Police records show that almost half of all motor
vehicle-related deaths involve alcohol. In most cases,
these deaths are the result of someone who was
drinking and driving. In recent years, more than
16,000 annual motor vehicle-related deaths have been
associated with the use of alcohol, with more than
300,000 people injured.
Many adults—by some estimates, nearly half the adult
population—choose never to drink alcohol, so they
never drive after drinking. For persons under 21,
it’s against the law in every U.S. state to drink alcohol.
There are good medical, psychological and
developmental reasons for these laws.
The obvious way to eliminate the leading highway
safety problem is for people never to drink alcohol and
then drive. But what if people do? How much is“too
much”if someone plans to drive? It’s a lot less
than many might think. Although it depends on each
person and situation, here is some general information
on the problem.
The Blood Alcohol Concentration (BAC) of someone
who is drinking depends upon four things:
The amount of alcohol consumed
The drinker’s body weight
The amount of food that is consumed before and
during drinking
The length of time it has taken the drinker to
consume the alcohol.According to the American Medical Association,
a 180 lb (82 kg) person who drinks three 12 ounce
(355 ml) bottles of beer in an hour will end up with a
BAC of about 0.06 percent. The person would reach the
same BAC by drinking three 4 ounce (120 ml) glasses
of wine or three mixed drinks if each had 1-1/2 ounces
(45 ml) of liquors like whiskey, gin or vodka.
4-3
2003 - Safari OM

When to Check Power Steering Fluid
It is not necessary to regularly check power steeringfluid
unless you suspect there is a leak in the system or
you hear an unusual noise. Afluid loss in this system
could indicate a problem. Have the system inspected
and repaired. SeeEngine Compartment Overview
on page 5-12for reservoir location.
How to Check Power Steering Fluid
Turn the key off, let the engine compartment cool down,
wipe the cap and the top of the reservoir clean, then
unscrew the cap and wipe the dipstick with a clean rag.
Replace the cap and completely tighten it. Then
remove the cap again and look at thefluid level on the
dipstick.
The level should be at the FULL COLD mark. If
necessary, add only enoughfluid to bring the level up to
the mark.
What to Use
To determine what kind offluid to use, seePart D:
Recommended Fluids and Lubricants on page 6-34.
Always use the properfluid. Failure to use the proper
fluid can cause leaks and damage hoses and seals.
Windshield Washer Fluid
What to Use
When you need windshield washerfluid, be sure to read
the manufacturer’s instructions before use. If you will
be operating your vehicle in an area where the
temperature may fall below freezing, use afluid that has
sufficient protection against freezing.
5-37
2003 - Safari OM

At Least Once a Year
Key Lock Cylinders Service
Lubricate the key lock cylinders with the lubricant
specied in Part D.
Body Lubrication Service
Lubricate all body door hinges, the body hood, fuel door
and rear compartment hinges, latches and locks
including interior glove box and console doors, hood
latch assembly, secondary latch, pivots, spring anchor,
release pawl and any moving seat hardware. Lubricate
the hood safety lever pivot and prop rod pivot. Part
D tells you what to use. More frequent lubrication may
be required when exposed to a corrosive environment.
Starter Switch Check
{CAUTION:
When you are doing this check, the vehicle
could move suddenly. If it does, you or others
could be injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake and the regular
brake. SeeParking Brake on page 2-26if
necessary.
Do not use the accelerator pedal, and be ready to
turn off the engine immediately if it starts.
3. Try to start the engine in each gear. The starter
should work only in PARK (P) or NEUTRAL (N).
If the starter works in any other position, your
vehicle needs service.
6-29
2003 - Safari OM

Automatic Transmission Shift Lock
Control System Check
{CAUTION:
When you are doing this check, the vehicle
could move suddenly. If it does, you or others
could be injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle. It should be parked on a level
surface.
2. Firmly apply the parking brake. SeeParking Brake
on page 2-26if necessary.
Be ready to apply the regular brake immediately if
the vehicle begins to move.3. With the engine off, turn the key to the RUN
position, but don’t start the engine. Without applying
the regular brake, try to move the shift lever out
of PARK (P) with normal effort. If the shift lever
moves out of PARK (P), your vehicle needs service.
Ignition Transmission Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to LOCK in each shift lever position.
The key should turn to LOCK only when the
shift lever is in PARK (P).
The key should come out only in LOCK.
6-30
2003 - Safari OM

Part D: Recommended Fluids and
Lubricants
Fluids and lubricants identied below by name, part
number or specication may be obtained from your
dealer.
Usage Fluid/Lubricant
Engine OilEngine oil with the American
Petroleum Institute Certied for
Gasoline Engines starburst symbol
of the proper viscosity. To
determine the preferred viscosity for
your vehicle’s engine, seeEngine
Oil on page 5-13.
Engine Coolant50/50 mixture of clean, drinkable
water and use only
DEX-COOL
®Coolant. SeeEngine
Coolant on page 5-25.
Hydraulic Brake
SystemDelco Supreme 11 Brake Fluid or
equivalent DOT-3 brakeuid.
Windshield
Washer SolventGM Optikleen
®Washer Solvent or
equivalent.
Usage Fluid/Lubricant
Parking Brake
Cable GuidesChassis Lubricant (GM Part No.
U.S. 12377985, in Canada
88901242, or equivalent) or
lubricant meeting requirements of
NLGI #2, Category LB or GC-LB.
Power Steering
SystemGM Power Steering Fluid (GM Part
No. U.S. 1052884, in Canada
993294, or equivalent).
Automatic
TransmissionDEXRON
®-III Automatic
Transmission Fluid.
Key Lock
CylindersMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474, or equivalent).
Chassis
LubricationChassis Lubricant (GM Part No.
U.S. 12377985, in Canada
88901242, or equivalent) or
lubricant meeting requirements of
NLGI #2, Category LB or GC-LB.
Front Wheel
BearingsWheel bearing lubricant meeting
requirements of NLGI #2, Category
GC or GC-LB (GM Part No. U.S.
1051344, in Canada 993037, or
equivalent).
6-34
2003 - Safari OM

Roadside Assistance Program
GMC’s Roadside Assistance Provides stranded owners
with over-the-phone roadside repairs, location of the
nearest GMC dealer or the following special services:
Flat Tire Change:Installation of spare tire will be covered
at no charge (customer is responsible for repair or
replacement of tire).
Fuel Delivery:Delivery of enough fuel for the customer
to get to the nearest service station (up to $5.00)
will be covered.
Jump Start:No-start situations which require a battery
jump start will be covered at no charge.
Lock Out:Replacement keys or locksmith service will be
covered at no charge if you are unable to gain entry
into your vehicle. Delivery of the replacement key will be
covered within 10 miles (16 km).
Emergency Towing Service:Towing to the nearest GMC
dealer for warranty related disablements will be covered.
Trip Routing:Custom-made, computerized highlighted
maps using the most direct or scenic route are provided
free of charge. Maps include points of interest and a
list of GMC dealers along the route. Also included is a
list of hotels along the route that are discounted
through affiliation with“Quest International.”Trip Routing
is available through Roadside Assistance by calling
1-800-GMC-8782 (462-8782). Please be prepared to
provide your Vehicle Identication Number (VIN). Allow
ve working days for fulllment.Trip Interruption Assistance:GMC will reimburse any
reasonable trip interruption expenses (up to $500.00)
when directly associated with warranty disablement. Trip
interruption service covers expenses such as meals
and overnight lodging if vehicle disablement occurs at
least 150 miles (240 km) from your home or rental
property. You will be required to obtain prior approval
from GMC Roadside Assistance and pay for expenses
at the time of disablement. Original receipts should
be submitted to GMC Roadside Assistance for
reimbursement. A service representative will provide
assistance when you call.
The Roadside Assistance services listed are available to
retail lease customers operating 2003 GMC light duty
trucks for a period of 3 years/36,000 miles (60,000 km).
All services must be pre-arranged by GMC Roadside
Assistance.
Over-the-phone assistance, such as providing the name
of the closest dealer or minor technical advice, etc.,
is available to all owner/operators of GMC trucks,
regardless of vehicle or mileage.
Just dial GMC Roadside Assistance at 1-800-GMC-8782
(1-800-462-8782, Roadside Assistance prompt) to
reach a qualied representative who can assist you.
Text telephone (TTY) users, call 1-888-889-2438.
7-6
2003 - Safari OM

K
Key Lock Cylinders Service..............................6-29
Keyless Entry System....................................... 2-4
Keys............................................................... 2-2
L
Lamps
Exterior......................................................3-12
Interior.......................................................3-15
Lamps On Reminder.......................................3-13
Lap Belt........................................................1-27
Lap-Shoulder Belt...................................1-19, 1-29
LATCH System
Child Restraints...........................................1-52
Securing a Child Restraint Designed for the
LATCH System........................................1-54
Latches, Seatback............................................ 1-6
Leaving Your Vehicle.......................................2-10
Leaving Your Vehicle With the Engine
Running.....................................................2-28
Light
Air Bag Readiness.......................................3-26
Anti-Lock Brake System Warning...................3-29
Brake System Warning.................................3-28Light (cont.)
Charging System.........................................3-27
Check Gages Warning.................................3-35
Low Fuel Warning.......................................3-36
Malfunction Indicator....................................3-30
Safety Belt Reminder
...................................3-25
Security
.....................................................3-34
Service All-Wheel-Drive
................................3-34
Tow/Haul Mode
...........................................3-35
Loading Your Vehicle
.......................................4-29
Locking Rear Axle
............................................ 4-8
Locks
Door
........................................................... 2-7
Front Doors
.................................................. 2-8
Leaving Your Vehicle
....................................2-10
Power Door
.................................................. 2-8
Programmable Automatic Door Locks
............... 2-9
Long Trip/Highway Definition
.............................. 6-6
Long Trip/Highway Intervals
............................... 6-6
Long Trip/Highway Scheduled Maintenance
........6-19
Loss of Control
...............................................4-13
Low Fuel Warning Light
...................................3-36
Luggage Carrier
..............................................2-45
Lumbar
Manual Controls
............................................ 1-3
8
2003 - Safari OM

R
Radiator Pressure Cap....................................5-27
Radios..........................................................3-37
AM-FM Radio.............................................3-38
Care of Your CD Player...............................3-49
Care of Your CDs ........................................3-49
Radio with CD............................................3-40
Rear Seat Audio..........................................3-45
Setting the Time for Radios with HR and
MN Buttons.............................................3-37
Setting the Time for Radios with the Set
Button....................................................3-37
Theft-Deterrent............................................3-46
Understanding Reception..............................3-49
Reading Lamps..............................................2-40
Rear Air Conditioning System...........................3-20
Rear Axle......................................................5-49
Locking........................................................ 4-8
Rear Climate Control System............................3-21
Rear Doors....................................................2-13
Rear Heating System......................................3-19
Rear Safety Belt Comfort Guides......................1-32
Rear Seat Audio (RSA)....................................3-45
Rear Seat Operation......................................... 1-7
Rear Seat Outside Passenger Positions.............1-29
Rear Seat Passengers, Safety Belts..................1-29
Rear Window Defogger....................................3-21Rearview Mirrors.............................................2-32
Reclining Seatbacks.......................................... 1-4
Recreational Vehicle Towing.............................4-29
Reinstalling the Engine Cover...........................5-21
Remote Keyless Entry System............................ 2-4
Remote Keyless Entry System, Operation............ 2-5
Removing the Engine Cover.............................5-17
Removing the Flat Tire and Installing the
Spare Tire..................................................5-70
Removing the Rear Seats.................................. 1-7
Removing the Spare Tire and Tools...................5-66
Removing the Wheel Covers............................5-69
Replacement Bulbs.........................................5-56
Replacing Brake System Parts
..........................5-42
Replacing Restraint System Parts After
a Crash
.....................................................1-69
Replacing the Rear Seats
.................................. 1-9
Reporting Safety Defects
Canadian Government
..................................7-10
General Motors
...........................................7-10
United States Government
.............................. 7-9
Reprogramming a Single HomeLink
®Button
.......2-37
Resetting Defaults
...........................................2-37
Restraint System Check
...................................6-28
Checking Your Restraint Systems
...................1-68
Replacing Restraint System Parts After
a Crash
..................................................1-69
11
2003 - Safari OM
