2003 MERCEDES-BENZ C CLASS COUPE ESP

Contents
Introduction ......................................... 9
Product information ............................... 9
Operator’s Manual ............................... 10 Service and warranty information .. 10
Important notice for California
retail buyers and lessees of
Mercedes-Benz automobiles .......... 11
Maintenance .................................. 12
Roadside Assistance ...................... 12
Change of address or ownership .... 12
Operating your vehicle outside
the USA or Canada ......................... 13
Where to find it .................................... 14
Symbols ............................................... 15
Operating safety .................................. 16 Proper use of the vehicle ............... 16
Problems with your vehicle .................. 17
Reporting safety defects ...................... 18 Reporting Safety Defects ............... 18
At a glance .......................................... 19
Cockpit .................................................20
Instrument cluster ................................22
Multifunction steering wheel ................24
Center console .....................................25
Overhead control panel ........................26
Door control panel ................................27Getting started ...................................29
Unlocking .............................................30 Unlocking with the SmartKey ..........30
Adjusting ..............................................32 Seats ...............................................32
Steering wheel ................................37
Mirrors ............................................39
Driving ..................................................41 Fastening the seat belt ...................41
Starting the engine .........................44
Switching on headlamps .................47
Turn signals and high beam ............47
Windshield wipers ...........................48
Problems while driving ....................50 Parking and locking .............................. 51
Parking brake .................................. 51
Switching off headlamps ................. 52
Turning off engine ........................... 52
Safety and Security ........................... 55
Occupant safety ................................... 56Airbags ........................................... 57
Seat belts ....................................... 62
Children in the vehicle .................... 65
Panic alarm* ........................................ 72 Activating ........................................ 72
Deactivating .................................... 72
Driving safety systems ......................... 73 ABS ................................................. 73
BAS ................................................. 74
ESP ................................................. 75
Anti-theft systems ................................ 78 Immobilizer ..................................... 78
Anti-theft alarm system* ................ 78
Tow-away alarm* ............................ 79

9
Product information
Introduction
Product informationPlease observe the following in your own
best interest:
We recommend using Mercedes-Benz orig-
inal parts as well as conversion parts and
accessories explicitly approved by us for
your vehicle model.
We have tested these parts to determine
their reliability, safety and their special
suitability for Mercedes-Benz vehicles.We are unable to make an assessment for
other products and therefore cannot be
held responsible for them, even if in indi-
vidual cases an official approval or authori-
zation by governmental or other agencies
should exist. Use of such parts and acces-
sories could adversely affect the safety,
performance or reliability of your vehicle.
Please do not use them.
Mercedes-Benz original parts as well as
conversion parts and accessories ap-
proved by us are available at your autho-
rized Mercedes-Benz Center where you will
receive comprehensive information, also
on permissible technical modifications,
and where proper installation will be per-
formed.

23
At a glance
Instrument cluster
Item
Page
1
Reset knob for:

Resetting trip odome-
ter
103


Instrument cluster illu-
mination
102


Resetting individual
settings
114
2
Tachometer with:?
Engine malfunction
indicator lamp
250
-
Antilock Brake Sys-
tem (ABS) malfunc-
tion indicator lamp
247
;
Brake warning
lamp, except Cana-
da
249
3
Brake warning
lamp, Canada only
249
Item
Page
3
Speedometer with:L
Left turn signal indi-
cator lamp
K
Right turn signal in-
dicator lamp
v
Electronic Stability
Program (ESP)
warning lamp
246
A
High beam head-
lamp indicator
99
E
Indicator lamp with-
out function
1
1The indicator lamp illuminates briefly when you
turn the key in the starter switch to position
2
DTRIndicator lamp with-
out function
1
Item
Page
4
Multifunction display
with:Trip odometer
103
Main odometerOutside temperature dis-
play
104
Digital clock
116
5
Display for program
mode and selector lever
position
135
136
6
Fuel gauge with:Fuel reserve warning lamp
250
<
Seat belt nonusage
warning lamp
250
1
Supplemental re-
straint system indi-
cator lamp
248

25
At a glance
Center console
Center console
Item
Page
1
Seat heater*, driver‘s side
91
2
ESP control switch
75
3
Hazard warning flasher
switch – switching on/off
99
4
Central locking switch
87
5
Anti-theft alarm system in-
dicator lamp
78
Tow-away alarm switch
79
6
Seat heater*, passenger
side
91
7
Indicator lamp
7
67
8
Audio system, or
159
COMAND* (see separate
operating instructions)
Item
Page
9
Climate control
142
10
Ashtray
198
11
Storage compartment
196
12
Armrest
197
13
Program mode selector for
automatic transmission
136
14
Gearshift lever for manual
transmission
Selector lever for automat-
ic transmission
44
45

30 Getting startedUnlockingThe “Getting started” section provides an
overview of the vehicle’s most basic func-
tions. First-time Mercedes-Benz owners
should pay special attention to the infor-
mation given here.
If you are already familiar with the basic
functions described here, the “Controls in
detail” section will help you with further in-
formation. The corresponding page refer-
ences are at the end of each segment.
UnlockingUnlocking with the SmartKeySmartKey with remote control 1‹
Lock button
2
Œ
Unlock button
3
Â
Panic button* (
page 72)

Press unlock button 2
Œ
on the key.
All turn signal lamps blink once. The
locking knobs in the doors move up.

Get in the vehicle and insert the key in
the starter switch.iCanada only:
Only vehicles equipped with an
anti-theft alarm system* have
SmartKeys with integrated panic
button* 3.

39
Getting started
Adjusting
Steering column, lengthen or shorten
Move stalk forward or backward in the
direction of arrow
1 until a comfortable
steering wheel position is reached with
your arms slightly bent at the elbow.
Steering column, height

Move stalk up or down in the direction
of arrow 2. Make sure that your legs
can move freely and that all the dis-
plays (including malfunction and indi-
cator lamps) on the instrument cluster
are clearly visible.
Mirrors
Adjust the inside and exterior rear view
mirrors before driving so that you have a
good view of the road and traffic condi-
tions. Inside rear view mirror

Manually adjust the inside rear view
mirror.
More information can be found in the
“Controls in detail” section (
page 138).
iWith the memory function*
(page 93) you can store settings for
the steering wheel together with set-
tings for the exterior rear view mirrors
and seat positions.
Warning!
G
In the case of an accident liquid electrolyte
may escape the mirror housing if the mirror
glass breaks.
Electrolyte has an irritating effect. Do not al-
low the liquid to come into contact with
eyes, skin, clothing, or respiratory system.
In case it does, immediately flush affected
area with water, and seek medical help if
necessary.

53
Getting started
Parking and locking
Turning off with the SmartKey
Turn the key in the starter switch to
position
0 and remove it.
The immobilizer is activated.

Press the seat belt release button
(page 41).

After exiting the vehicle press the lock
button
‹
on the remote control
(
page 30).
The locking knobs on the doors move
down.
More information can be found in the
“Controls in detail” section (
page 82).
iVehicles with automatic transmission:
The SmartKey can only be removed
from the starter switch with the gear
selector lever in position P.!With the SmartKey removed and the
driver’s door open, a warning sounds if
the vehicle’s exterior lamps are not
switched off.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the door
openings when closing the doors. Be espe-
cially careful when small children are
around.
Before closing doors, make sure that there
is no possibility of someone getting caught
in a door during closing.

58 Safety and SecurityOccupant safety

Adjust the driver seat as far as possible
rearward, still permitting proper opera-
tion of vehicle controls. The distance
from the center of the driver’s breast-
bone to the center of the airbag cover on
the steering wheel must be at least ten
inches (25 cm) or more. You should be
able to accomplish this by a combina-
tion of adjustments to the seat and
steering wheel. If you have any prob-
lems, please see your authorized
Mercedes-Benz Center.


Do not lean with your head or chest
close to the steering wheel or dash-
board.


Keep hands on the outside of steering
wheel rim. Placing hands and arms in-
side the rim can increase the risk and
potential severity of hand/arm injury
when driver front airbag inflates.


Adjust the front passenger seat as far as
possible rearward from the dashboard
when the seat is occupied.


Occupants, especially children, should
never lean their heads in the area of the
door where the side airbag inflates. This
could result in serious injuries or death
should the airbag be triggered. Always
sit upright, properly use the seat belts
and appropriate size infant or child re-
straint system.


Children 12 years old and under must
never ride in the front seat, except in a
Mercedes-Benz authorized
BabySmart
TM compatible child seat,
which operates with the BabySmart
TM
system installed in the vehicle to deacti-
vate the passenger side front airbag
when it is properly installed. Otherwise
they will be struck by the airbag when it
inflates in a crash. If this happens, seri-
ous or fatal injury will result.
Failure to follow these instructions can re-
sult in severe injuries to you or other occu-
pants.
If you sell your vehicle you are responsible
to make the buyer aware of these points. Be
sure to give the buyer this Operator’s Manu-
al.
Warning!
G
Accident research shows that the safest
place for children in an automobile is in the
rear seat. Should you choose to place a child
12 years old or under in the front passenger
seat of your vehicle, you must properly use
a BabySmart
TM child restraint which will
turn off the passenger side front airbag.
BabySmart
TM will not, however, turn off any
side impact airbag.
It should be noted that with respect to both
front and rear side impact airbags there is a
possibility for a side airbag related injury if
occupants, especially children, are not prop-
erly seated or restrained when next to a side
airbag which needs to deploy rapidly in a
side impact in order to do its job.
To help avoid the possibility of injury, please
follow these guidelines:
(1) Occupants, especially children, should never place their bodies or lean their
heads in the area of the door or rear
