4-15
EBU00073Rear brake pedal and lever
The brake pedal is located on the right side of
the machine and the brake lever is located on
the left handlebar. Push down on the pedal or
pull the lever toward the handlebar to apply the
rear brake.
q
q
1. Rear brake pedal1. Pédale de frein arrière1. Pedal del freno trasero
1. Rear brake lever1. Levier de frein arrière1. Palanca del freno trasero
5TH-9-60 4~5 9/25/01 4:23 PM Page 14
1. Lean towards inside of turn.
2. Support your weight on the outer footrest.1. Se pencher vers l’intérieur du virage.
2. S’appuyer sur le repose-pied externe.1. Inclínese hacia el interior del giro.
2. Descanse su peso en el descansapie externo.
7-43
As you approach a curve, slow down and begin
to turn the handlebars in the desired direction.
As you do so, put your weight on the footboard
to the outside of the turn (opposite your desired
direction) and lean your upper body into the
turn. Use the throttle to maintain an even speed
through the turn. This maneuver will let the
wheel on the inside of the turn slip slightly,
allowing the ATV to make the turn properly.
This procedure should be practiced at slow
speed many times in a large off-road area with
no obstacles. If an incorrect technique is used,
your ATV may continue to go straight. If the ATV
doesn’t turn, come to a stop and then practice
the procedure again. If the riding surface is slip-
pery or loose, it may help to position more of
your weight over the front wheels by moving for-
ward on the seat.
Once you have learned this technique you
should be able to perform it at higher speeds or
in tighter curves.
1
2
