2003 SUBARU BAJA window

Instruments and controls3-29
–
CONTINUED –
By pressing and releasing the left button, the automatic dimming
function is toggled on or off. When the automatic dimming function is
on, the auto dimming indicator light (green) located to the right of the
button will illuminate. By pressing and releasing the right button, the compass display is
toggled on or off. When the compass is on, an illuminated compass
reading will appear in the lower part of the mirror.
Even with the mirror in anti-glare mode, the mirror surface turns bright
if the transmission is shifted into reverse. This is to ensure good rear-
ward visibility during reversing. n Photosensors
HB6020BA
The mirror has a photosensor attached on both the front and back
sides. If the glare from the headlights of vehicles behind you strikes
the mirror, these sensors detect it and make the reflection surface of
the mirror dimmer to help prevent you from being blinded. For this
reason, use care not to cover the sensors with stickers, or other simi-
lar items. Periodically wipe the sensors clean using a piece of dry soft
cotton cloth or an applicator. nCompass calibration
1. For optimum calibration, switch off all nonessential electrical ac-
cessories (rear window defogger, heater/air conditioning system,
spotlight, etc.) and ensure all doors are shut.
2. Drive to an open, level area away from large metallic objects or

4-2
VentilatorCenter and side ventilators
HB5001BB
Adjustable side defroster grille (driver ’s side – if equipped)
HB5003BB
HB5002BB
Normal position
Side defroster grilleFin
Windshield defrost assist position
The driver ’s side defroster grille is adjustable. The normal position as
shown in the diagram directs warm air to the side glass. When more
rapid defrosting of the windshield is desired, the air flow can be
directed temporarily toward the windshield to assist the windshield
defroster. If this is done, the driver ’s side grille should always be
returned to its normal position so that the warm air flow can then be
used to defrost the driver ’s side window.

4-4
Manual heating and air conditioning systemControl panel
HB5004BC
1. Temperature control dial
2. Fan speed control dial
3. Air flow control dial
4. Air conditioner button
5. Air inlet selection button
6. Rear window defogger button (Refer to “Rear window defogger ” in
chapter 3.) n Temperature control dial
This dial regulates the temperature of air flow from the air outlets over
a range from the blue area (cool) to red area (warm). n Fan speed control dial
The fan operates only when the ignition switch is turned to the “ON”
position. The fan speed control dial is used to select four fan speeds. n Air flow control dial
This dial has the following five positions:
: Air flows through the instrument panel outlets.
: Air flows through the instrument panel outlets and the footoutlets.

4-6
nAir inlet selection button
WARNING
Continued operation in the ON position may fog up the windows.
Switch to the OFF position as soon as the outside dusty condi-tion clears.
HB5008BB
ON position (Recirculation): Interior air is recirculated inside the ve-
hicle. Push the air inlet selection button to the ON position. The indi- cator light will come on.OFF position (Outside Air): Outside air is drawn into the passenger
compartment. Push the air inlet selection button again to the OFF
position. The indicator light will go off.

Climate control4-7
–
CONTINUED –
Heater operation Defrosting or defogging the windshield
HB5011AA
To direct warm air to the windshield and front door windows:
1. Set the air flow control dial to “
”.
2. Turn the temperature control dial all the way to the right.
3. Set the fan speed control dial to the highest speed. NOTE
Warm air also comes out from the right and left air outlets. To
stop warm air flow from these outlets, turn the correspondingthumb-wheel to the “
” position.
Heating and defrosting
HB5012AA

Climate control4-11
–
CONTINUED –
1. Set the air inlet selection button to the “OFF” position.
2. Set the air flow control dial to “
”.
3. Set the air conditioner button to the “ON” position.
4. Set the temperature control dial to the blue area.
5. Set the fan speed control dial at the desired speed. Defrosting or defogging
HB5011BB
To direct warm air to the windshield and front door windows:
1. Set the air outlet control dial to “
”.
2. Set the temperature control dial to the red area.
3. Set the fan speed control dial at the highest speed.

4-12
Operating tips for heater and air conditionerCleaning ventilator grille
HBF046BA
Always keep the front ventilator inlet grille free of snow, leaves, or oth-
er obstructions to ensure efficient heating and defrosting. Since the
condenser is located in front of the radiator, this area should be kept
clean because cooling performance is impaired by any accumulation
of insects and leaves on the condenser. Efficient cooling after parking in direct sunlight
After parking in direct sunlight, drive with the windows open for a few
minutes to allow outside air to circulate into the heated interior. This
results in quicker cooling by the air conditioner. Keep the windowsclosed during the operation of the air conditioner for maximum cool-
ing efficiency. Lubrication oil circulation in the refrigerant circuit
Operate the air conditioner compressor at a low engine speed (at idle
or low driving speeds) a few minutes each month during the off-sea-
son to circulate its oil. Checking air conditioning system before summer season
Check the air conditioner unit for refrigerant leaks, hose conditions,
and proper operation each spring. This check is best performed by
your SUBARU dealer.

Interior and exterior equipments6-3
–
CONTINUED –
Map light
HB2034CC
To turn on the map light, push the switch. To turn it off, push the switch again.
When leaving the vehicle, make sure the light is turned off to avoid bat-
tery discharge.
Sun visors
HB7001BA
To block out glare, swing down the visors. To use the sun visor at a side
window, swing it down and move it sideways.
