2003 SUBARU BAJA key

Keys and doors2-13
–
CONTINUED –
Security system (if equipped)
The security system helps to protect your vehicle and valuables from
theft. The horn sounds and the turn signal lights flash if someone
attempts to break into your vehicle. The starter motor is also interrupted
to prevent starting the vehicle without a key.
The system can be armed and disarmed with the remote transmitter.
The system does not operate when the key is inserted into the ignitionswitch.
System operation
The security system will give the following alarm indications when trig-
gered: The turn signal lights will flash and the horn will sound intermit-
tently. In addition, the starter motor will not operate. The alarm automatically resets after 30 seconds; however, the
alarm will reactivate if the vehicle is tampered with again. The alarmwill continue for six times if any sensor continues to be activated.
The alarm is triggered by: Opening a door.
Application of physical shock to the vehicle (e.g. breaking glass or
forced entry). Note that there are two alarm levels for shock: warning
and alarm. In warning mode, the alarm detects lower level vibrations
and triggers 2 warning chirps on the horn and two flashes on the
lights as a deterrent to would be vandals. In alarm mode, higher lev-
els of shock are detected and the system will go into full alarm. Ignition switch being turned on while in armed state.
NOTE The alarm will not be triggered by opening the switchback
door. The alarm may not be triggered when the window is broken
with a sharp-edged tool. With the valet mode selected, the security system does not op-
erate and the turn signal lights do not flash when the remote

2-14
transmitter is used for locking and unlocking. The security system indicator light in the combination meter
flashes twice per second to show that the valet mode is selected.For details, refer to “Valet mode ” in this section.
Arming the system
n To arm the system using remote transmitter
HB2033BB
Press to Arm the system. Press to Disarm the system.
HB1000EB
1. Close all windows and moonroof.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood and switchback door are locked.
5. Close all doors.
6. Briefly press the “LOCK/ARM” button (for less than two seconds).
All doors will lock, an electronic chirp will sound one time, the turn
signal lights will flash one time and the indicator light starts flashing
slowly (approximately once every two seconds). If any of the doors (except the switchback door) is not fully closed, an
electronic chirp sounds five times, the turn signal lights flash five
times to alert you that the doors are not properly closed. When you
close the door, the system will automatically arm and doors will auto-
matically lock.

Keys and doors2-15
–
CONTINUED –
nTo arm the system using power door locking switches
HB2024CC
1. Close all windows and the moonroof.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood and switchback door are locked.
5. Close the doors but leave only the driver ’s door or the front pas-
senger’ s door open.
6. Push the power door locking switch forward ( “LOCK” side) to set
the door locks.
7. Close the door. An electronic chirp will sound one time, the turn
signal lights will flash one time and the indicator light will start flashing
slowly (approximately once every two seconds) to inform you that the
system has armed. NOTE The system can be armed even if the engine hood, the windows, the switchback door and/or moonroof are open. Always makesure that they are fully closed before arming the system. Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less than two
seconds) on the remote transmitter. The driver ’s door will unlock, an
electronic chirp will sound two times, the turn signal lights will flash
two times and the indicator light will go off.
To unlock all other doors, briefly press the “UNLOCK/DISARM” button

2-16
a second time. nEmergency disarming
If you cannot disarm the system using the transmitter (i.e. the trans-
mitter is lost, broken or the transmitter battery is too weak), you can
disarm the system without using the transmitter.
To disarm the system:
1. Unlock the door with the key and then open the door.
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it from “LOCK” to
“ON” three (3) times within 5 seconds .
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button pressed for more
than two seconds .
The horn will sound and the turn signal lights will flash.
To deactivate it, press the “LOCK/ARM” button or “UNLOCK/DISARM”
button.
Unless a button on the remote is pressed, the alarm will be deacti-
vated after approximately 30 seconds. Valet mode
When you choose the valet mode, the security system does not oper-
ate. In valet mode, the remote transmitter is used only for locking and
unlocking the doors and panic activation.
To enter the valet mode, open the driver ’s door and keep the
“UNLOCK/DISARM” button depressed for more than two seconds .
The security system indicator light will continue to flash 2 times per second indicating that the system is in the valet mode.
To exit valet mode, open the driver ’s door and keep the “UNLOCK/
DISARM” button pressed for more than two seconds. The indicator
will stop flashing. Passive arming
When passive arming mode has been programmed by the dealer,
arming of the system is automatically accomplished without using the

Keys and doors2-17
–
CONTINUED –
remote transmitter. Note that in this mode, DOORS MUST BE MANU-
ALLY LOCKED. nTo enter the passive mode
WARNING
Do not disconnect or tamper with any yellow connector and/or any harness covered with yellow insulation and/or tape.Doing so could result in accidental inflation of the SRS airbag orcould make the SRS airbag system inoperative, which may result
in serious injury.
HB2038BB
HB2036BA
1. Remove the side sill cover on the driver ’s side.
1) Open the driver ’s door.
2) Remove the two clips fastening the front portion of the cover
with a screwdriver.
3) Remove the side sill cover by pulling it up.
2. Connect the white (1 pole) connector.
3. Turn the ignition switch from “LOCK” to “ON”.
4. Install the side sill cover.
To place the system in active arming mode (remote required for ac-
tivation), disconnect the white connector.

2-18
nArming the system CAUTION
In passive mode, the system will automatically activate the alarm
but WILL NOT automatically lock the doors. In order to lock thedoors you must either lock them as indicated in step 4 below orwith the key once they have been closed. Failure to lock thedoors manually will result in a higher security risk.
HB2024DB
HB2031BB
1. Turn the ignition switch to “ON”.
2. Turn the ignition switch from “ON” to “LOCK” and remove the key
from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Before closing the doors, lock all doors with the inside door locklevers.
5. Close the doors. The system will automatically arm after one min-ute.
In the passive mode, the system can also be armed with the remote
transmitter or with the power door locking switches. If the remote
transmitter or power door lock switch is used to lock the vehicle, arm-
ing will take place immediately regardless of whether or not the pas-sive mode has been selected. Disarming the system
To disarm the system, briefly press the “UNLOCK/DISARM” button on

Keys and doors2-19
–
CONTINUED –
the transmitter. Tripped sensor identification
If an electronic chirp sounds four times and the turn signal lights flash
four times when you disarm the system, this indicates that the alarm
was triggered. The number of times the indicator light flashes indi-
cates what sensor caused the alarm condition.
To enter identification mode:
1. Open the driver ’s door and leave it open.
2. Turn the ignition switch to “ON” two times. ( “LOCK” “ON”
“LOCK” “ON” “LOCK”)
3. The indicator light will start flashing.
The indicator light provides the following indications. Flashing one time: Any door has been opened.
Flashing three times: The impact sensor in the system ’s unit has
been activated. This may indicate that your vehicle has been shocked
or tampered with by some outside force and/or unauthorized person.Flashing four times: The ignition switch has been turned on or the
battery has been disconnected. NOTE The battery must be reconnected before the indicator light will flash.
To exit this mode, close the door and turn the ignition switch to “ON”.

Keys and doors2-21
–
CONTINUED –
Windows Power windows
WARNING
To avoid serious personal injury caused by entrapment, you must observe the following warnings: When operating power windows, be extremely careful to pre-
vent anyone ’s fingers, arms or head from being caught in the
window. Always lock the passengers ’ windows using the lock switch
when children are riding in the vehicle. Before leaving the vehicle, always remove the key from the
ignition switch for safety and never allow an unattended child toremain in the vehicle. Failure to follow this procedure could result
in injury to a child operating the power window.
The power windows operate only when the ignition switch is in the “ON”
position.
Driver’ s side switches
HB2008BB
