8W-40 INSTRUMENT CLUSTER
Component Page
Airbag Control Module................ 8W-40-2
Body Control Module . . . 8W-40-2, 3, 4, 5, 6, 7, 8, 9,
10, 12, 13
Brake Fluid Level Switch............. 8W-40-10
Clockspring........................ 8W-40-11
Controller Antilock Brake.......... 8W-40-11, 15
Engine Control Module.......... 8W-40-9, 11, 15
Engine Coolant Temp Sensor....... 8W-40-7, 8, 9
Engine Oil Pressure Sensor........... 8W-40-15
Engine Oil Pressure Switch........... 8W-40-15
Front Control Module....... 8W-40-10, 11, 14, 15
Fuel Pump Module................... 8W-40-2
Fuse 24............................ 8W-40-2
G200..................... 8W-40-2, 12, 13, 14
G300............................. 8W-40-10
Instrument Cluster...... 8W-40-2, 3, 4, 5, 6, 7, 8,
9, 10, 12, 13, 14
Integrated Power Module........ 8W-40-2, 7, 8, 9,
10, 11, 14, 15
Left Front Door Ajar Switch............ 8W-40-3
Left Front Door Lock Motor/Ajar Switch . . 8W-40-3
Left Sliding Door Control Module........ 8W-40-4Component Page
Left Sliding Door Latch Sensing Switch . . . 8W-40-4
Left Sliding Door Lock Motor/Ajar
Switch.......................... 8W-40-4
Left Speed Control Switch............ 8W-40-11
Liftgate Ajar Switch.................. 8W-40-3
Liftgate Cinch/Release Motor........... 8W-40-3
Message Center.................. 8W-40-6, 14
Multi- Function Switch................ 8W-40-6
Parking Brake Switch............. 8W-40-12, 13
Powertrain Control Module..... 8W-40-7, 8, 11, 15
Right Front Door Ajar Switch........... 8W-40-3
Right Front Door Lock Motor/Ajar
Switch.......................... 8W-40-3
Right Sliding Door Control Module...... 8W-40-5
Right Sliding Door Latch Sensing Switch . . 8W-40-5
Right Sliding Door Lock Motor/Ajar
Switch.......................... 8W-40-5
Traction Control Switch........... 8W-40-7, 8, 9
Transmission Control Module........... 8W-40-8
Vehicle Speed Sensor............... 8W-40-7, 9
Washer Fluid Level Switch............ 8W-40-10
RS8W-40 INSTRUMENT CLUSTER8W-40-1
ProCarManuals.com
Page 810 of 2177
8W-42 AIR CONDITIONING-HEATER
Component Page
A/C Compressor Clutch......... 8W-42-14, 16, 19
A/C Compressor Clutch Relay.... 8W-42-14, 16, 19
A/C Pressure Sensor........... 8W-42-14, 16, 19
A/C-Heater Control............. 8W-42-2, 3, 4, 5
A/C-Heater Control................... 8W-42-7
ATC Remote Sensor................. 8W-42-11
Auto Temp Control..... 8W-42-8, 9, 10, 11, 12, 13
Battery........................... 8W-42-17
Blower Motor Resistor................ 8W-42-2
Body Control Module.......... 8W-42-4, 7, 9, 13
Driver Blend Door Actuator......... 8W-42-5, 10
ECM/PCM Relay................... 8W-42-17
Engine Control Module............ 8W-42-16, 17
Evaporator Temperature Sensor...... 8W-42-5, 10
Front Blower Module................ 8W-42-11
Front Blower Motor............... 8W-42-2, 11
Front Blower Motor Relay.......... 8W-42-2, 11
Front Control Module......... 8W-42-2, 6, 11, 12
Fuse 10......................... 8W-42-2, 11
Fuse 12......................... 8W-42-6, 12
Fuse 14............................ 8W-42-8
Fuse 16........................... 8W-42-17
Fuse 18..................... 8W-42-14, 16, 19
Fuse 27..................... 8W-42-15, 18, 20
Fuselink.......................... 8W-42-17
G102....................... 8W-42-15, 18, 20Component Page
G103....................... 8W-42-14, 16, 19
G200.............. 8W-42-2, 3, 4, 6, 8, 9, 11, 12
G300........................... 8W-42-7, 13
G302............................. 8W-42-12
Integrated Power Module....... 8W-42-2, 6, 8, 11,
12, 14, 15, 16, 17, 18, 19, 20
Mode Door Actuator............... 8W-42-5, 10
Passenger Blend Door Actuator...... 8W-42-5, 10
Powertrain Control Module . . . 8W-42-14, 15, 19, 20
Radiator Fan No. 1......... 8W-42-15, 17, 18, 20
Radiator Fan No. 2............ 8W-42-15, 18, 20
Radiator Fan Relay............... 8W-42-15, 20
Radiator Fan Relay No. 1.......... 8W-42-17, 18
Radiator Fan Relay No. 2............. 8W-42-18
Radiator Fan Relay No. 3............. 8W-42-18
Rear A/C-Heater Unit............... 8W-42-6, 7
Rear Auto Temp Control Switch........ 8W-42-13
Rear Blower Front Control Switch....... 8W-42-6
Rear Blower Motor.................. 8W-42-12
Rear Blower Motor Power Module...... 8W-42-12
Rear Blower Motor Relay........... 8W-42-6, 12
Rear Blower Rear Control Switch...... 8W-42-6, 7
Rear Mode Motor................... 8W-42-12
Rear Temperature Motor............. 8W-42-12
Recirculation Door Actuator......... 8W-42-5, 10
RS8W-42 AIR CONDITIONING-HEATER8W-42-1
ProCarManuals.com
Page 886 of 2177
8W-49 OVERHEAD CONSOLE
Component Page
Ambient Temperature Sensor........... 8W-49-2
Automatic Day/Night Mirror......... 8W-49-3, 4
Body Control Module............. 8W-49-2, 3, 4
Front Control Module................. 8W-49-2
Front Reading Lamps/Switch........... 8W-49-4
Fuse 14............................ 8W-49-2Component Page
G301.............................. 8W-49-4
Integrated Power Module.............. 8W-49-2
Left Power Mirror................... 8W-49-3
Overhead Console................ 8W-49-2, 3, 4
Powertrain Control Module............ 8W-49-2
RS8W-49 OVERHEAD CONSOLE8W-49-1
ProCarManuals.com
Page 985 of 2177
Component Page
Liftgate Cinch/Release Motor (Power
Liftgate)........................ 8W-80-92
Liftgate Cylinder Lock Switch (Export) . . 8W-80-92
Liftgate Left Pinch Sensor (Power
Liftgate)........................ 8W-80-92
Liftgate Right Pinch Sensor (Power
Liftgate)........................ 8W-80-92
Low Note Horn..................... 8W-80-92
Manifold Absolute Pressure Sensor (Gas) . 8W-80-93
Mass Air Flow Sensor (Diesel)......... 8W-80-93
Memory Seat/Mirror Module C1........ 8W-80-93
Memory Seat/Mirror Module C2........ 8W-80-94
Memory Seat/Mirror Module C3........ 8W-80-94
Memory Seat/Mirror Module C4........ 8W-80-94
Memory Set Switch................. 8W-80-95
Message Center (Highline)............ 8W-80-95
Mode Door Actuator (ATC)............ 8W-80-95
Mode Door Actuator (MTC)........... 8W-80-95
Multi-Function Switch............... 8W-80-96
Natural Vacuum Leak Detection Assembly
(2.4L Except Export)............... 8W-80-96
Output Speed Sensor (EATX).......... 8W-80-96
Overhead Console (Except Base)....... 8W-80-96
Oxygen Sensor 1/1 Upstream (Gas)..... 8W-80-97
Oxygen Sensor 1/2 Downstream (Gas) . . . 8W-80-97
Passenger Airbag................... 8W-80-97
Passenger Blend Door Actuator (ATC) . . . 8W-80-97
Passenger Blend Door Actuator (MTC) . . . 8W-80-98
Passenger Door Courtesy Lamp........ 8W-80-98
Passenger Door Lock Switch........... 8W-80-98
Passenger Folding Mirror Relay (Export) . 8W-80-98
Passenger Heated Seat Back.......... 8W-80-99
Passenger Heated Seat Cushion........ 8W-80-99
Passenger Heated Seat Module C1...... 8W-80-99
Passenger Heated Seat Module C2...... 8W-80-99
Passenger Heated Seat Module C3..... 8W-80-100
Passenger Power Seat Front Riser
Motor......................... 8W-80-100
Passenger Power Seat Horizontal
Motor......................... 8W-80-100
Passenger Power Seat Rear Riser
Motor......................... 8W-80-100
Passenger Power Seat Recliner Motor . . 8W-80-100
Passenger Power Seat Switch......... 8W-80-101
Passenger Power Window Motor....... 8W-80-101
Passenger Power Window Switch...... 8W-80-101
Passenger Seat Belt Switch.......... 8W-80-101
Passenger Seat Belt Tensioner........ 8W-80-102
Power Folding Mirror Switch (Export) . . 8W-80-102
Power Liftgate Module C1........... 8W-80-102
Power Liftgate Module C2........... 8W-80-103
Power Liftgate Motor............... 8W-80-103
Power Mirror Switch............... 8W-80-104
Power Outlet (Except Lowline)........ 8W-80-104
Power Seat Circuit Breaker (30A)..... 8W-80-104Component Page
Power Window Circuit Breaker (25A) . . . 8W-80-104
Power Window Switch (LHD Lowline) . . 8W-80-105
Powertrain Control Module C1 (NGC) . . 8W-80-105
Powertrain Control Module C1
(SBEC)........................ 8W-80-106
Powertrain Control Module C2 (NGC) . . 8W-80-107
Powertrain Control Module C2 (SBEC) . 8W-80-108
Powertrain Control Module C3 (NGC) . . 8W-80-109
Powertrain Control Module C4 (NGC)
(EATX) ........................ 8W-80-110
Radiator Fan No. 1 (Diesel).......... 8W-80-111
Radiator Fan No. 1 (Gas)............ 8W-80-111
Radiator Fan No. 2 (Diesel).......... 8W-80-111
Radiator Fan No. 2 (Gas)............ 8W-80-111
Radiator Fan Relay (Gas)............ 8W-80-112
Radiator Fan Relay No. 1 (Diesel)..... 8W-80-112
Radiator Fan Relay No. 2 (Diesel)..... 8W-80-112
Radiator Fan Relay No. 3 (Diesel)..... 8W-80-113
Radio C1......................... 8W-80-113
Radio C2 (CD Changer)............. 8W-80-114
Radio C2 (DVD/CD Changer)......... 8W-80-114
Rear A/C-Heater Unit (3 Zone MTC).... 8W-80-114
Rear Auto Temp Control Switch
(3 Zone ATC).................... 8W-80-115
Rear Blower Front Control Switch
(3 Zone MTC)................... 8W-80-115
Rear Blower Motor Power Module C1
(3 Zone ATC).................... 8W-80-115
Rear Blower Motor Power Module C2
(3 Zone ATC).................... 8W-80-116
Rear Blower Rear Control Switch C1
(3 Zone MTC)................... 8W-80-116
Rear Blower Rear Control Switch C2
(3 Zone MTC)................... 8W-80-116
Rear Dome Lamp (Except Luxury)..... 8W-80-116
Rear Intrusion Sensor (United
Kingdom)...................... 8W-80-117
Rear Mode Motor (3 Zone ATC)........ 8W-80-117
Rear Power Outlet................. 8W-80-117
Rear Temperature Motor (3 Zone ATC) . . 8W-80-117
Rear Washer Pump Motor............ 8W-80-118
Rear Wiper Motor.................. 8W-80-118
Recirculation Door Actuator (ATC)..... 8W-80-118
Recirculation Door Actuator (MTC)..... 8W-80-118
Remote Keyless Entry Antenna
(Japan)........................ 8W-80-119
Remote Keyless Entry Module........ 8W-80-119
Right B-Pillar Switch (Power Sliding
Door).......................... 8W-80-119
Right Cinch/Release Motor
(Power Sliding Door).............. 8W-80-119
Right Combination Relay
(Trailer Tow).................... 8W-80-120
Right Cylinder Lock Switch (Export) . . . 8W-80-120
Right Door Speaker (Lowline)......... 8W-80-120
8W - 80 - 4 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com
Page 998 of 2177
C100 - BLACK (POWERTRAIN SIDE)
CAV CIRCUIT
1 D21 18WT/BR
2 D123 20WT/BR (2.4L EATX)
2 D123 20WT/OR (3.3L/3.8L)
3 K119 20DB/LG (DIESEL)
3 D20 20WT/LG (GAS)
5 Z111 20BK/WT (3.3L/3.8L EXCEPT
EXPORT/2.4L)
5 Z111 18BK/WT (3.3L/3.8L EXPORT/
DIESEL)
6 N1 18DB/OR (DIESEL)
7 N2 18DB/YL (DIESEL)
7 D15 18DG/YL (2.4L)
7 D15 20DG/YL (3.3L/3.8L)
8 V32 18VT/YL (GAS)
8 K22 20OR/DB (DIESEL)
9 B29 20DG/WT (DIESEL)
9 B29 18DG/WT (GAS)
10 V37 18VT (GAS)
10 V37 20VT/TN (DIESEL)
11 V30 20VT/WT (GAS)
12 K900 20DB/DG (GAS)
12 K900 18DB/DG (DIESEL)
13 B1 18DG/OR (ANTILOCK BRAKES)
14 B2 18DG/LB (ANTILOCK BRAKES)
C101 - LT. GRAY (BODY SIDE)
CAV CIRCUIT
1 L50 18WT/TN
2-
3 F853 20LG/PK (DIESEL)
4-
5 B4 18DG/GY (ANTILOCK BRAKES)
6 B3 18DG/YL (ANTILOCK BRAKES)
7 F500 18DG/PK
8 K4 20BK/LB (DIESEL)
9 F852 20VT/PK (DIESEL)
9 T55 18YL/VT (AUTOSTICK)
10 K151 20WT (DIESEL)
RS8W-80 CONNECTOR PIN-OUTS8W-80-17
ProCarManuals.com
Page 999 of 2177
C101 - LT. GRAY (POWERTRAIN SIDE)
CAV CIRCUIT
1 L50 18WT/TN (GAS)
1 L50 20WT/TN (DIESEL)
2-
3 F853 20LG/PK (DIESEL)
4-
5 B4 18DG/GY (ANTILOCK BRAKES)
6 B3 18DG/YL (ANTILOCK BRAKES)
7 F500 18DG/PK
8 K4 20BK/LB (DIESEL)
9 K853 20DB/BR (DIESEL)
9-
10 K151 20WT (DIESEL)
C102 (2.4L) - BLACK (FUEL RAIL SIDE)
CAV CIRCUIT
1 K11 16BR/YL
2 K12 16BR/DB
3 K13 16BR/LB
4 K14 16BR/TN
5 K342 16BR/WT
6 K900 18DB/DG
7 K2 18VT/OR
8 K1 18VT/BR
9-
10 F855 18PK/YL
C102 (2.4L) - BLACK (POWERTRAIN SIDE)
CAV CIRCUIT
1 K11 16BR/YL
2 K12 16BR/DB
3 K13 16BR/LB
4 K14 16BR/TN
5 K342 16BR/WT
6 K900 18DB/DG
7 K2 18VT/OR
8 K1 18VT/BR
9-
10 F855 20PK/YL
8W - 80 - 18 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com
Page 1000 of 2177
C102 (3.3L/3.8L) - BLACK (FUEL RAIL SIDE)
CAV CIRCUIT
1 K342 16BR/WT
2 K1 18VT/BR
3 K11 16BR/YL
4 K12 16BR/DB
5 K13 16BR/LB
6 K14 16BR/TN
7 K900 18DB/DG
8 K38 16BR/OR
9 K58 16BR/VT
10 F855 18PK/YL
C102 (3.3L/3.8L) - BLACK (POWERTRAIN SIDE)
CAV CIRCUIT
1 K342 16BR/WT
2 K1 18VT/BR
3 K11 16BR/YL
4 K12 16BR/DB
5 K13 16BR/LB
6 K14 16BR/TN
7 K900 18DB/DG
8 K38 16BR/OR
9 K58 16BR/VT
10 F855 18PK/YL (EXPORT)
10 F855 20PK/YL (EXCEPT EXPORT)
C103 (DIESEL) - BLACK (FRONT END LIGHTING
SIDE)
CAV CIRCUIT
1 K342 16BR/WT
2 K342 16BR/WT
3 N122 20DB/YL
4 N210 18DB/DG
5 A201 12RD/LG
6-
RS8W-80 CONNECTOR PIN-OUTS8W-80-19
ProCarManuals.com
Page 1001 of 2177
C103 (DIESEL) - BLACK (POWERTRAIN SIDE)
CAV CIRCUIT
1 K342 16BR/WT
2 K342 16BR/WT
3 N122 20DB/YL
4 N210 20DB/DG
5 A201 12RD/LG
6-
C106 (EXPORT) - BLACK (FRONT END LIGHTING
SIDE)
CAV CIRCUIT
1 L43 18WT/DB
2 L33 18WT/LG
3 L77 18WT/BR
4 L61 16WT/LG
5 Z343 18BK/LG
6 L13 20WT/YL
7 Z203 20BK/YL
8 Z377 18BK/BR
C106 (EXPORT) - BLACK/YELLOW (COMPONENT
SIDE)
CAV CIRCUIT
1 L43 16WT
2 L33 16GY
3 L77 16BK
4 L61 16YL
5 Z343 16BR
6 L13 16RD
7 Z203 16BR
8-
C107 (EXPORT) - BLACK (FRONT END LIGHTING
SIDE)
CAV CIRCUIT
1 L44 16WT/TN
2 L34 16WT/GY
3 L78 18WT/OR
4 L60 16WT/TN
5 Z344 16BK/TN
6 L13 20WT/YL
7 Z203 20BK/YL
8 Z378 18BK/LB (GAS)
8 Z378 18BK/TN (DIESEL)
8W - 80 - 20 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com
