemical Paint Spotting...................................5-78
Child Restraints
Child Restraint Systems...............................1-34
Infants and Young Children...........................1-31
Lower Anchorages and Top Tethers for
Children (LATCH System)..........................1-40
Older Children.............................................1-29
Securing a Child Restraint Designed
for the LATCH System..............................1-42
Securing a Child Restraint in a Rear
Seat Position...........................................1-42Child Restraints (cont.)
Securing a Child Restraint in the
Right Front Seat Position..........................1-44
Top Strap...................................................1-38
Top Strap Anchor Location............................1-39
Where to Put the Restraint...........................1-37
Chime Level Adjustment..................................3-68
Cigarette Lighter.............................................3-16
Cleaning
Inside of Your Vehicle..................................5-73
Outside of Your Vehicle................................5-75
Underbody Maintenance...............................5-78
Weatherstrips..............................................5-75
Cleaning Aluminum or Chrome-Plated Wheels.....5-77
Cleaning Exterior Lamps/Lenses.......................5-76
Cleaning Fabric/Carpet....................................5-73
Cleaning Glass Surfaces..................................5-75
Cleaning Interior Plastic Components.................5-74
Cleaning the Top of the Instrument Panel...........5-74
Cleaning Tires................................................5-77
Cleaning Vinyl................................................5-74
Cleaning Windshield and Wiper Blades..............5-76
Climate Control System...................................3-16
Outlet Adjustment........................................3-19
Clutch, Hydraulic.............................................5-19
Compact Spare Tire........................................5-72
Content Theft-Deferrent....................................2-14
3

Driving (cont.)
Freeway.....................................................4-20
Hill and Mountain Roads..............................4-22
In Rain and on Wet Roads...........................4-16
Winter........................................................4-24
Driving on Grades...........................................4-42
Driving on Snow or Ice....................................4-25
Driving Through Deep Standing Water...............4-18
Driving Through Flowing Water.........................4-18
Driving with a Trailer.......................................4-40
E
Easy Entry Seat............................................... 1-6
Electrical System
Add-On Equipment......................................5-80
Fuses and Circuit Breakers...........................5-81
Headlamp Wiring.........................................5-80
Power Windows and Other Power Options......5-81
Windshield Wiper Fuses...............................5-81
Emergency Trunk Release Handle.....................2-11
Emissions Inspection and Maintenance
Programs...................................................3-31
Engine
Air Cleaner/Filter.........................................5-17
Battery.......................................................5-36Engine (cont.)
Check and Service Engine Soon Light............3-29
Coolant......................................................5-20
Coolant Heater............................................2-19
Coolant Temperature Gage...........................3-28
Cooling System Inspection............................6-23
Drive Belt Routing.......................................5-87
Engine Compartment Overview......................5-12
Exhaust.....................................................2-28
Oil .............................................................5-13
Overheating................................................5-23
Starting......................................................2-18
Engine Compartment Fuse Block......................5-84
Engine Coolant Level Check.............................6-18
Engine Cooling When Trailer Towing..................4-43
Engine Oil Additives........................................5-16
Engine Oil Level Check...................................6-18
Enhanced Traction System (ETS)........................ 4-8
Active Light................................................3-28
Warning Light.............................................3-27
Entry Lighting.................................................3-14
Event Data Recorders (EDR)............................. 7-9
Express-Down Window....................................2-13
Extender, Safety Belt.......................................1-28
Exterior Lamps...............................................3-11
5

F
Filter
Engine Air Cleaner......................................5-17
Finding a Program Type (PTY) Station
(RDS and XM™).................................3-46, 3-55
Finding a Station....................3-37, 3-39, 3-44, 3-54
Finish Care....................................................5-76
Finish Damage...............................................5-77
Five-Speed....................................................2-23
Fixed Mast Antenna........................................3-68
Flash-to-Pass................................................... 3-7
Flat Tire........................................................5-61
Flat Tire, Changing.........................................5-62
Fluid
Automatic Transaxle.....................................5-19
Manual Transaxle........................................5-19
Power Steering...........................................5-30
Windshield Washer......................................5-31
FM Stereo.....................................................3-67
Fog Lamps....................................................3-13
Folding the Seatback........................................ 1-7
Following Distance..........................................4-41
Footnotes................................................6-7, 6-13
Forward Gears...............................................2-22
Front Reading Lamps......................................3-14
Fuel............................................................... 5-4
Additives...................................................... 5-6Fuel (cont.)
California Fuel.............................................. 5-5
Filling a Portable Fuel Container..................... 5-9
Filling Your Tank........................................... 5-7
Fuels in Foreign Countries.............................. 5-6
Gage.........................................................3-34
Gasoline Octane........................................... 5-5
Gasoline Specications.................................. 5-5
System Inspection.......................................6-23
Fuses
Fuses and Circuit Breakers...........................5-81
Windshield Wiper.........................................5-81
G
Gage
Check Gages Warning Light..........................3-33
Engine Coolant Temperature.........................3-28
Fuel..........................................................3-34
Speedometer..............................................3-22
Tachometer.................................................3-22
Gasoline
Octane........................................................ 5-5
Specications............................................... 5-5
GM Mobility Program for Persons with
Disabilities.................................................... 7-5
6

H
Hazard Warning Flashers................................... 3-4
Head Restraints............................................... 1-5
Headlamp High/Low-Beam Changer.................... 3-7
Headlamp Wiring............................................5-80
Headlamps....................................................5-41
Bulb Replacement.......................................5-41
Front Turn Signal and Parking Lamps.............5-43
Halogen Bulbs............................................5-41
Highway Hypnosis...........................................4-22
Hill and Mountain Roads..................................4-22
Hitches..........................................................4-40
Hood
Checking Things Under................................5-10
Release.....................................................5-10
Horn............................................................... 3-5
How the System Alarm is Activated...................2-14
How to Add Coolant to the Coolant
Surge Tank.................................................5-27
How to Check................................................5-54
How to Check and Add Fluid............................5-20
How to Check Power Steering Fluid..................5-31
How to Detect a Tamper Condition....................2-15
How to Inspect the Engine Air Cleaner/Filter.......5-18
How to Turn Off the System Alarm....................2-15
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-13Hydraulic Clutch.............................................5-19
Hydraulic Clutch System Check........................6-19
Hydroplaning..................................................4-18
I
If No Steam Is Coming From Your Engine..........5-24
If Steam Is Coming From Your Engine...............5-23
If the Light Is Flashing.....................................3-30
If the Light Is on Steady..................................3-31
If You Are Caught in a Blizzard.........................4-26
If You Are Stuck in Sand, Mud, Ice or Snow.......4-28
If You Do Decide To Pull A Trailer.....................4-38
Ignition Positions.............................................2-16
Ignition Transaxle Lock Check..........................6-21
Infants and Young Children, Restraints...............1-31
Ination - Tire Pressure...................................5-53
Inspection
Brake System.............................................6-24
Caliper/Knuckle Maintenance.........................6-24
Engine Cooling System................................6-23
Exhaust System..........................................6-23
Fuel System...............................................6-23
Part C - Periodic Maintenance.......................6-23
Steering, Suspension and Front Drive Axle
Boot and Seal.........................................6-23
Throttle System...........................................6-23
7

Instrument Panel
Cluster.......................................................3-21
Overview..................................................... 3-2
Instrument Panel Brightness.............................3-14
Instrument Panel Fuse Block............................5-82
Interior Lamps................................................3-14
J
Jump Starting.................................................5-36
K
Key Lock Cylinders Service..............................6-19
Key Release Button (Manual Transaxle).............2-18
Keyless Entry System....................................... 2-3
Keys............................................................... 2-2
L
Lamps
Exterior......................................................3-11
Interior.......................................................3-14
Lamps On Reminder.......................................3-12
Lap-Shoulder Belt...................................1-14, 1-23LATCH System
Child Restraints...........................................1-40
Securing a Child Restraint Designed for the
LATCH System........................................1-42
Latches, Seatback............................................ 1-6
Leaving Your Vehicle.......................................2-10
Leaving Your Vehicle With the Engine
Running.....................................................2-26
Light
Air Bag Readiness.......................................3-23
Anti-Lock Brake System Warning...................3-26
Brake System Warning.................................3-25
Charging System.........................................3-24
Check Gages Warning.................................3-33
Enhanced Traction System (ETS)
Active Light.............................................3-28
Enhanced Traction System (ETS) Warning
Light......................................................3-27
Low Coolant Warning...................................3-29
Malfunction Indicator....................................3-29
Oil Pressure...............................................3-32
Passlock®Warning.......................................3-33
Safety Belt Reminder...................................3-23
Service Vehicle Soon...................................3-34
Up-Shift.....................................................3-25
Loading Your Vehicle.......................................4-31
Lockout Protection..........................................2-10
8
