2003 MERCEDES-BENZ E-CLASS height adjustment

35 Getting started
Adjusting
Seat adjustment
The seat adjustment switches are located
in each door.
1Seat fore and aft adjustment
2Seat height
3Seat cushion tilt
4Backrest tilt
5Head restraint height
Turn the key in the starter switch to
position1or2.
or

Press the KEYLESS GO* start/stop
button once or twice.
or

Open the driver’s or passenger door.
Seat height

Press the switch up or down in the di-
rection of arrow2.
Seat fore and aft adjustment

Press the switch forward or backward
in the direction of arrow1.
Adjust to a comfortable seating posi-
tion that still allows you to reach the
accelerator / brake pedal safely. The
position should be as far to the rear as
possible, consistent with ability to
properly operate controls.
Infants and small children must be seated in
an appropriate infant or child restraint sys-
tem, which is properly secured with the ve-
hicle’s seat belt, fully in accordance with the
child seat manufacturer’s instructions.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
iWhen moving the seat, be sure that
there are no items in the footwell or be-
hind the seats. Otherwise you could
damage the seats.
ProCarManuals.com

38 Getting startedAdjustingSteering wheel adjustment
The stalk is located on the steering column
(lower left).
1Steering column stalk, adjusts length
2Steering column stalk, adjusts height
Turn the key in the starter switch to
position1or2.
or

Press the KEYLESS GO* start/stop
button once or twice.
or

Open the driver or passenger door.Steering column, lengthen or shorten

Move stalk forward or backward in the
direction of arrow 1 until a comfortable
steering wheel position is reached with
your arms slightly bent at the elbow.
Steering column, height

Move the stalk up or down in the direc-
tion of arrow 2. Make sure that your
legs can move freely and that all the
displays (including malfunction and in-
dicator lamps) on the instrument clus-
ter are clearly visible.
Mirrors
Adjust the inside and exterior rear view
mirrors before driving so that you have a
good view of the road and traffic condi-
tions.
Inside rear view mirror
Manually adjust the inside rear view
mirror.
More information can be found in the
"Controls in detail" section (
page 157).
Warning!
G
In the case of an accident liquid electrolyte
may escape the mirror housing if the mirror
glass breaks.
Electrolyte has an irritating effect. Do not al-
low the liquid to come into contact with
eyes, skin, clothing, or respiratory system.
In case it does, immediately flush affected
area with water, and seek medical help if
necessary.
ProCarManuals.com

42 Getting startedDriving
Place the belt over your shoulder.

Push latch plate2 into buckle3 until it
clicks.

If necessary, tighten the lap portion to
a snug fit by pulling shoulder portion
up.
Belt outlet height adjustment
1Release button

Press release button1 and move the
seat belt height adjuster upward or
downward.Proper use of seat belts


Do not twist the belt when fastening.


Adjust seat belt so that the shoulder
portion is located as close as possible
to the middle of the shoulder (it should
not touch the neck or pass under the
arm).


Position the lap belt as low as possible
on your hips (over hip joint) and not
across the abdomen.


Place the seat backrest in a nearly up-
right position.


Each seat belt should never be used for
more than one person at a time.


Do not fasten a seat belt around a per-
son and another object at the same
time.


Check your seat belt during travel to
ensure that it is properly positioned.


Ensure that the seat belt is always fit-
ted snugly. You should avoid wearing
bulky clothing, such as winter coats,
when traveling in the vehicle.
ProCarManuals.com

209 Controls in detail
Driving systems
AIRMATIC DC (Dual Control)*
Vehicle level control
Your vehicle automatically adjusts its ride
height to

reduce fuel consumption


increase vehicle safety
The following vehicle chassis ride heights
are possible:


Normal


Raised


Lowered
The vehicle chassis ride height is raised or
lowered according to the selected level
setting and to the vehicle speed:


With increasing speed, ride height is re-
duced automatically by up to approxi-
mately 0.6 inch (15 mm) "Lowered"
level.


With decreasing speed, the ride height
is again raised to the "Normal" level.
Select the "Raised" level only when re-
quired by current driving conditions. Oth-
erwise


fuel consumption may increase


handling may be impairediThese height adjustments are so small
that you may not notice any change.
Warning!
G
To help avoid personal injury, keep hands
and feet away from wheel housing area, and
stay away from under the vehicle when low-
ering the vehicle chassis.
ProCarManuals.com

381 Index
A
ABS 73, 375
Malfunction indicator lamp 289
Messages in display 296
Warning lamp 289
Accelerator position, automatic
transmission 156
Accident
In case of 49
Activating
Air conditioning (cooling) 170, 181
Air recirculation mode 168, 178
Anti-theft alarm system 82
Automatic climate control 174
Central locking (control system) 142
Charcoal filter 180
Climate control 164
Defrost 167
Distance warning function* 206
Distronic* 202
Easy-entry/exit feature* 143
ESP 77
Exterior headlamps 46
Exterior lamps 113
Hazard warning flasher 115
Headlamps 46High beams 115
Ignition 31
Ignition with KEYLESS-GO* start/stop
button 33
Immobilizer 52, 81
Rear fog lamp 113
Rear window defroster 169, 180
Residual heat 171, 182
Tow-away alarm 83
Windshield wipers 47
Adjustable air outlets, rear passenger
compartment 182
Adjusting 34
Air distribution 166, 177
Air volume 166, 177
Backrest tilt 36
Exterior rear view mirror 39
Head restraint height 36
Head restraint tilt 36
Inside rear view mirror 38
Instrument cluster illumination 118
Mirrors 38
Multicontour seat* 104
Seat cushion depth 105
Seat cushion tilt 36
Seat fore and aft adjustment 35Seat height 35
Seats 34
Steering column height 38
Steering column length 38
Steering wheel 37
Air conditioner (cooling)
Turning off 170, 181
Turning on 170, 181
Air distribution
Adjusting 166, 177
Air outlets, rear passenger compartment
Adjustable 182
Air recirculation mode 167, 178
Activating 168, 178
Deactivating 168, 179
Air volume
Adjusting 166, 177
Airbags 57
BabySmart
TM airbag deactivation
system 67, 375
Children 58
Front 60
Passenger 60
Safety guidelines 59
Side impact 61
Window curtain 61
ProCarManuals.com

388 IndexGrarage door opener 27
H
Hand-held transmitter
Programming integrated remote
control 244
Hazard warning flasher 115
Switching off 115
Switching on 115
Head restraints 103
Headlamps
Automatic control 113
Bi-Xenon 375
Cleaning system* 158
Switching off 51
Switching on 46
Heated seats* 107
Height adjustment
Head restraints 36
Steering wheel 37
Vehicle level 209
High beam flasher 47, 115
High beam headlamps 332
Messages in display 316
Switching on 115Hood 261
Closing 261
Message in display 313
Opening 261
I
Identification labels 358
Ignition 31, 33
Switching on 44
Immobilizer 81
Activating 81
Deactivating 81
Indicator lamps see Lamps, indicator and
warning
Infant and child restraint systems 65
Info services 242
Information
About service and warranty 10
Button for Tele Aid* 239
Inside rear view mirror
Adjusting 38
Instrument 22
Instrument cluster 118, 377
Coolant temperature display 119
Illumination 118
Multifunction display 121
Outside temperature indicator 120Selecting language 135
Instrument lighting 118, 119
Integrated remote control
Canadian programming 245
Erasing memory 246
Hand-held transmitter 244
Operating 246
Rolling code programming 245
Interior lighting 116
Activating automatic control 116
Deactivating automatic control 116
Delayed switch-off 141
Manual operation 116
Interior storage spaces 226
Glove box 226
J
Jump starting 346
K
Key (SmartKey)
Changing the batteries 329
Key dependency memory
Settings 144
Key positions in starter switch 31
Key, electronic
Messages in display 323
ProCarManuals.com

392 IndexOverhead control panel 27
Garage door opener 243
Overspeed range 378
P
Panic alarm 72
Panic button on SmartKey 72
Parking 50
Parking brake 45, 50
Engaging 50
Message in display 310
Releasing 45
Parking lamps 332
Replacing the bulbs 335
Switching on 112
Parking position
Exterior rear view mirrors 111, 144,
158
Parktronic*
Sensor 284
PASSENGER AIRBAG OFF indicator
lamp 294
Passenger compartment
Inside rear view mirror 38
Interior lighting 116
Passenger safety see Occupant
safety 56Phone book*
Loading 149
Quick search 149
Phone number*
Dialing 149
Redialing 149
Poly-V-belt drive 378
Positions (Memory function)
Recalling from memory 110
Positions (Memory function*)
Storing into memory 110
Power seat
Adjusting backrest tilt 36
Adjusting head restraint height 36
Adjusting head restraint tilt 36
Adjusting seat cushion tilt 36
Adjusting seat height 35
Memory function 109
Removing/installing head
restraints 103
Seat fore and aft adjustment 35
Power train 378
Power windows 184
Blocking of rear window operation 71
Side windows 184
Synchronizing 186Practical hints
Lamp in center console 294
Problems
While driving 48
With vehicle 17
Product information 9
Program mode selector switch 378
Automatic transmission 155
Q
Quick search
Phone book* 149
R
Radio
Selecting stations 127
Range (distance to empty)
Calling up 147
Rear bench seat
Foldable 219
Rear fog lamp
Switching on 114
Rear lamps see Tail lamps
Rear passenger compartment
Adjustable air outlets 182
Rear seat head restraints
Folding back with switch 104
ProCarManuals.com

396 IndexSteering column
Height adjustment 38
Length adjustment 38
Steering gear oil
Message in display 318
Steering wheel
Adjusting 37
Electrical adjustment 38
Height adjustment 38
Stolen vehicle
Tracking services 242
Stopping
Sliding/pop-up roof* 188
Windows 185
Storage compartments
Glove box 226
Storing (Memory function*)
Positions into memory 110
Submenus
Convenience 143
For settings 123
In control system 125
Instrument cluster 134, 136
Lighting 138
Resetting functions in Control
system 131Selecting 131
Settings menu 131
Vehicle 142
Sun visors 158
Supplemental Restraint System
(SRS) 379
Suspension tuning
For regular driving style 212
For sporty driving style 212
Switching off
Automatic central locking (control
system) 142
Engine 51
ESP 76
Hazard warning flasher 115
Headlamps 51
Switching on
Automatic central locking (control
system) 142
ESP 77
Front fog lamps 114
Hazard warning flasher 115
Headlamps 46
High beams 115
Rear fog lamp 114
Windshield wipers 47Symbol (Distronic*)
Distance warning function* 129
Synchronizing
Power windows 186
Sliding/pop-up roof* 189
T
Tachometer 120
Overspeed range 120
Tail lamps 333, 336
Tele Aid System 379
Tele Aid* 234
Emergency calls 236
Info services 242
Information 239
Initiating an emergency call
manually 237
Remote door unlock 241
Roadside assistance 238
SOS button 237
Stolen vehicle tracking services 242
System self-check 235
Tele Aid System 235
Upgrade signals 240
Telematics* 379
Telephone* 24, 233
Answering a call 148
ProCarManuals.com
