1. Instrument cluster
2. Center vents
3. Personal lights or interior light
4. Side vents
5. Rear view mirror remote control levers
6. Glove box
7. Power door lock switches
8. Power window switches
9. Manual transmission gear shift lever orautomatic transmission selector lever
10. Rear console boxes
11. Cup holder
12. Power rear view mirror control switches
13. Front drive control lever
14. Tilt steering lock release lever
15. Hood lock release lever
16. Window lock switch
Instrument panel overview

’03 Tacoma U (L/O 0209)
1092003 MY TACOMA (OM35800U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights and Wipers
Headlights and turn signals11 0
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 111
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Instrument panel light control 11 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights 11 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Personal lights 11 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Windshield wipers and washer 11 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1 4

’03 Tacoma U (L/O 0209)
11 22003 MY TACOMA (OM35800U)
To adjust the brightness of the instru-
ment panel lights, turn the knob.Front light (regular cab models)
Rear light
(xtracab and double cab models)
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
“ON”—Keeps the light on all the time.
“OFF”—Turns the light off.
“DOOR”—Turns the light on when any of
the doors are opened. The light goes off
when all the doors are closed.
Vehicles without the power door lock sys-
tem—
To prevent the battery from being dis-
charged, the light will automatically turn
off if the door is left open for 30 minutes
with the switch at the “DOOR” position.
Vehicles with the power door lock sys-
tem—
To prevent the battery from being dis-
charged, the light will automatically turn
off after 30 minutes in the following cases.
The light is left at the “ON” position.
The door is left open with the switch
at the “DOOR” position.
Instrument panel light control Interior lights

’03 Tacoma U (L/O 0209)
2822003 MY TACOMA (OM35800U)
The inside of the lens of exterior lights
such as headlights may temporarily fog up
when the lens becomes wet in the rain or
in a car wash. This is not a problem
because the fogging is caused by the
temperature difference between the outside
and inside of the lens, just like the
windshield fogged up in the rain. However,
if there is a large drop of water on the
inside of the lens, or if there is water
pooled inside the light, contact your
Toyota dealer.Light bulbsBulb
No.WTy p e
Headlights—60/55A
Parking lights1685B
Front turn signal
lights4157NAK27/8C
Rear turn signal
lights115627D
Stop/tail lights115727/8D
Backup lights92118B
License plate
lights1943.8B
High mounted
stoplight1685B
Interior light Regular cab
Xtracab and
double cab
—
—5
10E
E
Personal lights—5E
Door courtesy
lights—3E
Glove box light—1.4B
A: HB2 halogen bulbs
B: Wedge base bulbs (clear)
C: Wedge base bulbs (amber)
D: Single end bulbs
E: Double end bulbs

’03 Tacoma U (L/O 0209)
2972003 MY TACOMA (OM35800U)
Engine compartment (without daytime run-
ning light system)
Fuses (type A)1. HEAD (RH) 10 A: Righthand headlight
2. HEAD (LH) 10 A: Lefthand headlight
3. DRL 7.5 A: Daytime running light
system
4. HEAD (HI RH) 10 A: Righthand head- light (high beam), high beam indicator
light
5. HEAD (HI LH) 10 A: Lefthand head-
light (high beam)
6. HEAD (LO RH) 10 A: Righthand headlight (low beam)
Engine compartment (with daytime run-
ning light system)
7. HEAD (LO LH) 10 A: Lefthand head-
light (low beam)
8. TAIL 10 A: Tail lights, licence plate
lights
9. A.C 10 A: Air conditioning system
10. ECTS 15 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
11. DOME 15 A: Car audio system, interior
light, clock, personal lights, door cour-
tesy light, day time running light sys-
tem, gauges and meters
Instrument panel
12. OBD 7.5 A: Onboard diagnosis sys-
tem
13. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
14. ALTS 7.5 A: Charging system
15. PWR OUTLET 15 A: Power outlet
16. ECUIG 15 A: Cruise control system,
antilock brake system, automatic
transmission shift lock system, SRS
airbag system
17. TURN 10 A: Turn signal lights, emer-
gency flashers
Fuses
