’03 Tacoma U (L/O 0209)
1092003 MY TACOMA (OM35800U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights and Wipers
Headlights and turn signals11 0
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 111
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Instrument panel light control 11 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights 11 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Personal lights 11 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Windshield wipers and washer 11 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1 4
’03 Tacoma U (L/O 0209)
11 32003 MY TACOMA (OM35800U)
ILLUMINATED ENTRY SYSTEM
When the switch is in the “DOOR” posi-
tion and any door is opened, the light will
come on. After all the doors are closed,
the light remains on for about 15 seconds
before fading out.
However, in the following cases, the light
goes out immediately:
All the doors are closed when the igni-
tion key is in the “ACC” or “ON” posi-
tion.
All the doors are closed and locked.
(with power door lock system models
only)
Vehicles with the power door lock sys-
tem—
When any door is unlocked with key, the
light will come on and remain on for 15
seconds before fading out.
The personal lights operate separately
with each outer switch.
To turn on the light, push the switch on
your side. To turn the light off, push the
switch once again.
To prevent the battery from being dis-
charged, the light will automatically turn
off after 30 minutes.To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.
Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
The “INT TIME” band lets you adjust the
wiping time interval when the wiper lever
is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it.
Personal lights Windshield wipers and washer
(intermittent type)
’03 Tacoma U (L/O 0209)
11 42003 MY TACOMA (OM35800U)
To squirt washer fluid, pull the lever
toward you and release it.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see “Adding washer fluid” in Section 7 3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.Lever position
Speed setting
Position 1Slow
Position 2Fast
For a single sweep of the windshield,
push the lever up and release it.
To squirt washer fluid, pull the lever
toward you and release it.
For instructions on adding washer fluid,
see “Adding washer fluid” in Section 7 3. In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
Windshield wipers and washer
(mist type)
’03 Tacoma U (L/O 0209)
2982003 MY TACOMA (OM35800U)
18. WIPER 20 A: Windshield wipers and
washer
19. 4WD 20 A: A.D.D. control system,
four wheel drive control system, rear
differential lock system
20. ACC 15 A: Cigarette lighter, clock,
power rear view mirrors, back up
lights, automatic transmission shift lock
system, SRS airbag system, seat belt
pretensioners, car audio system
21. GAUGE 10 A: Day time running light
system, back up lights, cruise control
system, rear differential lock system,
electronically controlled automatic
transmission system, starting system,
charging system, air conditioning sys-
tem
22. IGN 7.5 A: Gauges and meters, SRS
airbag system, seat belt pretensioners,
multiport fuel injection system/sequen-
tial multiport fuel injection system
23. ECU B 7.5 A: SRS warning light, air
conditioning system
24. HORN HAZ 15 A: Emergency flashers,
horns
25. STA 7.5 A: Clutch start cancel system,
starting system 26. STOP 10 A:
Stop lights, high mounted
stoplight, cruise control system, anti
lock brake system, multiport fuel injec-
tion system/sequential multiport fuel in-
jection system
Fuses (type B)
27. POWER 30 A: Power windows, power
seat
28. J/B 50 A: All components in “POWER”,
“HORN HAZ”, “STOP” and “ECU B”
fuses
29. AM2 30 A: Ignition system, multiport
fuel injection system/sequential fuel in-
jection system
30. HEATER 50 A: All components in “A.C”
fuse
31. AM1 40 A: Starting system
32. ABS2 30 A: Anti lock brake system
Fuses (type C)
33. ABS 60 A: Anti lock brake system
34. ALT 120 A: All components in “AM1”,
“HEATER”, “A.C”, “TAIL”, “ALT S” and
“PWR OUTLET” fuses
