147
G
ENGINE
GENERAL FEATURES
Engine code
Cycle
Number and layout of cylinders
Number of valves per cylinder
Bore x stroke mm
Capacity cc
Compression ratio
Maximum power output (EEC) kW
bhp
at rpm
Peak torque (EEC) Nm
m.kg
at rpm
TIMING
Inlet: opens BTDC
closes ABDC
Exhaust: opens BBDC
closes ATDC
Valve clearances for timing check
inlet mm
exhaust mm
Valve clearances when cold
inlet mm
exhaust mm1.2
188A4.000
Otto
4 in line
2
70.8x78.9
1242
9.5±0.2:1
44
60
5000
102
10.4
2500
2°
32°
30°
4°
0.8
0.8
0.4±0.05
0.4±0.051.2
16V
188A5.000
Otto
4 in line
4
70.8x78.9
1242
10.6±0.2:1
59
80
5000
114
11.6
4000
0°
32°
32°
0°
0.45
0.45
(*)
(*)
(*) Hydraulic tappets.
