2003 JEEP GRAND CHEROKEE low beam

JUNCTION BLOCK C2 (RHD) - BLACK 52 WAY
CAV CIRCUIT FUNCTION
1 X3 22BK/RD HORN RELAY CONTROL
2- -
3 L39 20LB FOG LAMP RELAY OUTPUT
4- -
5 L61 20TN/LG LEFT TURN SIGNAL
6- -
7- -
8 V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
9 V6 16DB (GAS) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 L62 20BR/RD RIGHT TURN SIGNAL
11 F991 20OR/DB (GAS) FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 L39 20LB FOG LAMP RELAY OUTPUT
13 - -
14 - -
15 V16 22VT -
16 - -
17 - -
18 - -
19 - -
20 L7 20BK/YL PARK LAMP RELAY OUTPUT
21 L7 18BK/YL PARK LAMP RELAY OUTPUT
22 - -
23 - -
24 F37 16RD/LB FUSED B(+)
25 F22 18WT/TN FUSED IGNITION SWITCH OUTPUT (RUN)
26 L60 20TN RIGHT TURN SIGNAL
27 F45 20YL/RD FUSED IGNITION SWITCH OUTPUT (START)
28 V55 16TN/RD WIPER PARK SWITCH SENSE
29 - -
30 - -
31 - -
32 M1 20PK/RD FUSED B(+)
33 V55 16TN/RD (GAS) WIPER PARK SWITCH SENSE
34 - -
35 - -
36 A146 12OR/WT FUSED B(+)
37 - -
38 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
39 L43 18VT FUSED LEFT LOW BEAM OUTPUT
40 - -
41 - -
42 F20 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
43 F12 20DB/WT (GAS) FUSED IGNITION SWITCH OUTPUT (RUN-START)
44 - -
45 A146 12OR/WT FUSED B(+)
46 - -
47 F32 20PK/DB FUSED B(+)
48 - -
49 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
50 L33 18RD FUSED LEFT HIGH BEAM OUTPUT
51 - -
52 F60 16RD/WT FUSED B(+)
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 89

LEFT HEADLAMP LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2 L114 18VT/DB HEADLAMP ADJUST SIGNAL
3 L7 20BK/PK PARK LAMP RELAY OUTPUT
LEFT HIGH BEAM HEADLAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A Z1 18BK GROUND
B L33 18RD FUSED LEFT HIGH BEAM OUTPUT
LEFT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X83 18YL/RD LEFT INSTRUMENT PANEL SPEAKER (+)
2 X81 18YL/BK LEFT INSTRUMENT PANEL SPEAKER (-)
LEFT LIFTGATE AJAR SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z1 20BK GROUND
2 G78 20TN/BK LIFTGATE AJAR SWITCH SENSE
LEFT LOW BEAM HEADLAMP - GRAY 2 WAY
CAV CIRCUIT FUNCTION
A Z1 18BK GROUND
B L43 18VT FUSED LEFT LOW BEAM OUTPUT
8W - 80 - 94 8W-80 CONNECTOR PIN-OUTWJ

RIGHT HIGH BEAM HEADLAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A Z1 18BK GROUND
B L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
RIGHT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X86 18OR/RD RIGHT INSTRUMENT PANEL SPEAKER (+)
2 X84 18OR/BK RIGHT INSTRUMENT PANEL SPEAKER (-)
RIGHT LIFTGATE AJAR SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z1 20BK GROUND
2 G78 20TN/BK LIFTGATE AJAR SWITCH SENSE
RIGHT LOW BEAM HEADLAMP - GRAY 2 WAY
CAV CIRCUIT FUNCTION
A Z1 18BK GROUND
B L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
RIGHT MULTI-FUNCTION SWITCH - WHITE 10 WAY
CAV CIRCUIT FUNCTION
1 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 V20 18BK/WT REAR WASHER PUMP MOTOR CONTROL
3 V10 20BR WASHER PUMP SWITCH SENSE
4- -
5 V13 18BR/LG REAR WIPER MOTOR CONTROL
6 V22 18BR/YL REAR WIPER MOTOR DELAY CONTROL
7 V9 20WT/BK WINDSHIELD WIPER SWITCH RETURN
8 V52 20DG/RD WINDSHIELD WIPER SWITCH MUX
9 V48 20RD/GY WIPER HIGH CONTROL
10 - -
8W - 80 - 116 8W-80 CONNECTOR PIN-OUTWJ

CONNECTOR NAME/
NUMBERCOLOR LOCATION FIG.
Left Front Park/Turn Signal
Lamp (Except Built-Up-Export)BK At Lamp N/S
Left Front Side Marker Lamp
(Except Built-Up-Export)WT At Lamp N/S
Left Front Turn Signal Lamp
(Built-Up-Export)WT At Lamp N/S
Left Front Wheel Speed
SensorGY At Left Front Wheel Opening 4
Left Headlamp Leveling Motor
(Built-Up-Export)BK At Motor N/S
Left High Beam Headlamp BK At Lamp N/S
Left Instrument Panel Speaker WT At Speaker 19, 20
Left Liftgate Ajar Switch BK In Liftgate 38
Left Low Beam Headlamp GY At Lamp N/S
Left Multi-Function Switch WT On Steering Column 23
Left Rear Door Lock Motor/Ajar
SwitchBK In Left Rear Door 28
Left Rear Door Speaker WT In Left Rear Door 28
Left Rear Lamp Assembly BK At Lamp Assembly 37
Left Rear Wheel Speed Sensor GY Near Left Rear Wheel 33, 35
Left Remote Radio Switch BK At Switch in Steering Wheel N/S
Left Side Impact Sensor BK Left Body N/S
Left Side Repeater Lamp
(Built-Up-Export)BK On Left Front Fender 3, 4
Left Visor/Vanity Lamp BK At Lamp N/S
License Lamp No.1 BK At Lamp N/S
License Lamp No.2 BK At Lamp N/S
Liftgate Flip-Up Ajar Switch GY In Liftgate 38
Liftgate Flip-Up Push Button
SwitchBK In Liftgate N/S
Liftgate Flip-Up Release
SolenoidBK In Liftgate 38
Liftgate Lock Motor BK In Liftgate 38
Line Pressure Sensor (4.7L) BK Rear of Transmission N/S
Manifold Absolute Pressure
Sensor (4.0L)BK At Throttle Body 9
Manifold Absolute Pressure
Sensor (4.7L)BK Right Side of Engine 13
Manual Temperature Control -
C1 (MTC)WT Center of Instrument Panel N/S
Manual Temperature Control -
C2 (MTC)WT Center of Instrument Panel N/S
Mass Air Flow sensor (Diesel) BK Near T/O for G105 8
Mode Door Motor/Actuator
(AZC)BK Right Center of Instrument Panel N/S
WJ8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 7
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

CONNECTOR NAME/
NUMBERCOLOR LOCATION FIG.
Right Front Park/Turn Signal
Lamp (Except Built-Up-Export)BK At Lamp N/S
Right Front Side Marker Lamp
(Except Built-Up-Export)WT At Lamp N/S
Right Front Turn Signal Lamp
(Built-Up-Export)WT At Lamp N/S
Right Front Wheel Speed
SensorGY In Right Front Wheel Opening N/S
Right Headlamp Leveling
Motor (Built-Up-Export)BK At Motor N/S
Right High Beam Headlamp BK At Lamp N/S
Right Instrument Panel
SpeakerWT At Speaker 19, 20
Right Liftgate Ajar Switch BK In Liftgate 38
Right Low Beam Headlamp GY At Lamp N/S
Right Multi-Function Switch WT On Steering Column 23
Right Rear Door Lock
Motor/Ajar SwitchBK In Right Rear Door 29
Right Rear Door Speaker WT In Right Rear Door 29
Right Rear Lamp Assembly BK At Lamp Assembly 37
Right Rear Wheel Speed
SensorBK Near Right Rear Wheel 33, 35
Right Remote Radio Switch BK At Switch in Steering Wheel N/S
Right Side Repeater Lamp
(Built-Up-Export)BK On Right Front Fender 5
Right Visor/Vanity Lamp BK At Lamp N/S
Seat Belt Switch WT At Driver Seat N/S
Seat Module - C1 (Premium) BK Under Driver Seat N/S
Seat Module - C2 (Premium) OR Under Driver Seat N/S
Sentry Key Immobilizer Module BK On Steering Column 23
Shifter Assembly (Gas) WT Between Front Seats 23
Shifter Assembly C1 (Diesel) Between Front Seats N/S
Shifter Assembly C2 (Diesel) Between Front Seats N/S
Siren (Built-up-export) Left Front Fender 3, 4
Speed Control Switch NO. 1 BK On Steering Wheel N/S
Speed Control Switch NO. 2 BK On Steering Wheel N/S
Sunroof Control Module At Sunroof 32
Sunroof Motor C1 WT At Sunroof N/S
Sunroof Motor C2 BK In Overhead N/S
Sunroof Switch GY At Switch N/S
Temperature Valve Actuator
(MTC)BK On HVAC Housing N/S
Throttle Position Sensor (4.0L) BK Left Side of Engine 9
Throttle Position Sensor (4.7L) WT Left Side of Engine 13
8W - 91 - 10 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONWJ
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
