2003 SUBARU BAJA engine

Maintenance and service11-11
–
CONTINUED –
12. Reinstall the cover under the oil filter.
13. Pour engine oil through the filler neck.
Oil capacity (Guideline): 4.2 US qt (4.0 liters, 3.5 Imp qt)
The oil quantity indicated above is only a guideline. The necessary quantity of oil depends on the quantity of oil that has been drained.
The quantity of drained oil differs slightly depending on the tempera-
ture of the oil and the time the oil is left flowing out. After refilling the
engine with oil, therefore, you must use the dipstick to confirm that the
level is correct.
14. Start the engine and make sure that no oil leaks appear aroundthe filter ’s rubber seal and drain plug.
15. Run the engine until it reaches the normal operating temperature.
Then stop the engine and wait a few minutes to allow the oil drain
back. Check the oil level again and if necessary, add more engine oil. Recommended grade and viscosity CAUTION
Use only engine oil with the recommended grade and viscosity.
Oil grade: ILSAC GF-3, which can be identified with the new API certification mark (Starburst mark)
or API classification SL with the words “ENERGY CON-
SERVING” (if you cannot obtain the oil with SL grade,
you may use SJ grade “ENERGY CONSERVING ” oil).
These recommended oil grades can be identified by looking for either
or both of the following marks displayed on the oil container.

11-12
New API Certification Mark (Starburst Mark)
1Indicates the oil quality by API desig- nations
2 Indicates the SAE oil viscosity grade
3 Indicates that the oil has fuel savingcapabilities
In choosing an oil, you want the proper quality and viscosity, as well
as one that will add to fuel economy. The following table lists the rec-
ommended viscosities and applicable temperatures.
When adding oil, different brands may be used together as long as
they are the same API classification and SAE viscosity as those rec-
ommended by SUBARU.
Engine oil viscosity (thickness) affects fuel economy. Oils of lower vis-
cosity provide better fuel economy. However, in hot weather, oil of
higher viscosity is required to properly lubricate the engine.
OM-H2756
SAE viscosity numbr and applicable temperature

Maintenance and service11-13
–
CONTINUED –
Recommended grade and viscosity under severe driving conditions
If the vehicle is used in desert areas, in areas with very high tempera-
tures, or used for heavy-duty applications such as towing a trailer, use
of oil with the following grade and viscosities is recommended.
API classification SL (or SJ): SAE viscosity No.: 30, 40, 10W-50,
20W-40, 20W-50
Cooling system
WARNING
Never attempt to remove the radiator cap until the engine has
been shut off and has cooled down completely. Since the coolantis under pressure, you may suffer serious burns from a spray ofboiling hot coolant when the cap is removed.
CAUTION
The cooling system has been filled at the factory with a high
quality, corrosion-inhibiting, year-around coolant which providesprotection against freezing down to –33°F ( –36 °C). For adding,
use genuine SUBARU coolant or an equivalent: a mixture of 50%
soft water and 50% ethylene-glycol basis coolant. Use of improp-er coolants may result in corrosion in the cooling system. It is im-portant to maintain protection against freezing and corrosion,even if freezing temperatures are not expected. Never mix differ-ent kinds of coolant. Do not splash the engine coolant over painted parts. The alco-
hol contained in the engine coolant may damage the paint sur-face.
Hose and connections
Your vehicle employs an electric cooling fan which is thermostatically

11-14
controlled to operate when the engine coolant reaches a specific tem-
perature.If the radiator cooling fan does not operate even when the engine
coolant temperature gauge exceeds the normal operating range, the
cooling fan circuit may be defective. Check the fuse and replace it if
necessary. If the fuse is not blown, have the cooling system checked
by your SUBARU dealer.
If frequent addition of coolant is necessary, there may be a leak in the
engine cooling system. It is recommended that the cooling systemand connections be checked for leaks, damage, or looseness.
Engine coolant Checking the coolant level
Check the coolant level at each fuel stop.
HBB004FB
1. Check the coolant level on the outside of the reservoir while the
engine is cool.
2. If the level is close to or lower than the “LOW” level mark, add
coolant up to the “FULL” level mark. If the reserve tank is empty, re-
move the radiator cap and refill as required.

Maintenance and service11-15
–
CONTINUED –
HG0115
Rubber gaskets
3. After refilling the reserve tank and the radiator, reinstall the caps
and check that the rubber gaskets inside the radiator cap are in the
proper position. Changing the coolant
WARNING
Never attempt to remove the radiator cap until the engine has
been shut off and has cooled down completely. Since the coolantis under pressure, you may suffer serious burns from a spray ofboiling hot coolant when the cap is removed.
Change the engine coolant using the following procedures according
to the maintenance schedule in the “Warranty and Maintenance Book-
let”. 1. Remove the under cover.
2. Place a proper container under the drain plug and loosen the drainplug.

Maintenance and service11-17
–
CONTINUED –
HG0115
Rubber gaskets
5. Put the radiator cap back on and tighten firmly. At this time, make
sure that the rubber gasket in the radiator cap is correctly in place.
6. Start and run the engine for more than five minutes at 2,000 to
3,000 rpm.
7. Stop the engine and wait until the coolant cools down (122 to140 °F [50 to 60 °C]). If there is any loss of coolant, add coolant to the
radiator’ s filler neck and to the reserve tank ’s “FULL” level.
8. Put the radiator cap and reservoir cap back on and tighten firmly.
Air cleaner element
WARNING
Do not operate the engine with the air cleaner element removed.The air cleaner element not only filters intake air but also stops
flames if the engine backfires. If the air cleaner element is not
installed when the engine backfires, you could be burned.
The air cleaner element functions as a filter screen. When the element is
perforated or removed, engine wear will be excessive and engine life
shortened.
The air cleaner element is a viscous type. It is unnecessary to clean or wash the element.

Maintenance and service11-21
–
CONTINUED –
Manual transmission oil
Checking the oil level
Check the oil level monthly.
1. Park the vehicle on a level surface and stop the engine.
OM-H0210
Upper level Lower level
HBB004DB
2. Pull out the dipstick, wipe it clean, and insert it again.
3. Pull out the dipstick again and check the oil level on it. If it is below
the lower level, add oil through the dipstick hole to bring the level upto the upper level. Recommended grade and viscosity
Each oil manufacturer has its own base oils and additives. Never use
different brands together.
Oil grade: API classification GL-5

11-22
SAE viscosity No. and Applicable Temperature
OM-H0205
Automatic transmission fluidChecking the fluid level
The automatic transmission fluid expands largely as its temperature
rises; the fluid level differs according to fluid temperature. Therefore,
there are two different scales for checking the level of hot fluid andcold fluid on the dipstick.
Though the fluid level can be checked without warming up the fluid on the “COLD” range, we recommend checking the fluid level when
the fluid is at operating temperature. n Checking the fluid level when the fluid is hot
Check the fluid level monthly.
1. Drive the vehicle several miles to raise the temperature of the
transmission fluid up to normal operating temperature; 158 to 176 °F
(70 to 80 °C) is normal.
2. Park the vehicle on a level surface and set the parking brake.
3. First shift the selector lever in each position. Then shift it in the “P”
position, and run the engine at idling speed.
