6-37
PERIODIC MAINTENANCE AND MINOR REPAIR
63. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
3. Disconnect the headlight cou-
pler, and then remove the bulb
cover.
1
2
1. Headlight coupler
2. Bulb cover
EAU04128
Replacing a headlight bulbHeadlight bulb, replacingThis scooter is equipped with quartz
bulb headlights. If a headlight bulb
burns out, replace it as follows.
1. Place the scooter on the center-
stand.
2. Remove panel A. (See page
6-11 for panel removal and
installation procedures.)
5SJ-28199-E1 7/11/02 11:03 AM Page 86

6-38
PERIODIC MAINTENANCE AND MINOR REPAIR
6 4. Unhook the headlight bulb hold-
er, and then remove the defec-
tive bulb.EW000119
w
Headlight bulbs get very hot.
Therefore, keep flammable prod-
ucts away from a lit headlight bulb,
and do not touch the bulb until it
has cooled down.
1
1. Headlight bulb holder
EC000105
cC
Do not touch the glass part of the
headlight bulb to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the
bulb, and the bulb life will be
adversely affected. Thoroughly
clean off any dirt and fingerprints
on the headlight bulb using a cloth
moistened with alcohol or thinner.
6. Install the headlight bulb cover,
and then connect the coupler.
a
a. Do not touch the glass part of the bulb.
5. Place a new headlight bulb into
position, and then secure it with
the bulb holder.
5SJ-28199-E1 7/11/02 11:03 AM Page 87

6-39
PERIODIC MAINTENANCE AND MINOR REPAIR
67. Install the panel.
8. Have a Yamaha dealer adjust
the headlight beam if necessary.
3. Remove the socket (together
with the turn signal light bulb) by
turning it counterclockwise.
4. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
5. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
6. Install the socket (together with
the bulb) by turning it clockwise.
7. Install the panel.
1
1. Socket
EAU03111
Replacing a front turn signal
light bulb
Turn signal light bulb (front), replacing1. Place the scooter on the center-
stand.
2. Remove panel A. (See page
6-11 for panel removal and
installation procedures.)
5SJ-28199-E1 7/11/02 11:03 AM Page 88

6-40
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03618
Replacing a rear turn signal
light bulb
Turn signal light bulb (rear), replacing1. Place the scooter on the center-
stand.
2. Remove cowling C. (See page
6-10 for cowling removal and
installation procedures.)
EAU03619
Replacing a tail/brake light
bulb
Tail/brake light bulb, replacing1. Place the scooter on the center-
stand.
2. Remove cowling C. (See page
6-10 for cowling removal and
installation procedures.)
3. Remove the socket (together
with the bulb) by turning it coun-
terclockwise.
4. Remove the defective bulb by
pulling it out.
5. Insert a new bulb into the socket.
6. Install the socket (together with
the bulb) by turning it clockwise.
7. Install the cowling.
1
1. Socket
5SJ-28199-E1 7/11/02 11:03 AM Page 89

6-41
PERIODIC MAINTENANCE AND MINOR REPAIR
63. Remove the socket (together
with the bulb) by turning it coun-
terclockwise.
4. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
5. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
6. Install the socket (together with
the bulb) by turning it clockwise.
7. Install the cowling.
1
1. Socket
3. Remove the license plate light
lens by removing the screws.
12
1. License plate light lens
2. Screw (×2)
EAU03621
Replacing the license plate
light bulb
License plate light bulb, replacing1. Place the scooter on the center-
stand.
2. Remove cowling C. (See page
6-10 for cowling removal and
installation procedures.)
5SJ-28199-E1 7/11/02 11:03 AM Page 90

6-42
PERIODIC MAINTENANCE AND MINOR REPAIR
6 4. Remove the defective bulb by
pulling it out.
5. Insert a new bulb into the socket.
6. Install the lens by installing the
screws.
EC000108
cC
Do not overtighten the screws,
otherwise the lens may break.
7. Install the cowling.
1
1. Bulb
EAU03087
