2003 NISSAN PATHFINDER Owners Manual

ShiftingPush the button to shift into P, R or from D to 2.
All other positions can be selected without
pushing the button.
P (Park):
Use this selector position when the vehicle is
parked or when starting the engine. Make sure
the vehicle is completely stopped.The brake
pedal must be depressed and the selector
lever button pushed in to move the selec-
tor lever from N(Neutral) or any drive
position to P (Park).Apply the parking brake.
When parking on a hill, apply the parking brakefirst, then move the lever to the P (Park) position.
R (Reverse):
Use this position to back up. Always be sure the
vehicle is completely stopped before selecting R
(Reverse).The brake pedal must be de-
pressed and selector lever button pushed
in to move the selector lever from P (Park),
N(Neutral) or any drive position to R (Re-
verse).
N(Neutral):
Neither forward nor reverse gear is engaged.
The engine can be started in this position. You
may shift to N and restart a stalled engine while
the vehicle is moving.
D (Drive):
Use this position for all normal forward driving.
2 (Second gear):
Use for hill climbing, effective engine braking on
downhill grades or starting on slippery roads.
Do not downshift into the 2 position at speeds
over the following speeds and do not exceed the
following speeds in the 2 position:
Two wheel drive:
60 MPH (95 km/h)Four wheel drive:
(Part time)
2H and 4H positions 50 MPH (80 km/h)
4L position 19 MPH (30 km/h)
(All-mode)
2WD and AUTO positions
60 MPH (95 km/h)
4H position 50 MPH (80 km/h)
4LO position 22 MPH (35 km/h)
1 (Low gear):
Use this position when climbing steep hills
slowly or driving slowly through deep snow,
sand or mud, or for maximum engine braking on
steep downhill grades.
Do not shift into 1 position at speeds over the
following speeds:
Two wheel drive:
60 MPH (95 km/h)
Four wheel drive:
(Part time)
2H and 4H positions 50 MPH (80 km/h)
4L position 19 MPH (30 km/h)
SSD0092
5-12
Starting and driving


03.1.28/R50-D/V5


(All-mode)
2WD and AUTO positions
30 MPH (50 km/h)
4H position 30 MPH (50 km/h)
4LO position 10 MPH (15 km/h)
Do not exceed the following speeds in the 1
position:
Two wheel drive:
30 MPH (50 km/h)
Four wheel drive:
(Part time)
2H and 4H positions 30 MPH (50 km/h)
4L position 12 MPH (19 km/h)
(All-mode)
2WD and AUTO positions
30 MPH (50 km/h)
4H position 30 MPH (50 km/h)
4LO position 10 MPH (15 km/h)
SSD0212A
SSD0111B
Starting and driving
5-13


03.1.28/R50-D/V5


Shift lock releaseIf the battery charge is low, the select lever may
not be moved from the P position even with the
brake pedal depressed and the select lever
button pushed.
To move the select lever, remove the shift lock
cover using a flat-bladed screwdriver, and push
the shift lock release button and select lever
button with the parking brake securely applied
and the brake pedal firmly depressed. The select
lever can be moved to N (Neutral).
To push the shift lock release button, follow the
procedure as illustrated.
If the lever cannot be moved out of P (Park) have
your NISSAN dealer check the automatic trans-
mission system as soon as possible.
WARNING
If the selector lever cannot be moved
from the P position while the engine is
running and the brake pedal is de-
pressed, the stop lights may not work.
Malfunctioning stop lights could cause
an accident injuring yourself and others.
Accelerator downshift
— In D position —For rapid passing or hill climbing, fully depress
the accelerator pedal to the floor. This shifts the
transmission down into second gear or first gear,
depending on the vehicle speed.
Overdrive switchEach time your vehicle is started, the transmis-
sion is automatically reset to overdrive on.
ON: For normal driving the overdrive switch
is engaged. The transmission is up-
shifted into overdrive as the vehicle
speed increases.
The overdrive does not engage until the
engine has warmed up.
OFF: For driving up and down long slopes
where engine braking would be advan-
tageous, push the overdrive switch. The
O/D OFF light illuminates. When cruis-
SSD0106
5-14
Starting and driving


03.1.28/R50-D/V5


ing at a low speed or climbing a gentle
slope, you may feel uncomfortable shift
shocks as the transmission shifts be-
tween 3rd and overdrive repeatedly. In
this case, press the overdrive switch.
The O/D OFF indicator light comes on
at this time.
When driving conditions change, press the over-
drive switch again. The O/D OFF indicator light
goes out.
Remember not to drive at high speeds for ex-
tended periods of time with the O/D OFF light
illuminated. This reduces the fuel economy.
Fail-safeWhen the Fail-safe operation occurs, the next
time the key is turned to the ON position, the
O/D OFF light will blink for approximately 8
seconds after coming on for 2 seconds. While
the vehicle can be driven under these circum-
stances please note that the gears in the auto-
matic transmission may be locked in third gear.
If the vehicle is driven under extreme con-
ditions, such as excessive wheel spinning
and subsequent hard braking, the Fail-safe
system may be activated. This will occur
even if all electrical circuits are functioning
properly. In this case, turn the ignition key
OFF and wait for 3 seconds. Then turn thekey back to the ONposition. The vehicle
should return to its normal operating con-
dition. If it does not return to its normal
operating condition have your NISSAN
dealer check the transmission and repair if
necessary.
MANUAL TRANSMISSION
Shifting
WARNING

Do not downshift abruptly on slip-
pery roads. This may cause a loss of
control.

Do not over-rev the engine when
shifting to a lower gear. This may
cause a loss of control or engine
SSD0107
Starting and driving
5-15


03.1.28/R50-D/V5


damage.
To change gears, or when up shifting or down
shifting, depress the clutch pedal fully, shift into
the appropriate gear, then release the clutch
slowly and smoothly.
Start the vehicle in 1st gear and shift to 2nd, 3rd
and 4th up to 5th gear in sequence according to
the vehicle speed.
You cannot shift directly from 5th gear into
Reverse. First shift into the Neutral position, then
into Reverse.
If it is difficult to move the shift lever into Reverse
or 1st, shift into Neutral, then release the clutch
pedal and shift into Reverse or 1st again. If your
vehicle is equipped with four wheel drive, see
“Using four wheel drive” later in this section.
Suggested up-shift speedsThe table below provides suggested speed
ranges for shifting into a higher gear. These
suggestions relate to fuel economy and vehicle
performance. Actual shift ranges should be ad-
justed for specific road conditions, weather con-
ditions and individual driving habits.

Two wheel drive models and four wheel drive
models (2H and 4H position)MPH (km/h)
1st to 2nd 15 (24)
2nd to 3rd 25 (40)
3rd to 4th 40 (64)
4th to 5th 45 (72)

Four wheel drive model (4L position)
MPH (km/h)
1st to 2nd 8 (13)
2nd to 3rd 12 (20)
3rd to 4th 20 (32)
4th to 5th 22 (36)
Suggested maximum speed in each
gearDownshift to a lower gear if the engine is not
running smoothly, or if you need to accelerate.
Do not exceed the maximum suggested speed
(shown below) in any gear. For level road driving,
use the highest gear suggested for that speed.
Always observe posted speed limits, and drive
according to the road conditions which will
ensure safe operation. Do not overrev the engine
when shifting to a lower gear as it may cause
engine damage or loss of vehicle control.Allowable maximum speed in each gear
Two wheel drive models and four wheel drive
models (2H position) MPH (km/h)
1st 22 (36)
2nd 37 (60)
3rd 56 (90)
4th & 5th — (—)
Four wheel drive models MPH (km/h)
4H position
1st 22 (36)
2nd 37 (60)
3rd 50 (80)
4th & 5th 50 (80)
4L position
1st 9 (15)
2nd 19 (30)
3rd 28 (45)
4th & 5th 31 (50)
CAUTION

Do not rest your foot on the clutch
pedal while driving. This may cause
clutch damage.

Stop your vehicle completely before
shifting into R (Reverse).
5-16
Starting and driving


03.1.28/R50-D/V5


When the vehicle is stopped for a
period of time, for example at a stop
light, shift to N(Neutral) and release
the clutch pedal with the foot brake
applied.
To apply:pull the lever up.
To release:
1. Firmly apply foot brake.
2.Manual transmission models:
Place the gearshift lever in the N (Neutral)
position.
Automatic transmission models:
Move the selector lever to the P (Park) posi-
tion.
3. While pulling up on the lever slightly, push
the button and lower completely.4. Before driving, be sure the brake warning
light goes out.
WARNING

Be sure the parking brake is fully
released before driving. Failure to do
so can cause brake failure and lead
to an accident.

Do not release the parking brake
from outside the vehicle.

Do not use the gear shift in place of
the parking brake. When parking, be
sure the parking brake is fully en-
gaged.

Do not leave children unattended in a
vehicle. They could release the park-
ing brake and cause an accident.
PD1001M
PARKING BRAKE
Starting and driving
5-17


03.1.28/R50-D/V5


WARNING
Do not use the cruise control when driv-
ing under the following conditions:

when it is not possible to keep the
vehicle at a set speed.

in heavy traffic or in traffic that varies
in speed.

on winding or hilly roads.

on slippery roads (rain, snow, ice,
etc.)

in very windy areas.
Doing so could cause a loss of vehicle
control and result in an accident.
CAUTION
On manual transmission models, do not
shift into N(Neutral) without depressing
the clutch pedal when the cruise control
is set. Should this occur, depress the
clutch pedal and turn the main switchoff immediately. Failure to do so may
cause engine damage.
PRECAUTIONS ON CRUISE
CONTROL
If the engine coolant temperature becomes
excessively high, the cruise control system
will automatically be canceled.

If the cruise control system malfunctions, it
cancels automatically. The SET indicator light
in the instrument panel then blinks to warn
the driver.

If the SET indicator light blinks, turn the
cruise control main switch off and have the
system checked by your NISSAN dealer.

The SET indicator light may blink when the
cruise control main switch is turned on while
pushing the RES/ACCEL, COAST/
SET, or CANCEL switch (located on the
steering wheel). To properly set the cruise
control system, perform the preceding steps
in the order indicated.
CRUISE CONTROL OPERATIONSThe cruise control allows driving at a fixed speed
between 25 to 89 MPH (40 to 144 km/h)
without keeping your foot on the accelerator
pedal.
To turn on the cruise control,push the main
switch on. The CRUISE indicator light on the
meter panel will come on.
To set at cruising speed,accelerate your
vehicle to the desired speed, push the
SET/COAST switch and release it. (The SET
light will come on.) Take your foot off the accel-
SSD0236A
CRUISE CONTROL (if so
equipped)5-18
Starting and driving


03.1.28/R50-D/V5


erator pedal. Your vehicle will maintain the set
speed.

To pass another vehicle,depress the ac-
celerator pedal. When you release the pedal,
the vehicle will return to the previously set
speed.

The vehicle may not maintain the set speed
when going up or down steep hills. If this
happens, drive without the cruise control.
To cancel the preset speed,follow any of
these three methods:
a) Push the cancel switch; The SET light will go
out.b) Tap the brake pedal; The SET light will go
out.
c) Turn the main switch off. Both the CRUISE
indicator and SET indicator lights will go out.

If you depress the brake pedal while pushing
the ACCEL/RES set switch and reset at the
cruising speed, turn the main switch off once
and then turn it on again.

The cruise control will automatically be can-
celled if the vehicle slows down more than 8
MPH (13 km/h) below the set speed.

Depress the clutch pedal (manual transmis-
sion), or move the selector lever to N position
(automatic transmission). The SET light will
go out.
To reset at a faster cruising speed,follow
either of these three methods:
a) Depress the accelerator pedal. When the
vehicle attains the desired speed, push and
release the SET/COAST switch.
b) Push and hold the ACCEL/RES set switch.
When the vehicle attains the speed you
desire, release the switch.
c) Push, then quickly release the ACCEL/
RES set switch. Each time you do this, the
set speed will increase by about 1 MPH (1.6
km/h).To reset at a slower cruising speed,follow
either of these three methods:
a) Lightly tap the brake pedal. When the vehicle
attains the desired speed, push the
SET/COAST switch and release it.
b) Push and hold the SET/COAST switch. Re-
lease the switch when the vehicle slows
down to the desired speed.
c) Push, then quickly release the SET/
COAST switch. Each time you do this, the set
speed will decrease by about 1 MPH (1.6
km/h).
To resume the preset speed,push and re-
lease the ACCEL/RES set switch. The vehicle
will resume the last set cruising speed when the
vehicle speed is over 25 MPH (40 km/h).
Precautions
The CRUISE indicator may sometimes blink
when the cruise control switch (Main switch)
is turned ON while pushing the ACCEL/RES
switch or SET/COAST switch or CANCEL
switch (located on the steering wheel). To
properly set the cruise control system per-
form the steps above in the order indicated.
(This is a fail-safe mode. Turn the main switch
OFF and turn it ON again without pushing the
set switch to return to normal operation.)
SSD0219D
Starting and driving
5-19


03.1.28/R50-D/V5
