2003 CHRYSLER CONCORDE spark plugs replace

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
158,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-33-01 3N.
Maint enance Service Sc hedule ÒBÓ
158,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace if necessary (Minivan, Concorde,Intrepid and 300M only).
l Replace the spark plugs (Concorde, Intrepid and 300M only).
l Flush and replace engine coolant at 60 months or 160,000 kilometres.
l Replace the engine timing belt (Concorde, Intrepid and 300M only).
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (all except Sebring and Sebring Convertible).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
03Minivan and Car Maint 1/15/03 9:55 AM Page 95

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l nspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace ifnecessary (Minivan, Concorde, Intrepid and 300M only).
l Replace the spark plugs (Concorde, Intrepid and 300Monly).
l Flush and replace engine coolant at 60 months or160,000 kilometres.
l Replace the engine timing belt (Concorde, Intrepid and300M only).
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (all except Sebring and Sebring Convertible).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plugcondition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
158,0 00 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 96

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
168,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-35-01 3N.
Maint enance Service Sc hedule ÒBÓ
168,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible only).
l Inspect and replace, if required, the air cleaner element (PT Cruiser and Neon only).
l Replace the engine air cleaner filter if required (Minivan, Concorde, Intrepid and 300M only).
l Replace the spark plugs (2.7L Sebring and Sebring Convertible only).
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (Neon and PT Cruiser only).
l Replace the accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Inspect the generator belt, replace if necessary (2.4L Minivan only).
l Inspect and adjust the power steering pump belt tension (2.4L Minivan only).
l Replace the engine timing belt (2.4L PT Cruiser only).
l Change the all-wheel-drive power transfer unit fluid (Minivan only).*
l Change the all-wheel-drive overrunning clutch and rear carrier fluid (Minivan only).*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% atsustained high speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow or commercial service.
03Minivan and Car Maint 1/15/03 9:55 AM Page 99

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible only).
l Inspect and replace, if required, the air cleaner element (PT Cruiser and Neon only).
l Replace the engine air cleaner filter if required (Minivan,Concorde, Intrepid and 300M only).
l Replace the spark plugs (2.7L Sebring and Sebring Convertibleonly).
l Inspect and replace, if required, the make-up air filter locatedinside the air cleaner (Neon and PT Cruiser only).
l Check and retention accessory drive belts (2.7L Sebring, SebringConvertible only).
l Inspect the generator belt, replace if necessary (2.4L Minivan only).
l Inspect and adjust the power steering pump belt tension (2.4LMinivan only).
l Replace the engine timing belt (2.4L PT Cruiser only).
l Change the all-wheel-drive power transfer unit fluid (Minivan only).*
l Change the all-wheel-drive overrunning clutch and rear carrierfluid (Minivan only).*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals thanshown in Schedule B if the vehicle is operated more than 50% at sustainedhigh speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow
or commercial service.Maint enance Service Sc hedule ÒBÓ
168,0 00 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 100

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
192,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-40-01 3N.
Maint enance Service Sc hedule ÒBÓ
1 92,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Replace the engine air cleaner filter if required (all models).
l Replace the air conditioning filter (Minivan only).
l Replace the ignition cables (2.4L).
l Replace the spark plugs (2.4L).
l Inspect the PCV valve and replace as necessary.
l Replace the make-up air filter located inside the air cleaner (Neon and PT Cruiser only).
l Replace drive belts (Concorde, Intrepid and 300M only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Replace the accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Inspect the generator belt, replace if necessary (2.4L Minivan only).
l Inspect and adjust the power steering pump belt tension (2.4L Minivan only).
l Inspect the serpentine drive belt, replace if necessary (Minivan 3.3L and 3.8L only).
l Replace power steering fluid (Concorde, Intrepid and 300M only)..
l Change the all-wheel-drive power transfer unit fluid (Minivan only).*
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Minivan, Neon and PT Cruiser only).
l Inspect the front and rear brake linings and components (Sebring and Sebring Convertible only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% at sustained high speeds during hotweather, above 32 ¡C (90 ¡F) or if used for trailer tow or commercial service.
03Minivan and Car Maint 1/15/03 9:55 AM Page 109

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Replace the engine air cleaner filter if required (all models).
l Replace the air conditioning filter (Minivan only).
l Replace the ignition cables (2.4L).
l Replace the spark plugs (2.4L).
l Inspect the PCV valve and replace as necessary.
l Replace the make-up air filter located inside the air cleaner (Neon and PT Cruiser only).
l Replace drive belts (Concorde, Intrepid and 300M only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Replace the accessory drive belts (2.7L Sebring, Sebring Convertibleonly).
l Inspect the generator belt, replace if necessary (2.4L Minivan only).
l Inspect and adjust the power steering pump belt tension (2.4L Minivanonly).
l Inspect the serpentine drive belt, replace if necessary (Minivan 3.3Land 3.8L only).
l Replace power steering fluid (Concorde, Intrepid and 300M only).
l Change the all-wheel-drive power transfer unit fluid (Minivan only).*
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Minivan, Neon and PT Cruiser only).
l Inspect the front and rear brake linings and components (Sebring andSebring Convertible only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals thanshown in schedule B if the vehicle is operated more than 50% at sustainedhigh speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow
or commercial service.Maint enance Service Sc hedule ÒBÓ
1 92,0 00 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 110

Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
240,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-50-01 3N.
Maint enance Service Sc hedule ÒBÓ
240,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Replace the engine air cleaner filter if required (all models).
l Replace the ignition cables (3.3 and 3.8L only).
l Replace the spark plugs (2.4L).
l Replace the spark plugs (3.3, 3.8L).
l Inspect the PCV valve and replace as necessary.
l Replace the make-up air filter located inside the air cleaner (Neon and PT Cruiser only).
l Adjust the generator belt tension (Neon and PT Cruiser only).
l Inspect the generator belt, replace if necessary (2.4L Minivan only).
l Inspect and adjust the power steering pump belt tension (2.4L Minivan only).
l Change the all-wheel-drive power transfer unit fluid (Minivan only).*
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Minivan, Neon and PT Cruiser only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% atsustained high speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow or commercial service.
03Minivan and Car Maint 1/15/03 9:55 AM Page 129

Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Replace the engine air cleaner filter if required (all models).
l Replace the ignition cables (3.3 and 3.8L only).
l Replace the spark plugs (2.4L).
l Replace the spark plugs (3.3, 3.8L).
l Inspect the PCV valve and replace as necessary.
l Replace the make-up air filter located inside the air cleaner (Neonand PT Cruiser only).
l Adjust the generator belt tension (Neon and PT Cruiser only).
l Inspect the generator belt, replace if necessary (2.4L Minivanonly).
l Inspect and adjust the power steering pump belt tension (2.4LMinivan only).
l Change the all-wheel-drive power transfer unit fluid (Minivanonly).*
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the tie rod ends and boot seals (Minivan, Neon and PT Cruiser only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals thanshown in Schedule B if the vehicle is operated more than 50% at sustainedhigh speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow
or commercial service.Maint enance Service Sc hedule ÒBÓ
240,0 00 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 130
