2004 BMW MOTORRAD K 1200 S ESP

Maintenance688
Draining off engine oil • Remove the seat (
b 40)
.
• Press the retainer of clear
hose 2 on the left and right
and pull upwards out of the
oil tank.
• Pull the clear hose down-
wards out of the frame and
drain off the oil into a suitable
container.
• Insert the clear hose in the
oil tank and lock into place.
• Check the oil level.
• Repeat the draining and
checking procedure until the
engine oil level is located
between the MIN and
MAX marks.
• Store or dispose of excess
engine oil in an environmen-
tally-responsible manner.
Coolant Checking the coolant
levelCheck the coolant level at
regular intervals.
1Display for coolant level
• Read off the coolant level
from the coolant display1.
2Maximum coolant level
3Minimum coolant level
The coolant level must be
located between the MIN and
MAX marks.
If the coolant is below the
MIN mark:
• Top up the coolant.

697Maintenance
BMW Motorrad provides
an adapter for removing
the quick-release axle. This
adapter can be combined with
any commercially available
open-end or ring spanner with
width across flats 22. The
adapter with BMW special tool
number 36 3 690 can be ob-
tained from your authorised
BMW motorcycle dealer.c
• Place the front wheel in the
front wheel guide on the
ground.• Roll out the front wheel
forwards.
Installing the front wheel
An overview of the types
of screw used and the
corresponding tightening
torques can be found on
(
b 124).c
Screw connections tight-
ened to the incorrect torque
can come loose or damage
the screw connection itself.
Make sure that you have the
tightening torques checked by
a specialist workshop, prefer-
ably by an authorised
BMW motorcycle dealerc
During the following
work, parts of the front
brake, in particular of the
BMW Integral ABS, can be damaged.
Ensure that no parts of the
brake system are damaged, in
particular the ABS sensor with
cable and the ABS sensor
ring.c
The front wheel must be
fitted in the direction of
rotation.
Observe the direction of rota-
tion arrows on the tyres or on
the rim.c
• Roll the front wheel into the
front wheel guide.

Maintenance6100
• Remove clamp3 on the
silencer.
Do not remove the
sealing grease from the
clamp.c• Remove bolt4 of the end
silencer bracket on the
pillion footrest.
• Turn the end silencer
outwards.
• Engage first gear.
• Remove mounting bolts5
from the rear wheel, holding
the wheel as you do so.
• If the BMW Motorrad rear
wheel stand is used: remove
the retaining disc.• Place the rear wheel on the
ground.
• Roll the rear wheel out
towards the rear.
• If the BMW Motorrad rear
wheel stand is used: attach
the retaining disc again.
Installing the rear wheel
An overview of the types
of screw used and the
corresponding tightening
torques can be found on
(
b 124).c

Care7118
Cleaning and care Regular cleaning, using the
correct methods, is an impor-
tant factor in maintaining the
value of your motorcycle.
It also ensures that safety-
relevant parts remain in full
working order.Care productsWe recommend that you use
the cleaning and care prod-
ucts you can obtain from your
authorised BMW motorcycle
dealer. The materials in BMW
Care Products have been
tested in laboratories and in
practice; they provide opti-
mised care and protection for
the materials used in your
vehicle. The use of unsuitable
cleaning and care prod-
ucts can damage vehicle
components.
For cleaning, do not use any
solvents such as nitro-thin-
ners, cold cleaning agents,
fuel or similar, and do not use
cleaning agents that contain
alcohol.c
Washing the motorcycleWe recommend that you use
BMW insect remover to soften
and wash off insects and resil-
ient dirt on painted parts prior
to washing the motorcycle. To
prevent stains, do not wash
the motorcycle immediately
after it has been exposed to
strong sunlight and do not
wash it in the sun.Make sure that the motorcycle
is washed frequently, espe-
cially during the winter
months.
To remove road salt, clean the
motorcycle with cold water
immediately after every trip.
Warm water reinforces
the effects of the salt.
Only use cold water to remove
road salt.c
Wet brake discs reduce
the braking effect.
After washing the motorcycle,
dry the brakes by braking.c
The high water pressure
of steam jet cleaners can
damage gaskets, the hydraulic
brake system and the electri-
cal equipment.

7119
Care
Do not use steam jet cleaners
or high-pressure cleaners.cPlasticsClean plastic parts with water
and BMW plastic care
emulsion. This includes in
particular:
– Windscreens
– Headlight lenses made of
plastic
– Covering glass of the
instrument cluster
– Black, unpainted parts
If plastic parts are
cleaned using unsuitable
cleaning agents, the surfaces
can be damaged.
Do not use cleaning agents
that contain alcohol, solvents
or abrasives to clean plastic
parts. "Fly sponges" or spong-
es with hard surfaces can also
lead to scratches.cSoften resilient dirt and
insects by applying a wet
cloth.c
WindscreenRemove dirt and insects with a
soft sponge and lots of water.
Fuel and chemical
solvents attack the
windscreen.
Do not use cleaning agents.cChromeEspecially in the case of road
salt, carefully clean chrome
with plenty of water and BMW
vehicle shampoo. Use chrome
polish for additional treatment.RadiatorClean the radiator regularly to
prevent overheating of the
engine due to inadequate cooling. For example, use a
garden hose with low water
pressure.
Cooling fins can be bent
easily.
When cleaning the radiator,
ensure that the fins are not
bent.c
Paint careRegular washing of the motor-
cycle counteracts the long-
term effects of materials that
damage the paint, especially if
your motorcycle is ridden in
areas with high air pollution or
natural sources of dirt, e.g.
tree resins or pollen.
However, remove particularly
aggressive materials immedi-
ately; otherwise changes in
the paint or discolouration can
occur. These include, e.g.,
spilt fuel, oil, grease, brake

E3BMW Motorrad Integral ABS
To achieve the shortest
braking distance, it is neces-
sary to apply the front brake
gradually and with increasing
force. This makes best use of
the dynamic increase in load
on the front wheel. At the
same time, the clutch should
be disengaged.
In emergency braking as it is
often taught, in which the
brake pressure is generated
as quickly as possible and with
all possible force, the dynamic
load distribution cannot follow
the increasing deceleration
and the braking force cannot
be completely transferred to
the road. The ABS has to
intervene to ensure that the
front wheel does not lock up;
this reduces the brake pres-
sure and the braking distance
is extended.What happens if ABS control
fails?
A fault in BMW Motorrad
Integral ABS is indicated by a
corresponding warning dis-
play in the instrument cluster.
If only ABS control fails, the
Integral system and the brake
servo action remain opera-
tional. If these systems also
fail, the residual brake function
is applied. In this case, the
forces to be applied to the
brake levers will be signifi-
cantly higher and the lever
travel required will be longer.
The residual brake function is
a mechanical function and is
always available in the event
of the failure of the BMW
Motorrad Integral ABS,
whatever the battery condi-
tion. It meets all requirements
of legislation around the world on the design of brakes for
motor vehicles and allows the
rider to brake the motorcycle.
The following notes must be
observed for riding with the
residual braking function:
• set the brake lever to
maximum travel
• always brake with both front
and rear brakes
• where it is safe to do so, try
out the brakes so that you
can learn the brakes'
response characteristics
• be aware of the prevailing
road conditions and adapt
your braking force
accordingly
• since this is an emergency-
run function, you should visit
a specialist workshop, or
better still a BMW Motorrad
dealer, as quickly as
possibleInfo_I_ABS_en_xx.fm Seite 3 Dienstag, 19. Juli 2005 2:48 14
