2003 BMW X5 3.0I wiper blades

Contents

Operation, maintenance
Owner service procedures

Special operating instructions:

Break-in procedures130
Driving your BMW X5131
General driving notes132
Antilock Brake System132
Brake system132

Wheels and tires:

Tire inflation pressures134
Tire condition134
Tire replacement135
Wheel and tire
combinations137
Winter tires138
Snow chains138

Under the hood:

Hood139
Engine compartment
essentials140
Washer fluid141
Engine oil141
Coolant143
Brake fluid144

Care and maintenance:

The BMW Maintenance
System145

Laws and regulations:

Technical modifications146
California Proposition
65 Warning146
OBD interface socket147

Replacement procedures:

Onboard tool kit150
Windshield wiper blades150
Lamps and bulbs151
Changing a wheel154
Battery160
Fuses160

Assistance, giving and
receiving:

Jump-starting162
Towing the vehicle164

68n
Indicator/Headlamp ßasher
Washer/Wiper system/Rain sensor
*
1High beams Ð blue indicator
2 Headlamp flasher Ð blue indicator
3 Turn signal indicators Ð green
indicator accompanied by periodic
clicking sound from the relayTo signal brieflyPress the lever up to but not beyond
the pressure point. It then returns to the
center position when released.
If the indicator lamp and the
clicking from the relay are both
faster than normal, one of the turn
signal indicators has failed.< 530de265
0Wipers retracted
1 Intermittent mode or rain sensor

2 Normal wipe
3 Fast wipe
4 Brief wipe
5 Clean the windshield
6 Special wash program
*
7 Rotary dial for control of the wipe
interval or the sensitivity of the rain
sensor
530de324
Wipers retracted Ð home positionThe left wiper is partially concealed by
the hood. In order to bring the wipers to
roughly a vertical position Ð this is
important for changing the wiper blades
or to fold the wipers out during frosty
weather, for example:
>With the lever in position 1, switch off
the ignition as soon as the wipers
come to a stop.
If equipped with a rain sensor:
1. Switch on the wipers with the lever in
position 1, 2 or 4
2. When the wipers are approx. vertical,
switch the ignition off.
For changing the wiper blades, refer to
page 150.
Fold the wipers back down onto
the windshield before you turn the
ignition key to position 1 or 2 again. If
you do not, they could be damaged.<

150n
Under the cargo area floor in a pocket.
530us106
Front 1. Move the wiper to a fold-out posi-
tion, refer to page 68
2. Lift the wiper arm and press the
securing spring, refer to arrow
3. Pull the wiper blade off toward the
wiper arm
4. Insert the new blade and snap it into
place.
Fold the wipers back down onto
the windshield before you turn the
ignition key to position 1 or 2 again. If
you do not, they could be damaged.< 530de300
Rear

1. Hold the wiper blade on the window
and remove/unclip the wiper arm at
the articulated joint, refer to arrow
2. Insert a new wiper blade and press it
on/clip it into the wiper arm.
Use only wiper blades approved
by BMW.< 530de301
Onboard tool kit Windshield wiper blades

Everything from A to ZPPark Distance Control
PDC90
Parking aid90
Parking brake20, 64
Parking lamps99
Particle filter104, 110
Passenger side mirror tilt
function51
PDC Park Distance
Control90
Please fasten safety belts
warning lamp20
Poor driving conditions131
Power loss
sliding/tilt sunroof43
Power outlets
flashlight124
other appliances124
vacuum cleaner124
Power rating168
Power rear-seat
backrests48
Power seat46
Power windows40
safety switch41
Pull-out cargo floor124
RRain sensor68
RDC Tire Pressure
Monitor97
warning lamp19, 21
Rear backrests, folding
down120
Rear lamps153
Rear passenger area climate
control109
Rear seats, power48
Rear window
defroster103, 108
Rear window wiper70
blade replacement150
Rear-seat backrest, folding
down120
Rear-seat backrests,
power48
Rearview mirrors
exterior53
interior54
Rechargeable flashlight115
Recirculated-air
mode103, 108
Reclining seat44
Refueling24, 181
Releasing
hood139
tailgate following an
electrical malfunction38Reminder signal Ð Memo83
Remote control31
computer89
Removal aid for the spare
wheel156
Removing condensation
from the
windows104, 107
Replacing
antifreeze, radiator143
bulbs151
fuses160
windshield wiper
blades150
Reporting safety defects10
Reservoir, washer
system141
Residual heat106, 109
Reverse65
Rims137
Roller sun blinds111
Roof load capacity170
Roof-mounted luggage
rack127
SSafe seating position44
with airbags44
with safety belts44
Safety belts49
height adjustment49Safety defects, reporting10
Safety lock buttons35
Seat adjustment44
Seat belts49
Seat, electric power46
Seat heating51
Seat, mechanical45
Seat memory50
Seat, mirror and steering
wheel memory50
Securing cargo38, 126
Selector lever, automatic
transmission66
Self-leveling
suspension94, 131
inactive94
warning lamp21
Service and Warranty
Information Booklet for US
models145
Service Engine Soon
indicator lamp21
Service Interval
Display76, 145
Set temperature107
Shiftlock66
Shoulder support47
Side airbags55
Side Impact Head Protection
System55
