2003 VOLVO XC70 height adjustment

2003 VOLVO XC70
E - Rear fog light
The rear fog light is considerably brighter than the normal tail lights \
and should be used only when
conditions such as fog, rain, snow, smoke or dust reduce visibility for \
other vehicles to less than 500 ft
(150 meters).
An LED in the switch indicates when the rear fog light is on.
The rear fog light will only function in combination with the high/low b\
eam head-lights.
By design, there is one rear fog light only, located in the driver's sid\
e tail light cluster.
Rear fog light in the instrument panel
This light indicates that the rear fog light is on.

pg. 35 Steering wheel adjustment, Ignition switch/steering wheel lock

Steering wheel adjustment
Both the height and the reach of the steering wheel can be adjusted to a\
comfortable position for the
driver. Pull down the lever on the left of the steering column. Adjust t\
he steering wheel to a suitable
position and press the lever back into place to lock the steering wheel \
in the new position. Check that the
steering wheel is locked in the new position.
WARNING!
Never adjust the steering wheel while
driving.
file:///K|/ownersdocs/2003/2003_XC70/03xc70_02b.htm (4 of 18)12/30/200\
6 4:17:54 PM

2003 VOLVO XC70
Folding front seat backrest
The passenger seat backrest can be folded down to the horizontal positio\
n for carrying long loads. To
fold down the backrest:
l Move the seat as far rearward as possible
l Adjust the backrest tilt to the most upright position
l Lift the catches on the lower rear side of the backrest
l Without releasing the catches, push the backrest forward
l Move the seat as far forward as possible
WARNING!
Cover sharp edges on the load to help prevent injury to occupants. Secur\
e the load to help prevent
shifting during sudden stops.


pg. 58 Front seats
Manual height adjustment - front seat
The front edges of the driver and passenger seat cushions can be adjuste\
d to seven different settings and
the rear edges to nine different settings.
Lever (A) - adjusting the front edge of the seat.
Lever (B) - adjusting the rear edge of the seat.
Manual front-rear adjustment
file:///K|/ownersdocs/2003/2003_XC70/03xc70_04a.htm (5 of 11)12/30/200\
6 4:17:56 PM
