2002 YAMAHA XVS125 transmission

3-2
EAU03034
Indicator and warning lights
Indicator lights
EAU00063
High beam indicator light “&”
High beam indicator light
This indicator light comes on when
the high beam of the headlight is
switched on.
EAU00057
Turn signal indicator light “5”
Turn signal indicator light
This indicator light flashes when the
turn signal switch is pushed to the left
or right.
EAU00061
Neutral indicator light “N”
Neutral indicator light
This indicator light comes on when
the transmission is in the neutral
position.
EAU04243
Engine trouble warning light “”
Engine trouble warning light
This warning light comes on or flash-
es when an electrical circuit monitor-
ing the engine is defective. When this
occurs, have a Yamaha dealer check
the self-diagnosis system.NOTE:
This warning light comes on for a few
seconds when the key is turned to
“ON”, but this does not indicate a
malfunction.
EAU01087
Speedometer unit The speedometer unit is equipped
with a speedometer, an odometer
and a tripmeter. The speedometer
shows riding speed. The odometer
shows the total distance traveled.
The tripmeter shows the distance
traveled since it was last set to zero
with the reset knob. The tripmeter
can be used to estimate the distance
that can be traveled with a full tank of
fuel. This information will enable you
to plan future fuel stops.
INSTRUMENT AND CONTROL FUNCTIONS
3
2040
600
km/h80
100
120140160
12 34
2040600
km/h80
100
120140160
1
23
4
1. High beam indicator light “&”
2. Turn signal indicator light “5”
3. Neutral indicator light “N”
4. Engine trouble warning light “”
1. Speedometer
2. Odometer
3. Tripmeter
4. Reset knob
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 12

3-5
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU00152
Clutch lever
Clutch lever
The clutch lever is located at the left
handlebar grip. To disengage the
clutch, pull the lever toward the han-
dlebar grip. To engage the clutch,
release the lever. The lever should
be pulled rapidly and released slowly
for smooth clutch operation.
The clutch lever is equipped with a
clutch switch, which is part of the igni-
tion circuit cut-off system. (See page
3-11 for an explanation of the ignition
circuit cut-off system.)
EAU00157
Shift pedal
Shift pedal
The shift pedal is located on the left
side of the engine and is used in
combination with the clutch lever
when shifting the gears of the
5-speed constant-mesh transmission
equipped on this motorcycle.
EAU00158
Brake lever
Brake lever
The brake lever is located at the right
handlebar grip. To apply the front
brake, pull the lever toward the han-
dlebar grip.
1
1
1
1. Clutch lever 1. Shift pedal 1. Brake lever
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 15

3-11
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU03720
Ignition circuit cut-off
system
Ignition circuit cut-off system
The ignition circuit cut-off system
(comprising the sidestand switch,
clutch switch and neutral switch) has
the following functions.
8It prevents starting when the
transmission is in gear and the
sidestand is up, but the clutch
lever is not pulled.
8It prevents starting when the
transmission is in gear and the
clutch lever is pulled, but the
sidestand is still down.
8It cuts the running engine when
the transmission is in gear and
the sidestand is moved down.
Periodically check the operation of
the ignition circuit cut-off system
according to the following procedure.
EW000045
wIf a malfunction is noted, have a
Yamaha dealer check the system
before riding.
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 21

3-12
INSTRUMENT AND CONTROL FUNCTIONS
3
With the engine turned off:
1. Move the sidestand down.
2. Make sure that the engine stop switch is set to “
#”.
3. Turn the key to “ON”.
4. Shift the transmission into the neutral position.
5. Push the start switch.
Does the engine start?
The neutral switch may be defective.
The motorcycle should not be ridden until
checked by a Yamaha dealer.
With the engine still running:
6. Move the sidestand up.
7. Keep the clutch lever pulled.
8. Shift the transmission into gear.
9. Move the sidestand down.
Does the engine stall?After the engine has stalled:
10. Move the sidestand up.
11. Keep the clutch lever pulled.
12. Push the start switch.
Does the engine start?
The sidestand switch may be defective.
The motorcycle should not be ridden until
checked by a Yamaha dealer.The clutch switch may be defective.
The motorcycle should not be ridden until
checked by a Yamaha dealer.
NO
NOTE:This check is most reliable if performed with
a warmed-up engine.
YESYES NO
The system is OK. The motorcycle can be ridden.
YES NO
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 22

5-1
EAU00372
OPERATION AND IMPORTANT RIDING POINTS
5
EAU00373
w8Become thoroughly familiar
with all operating controls and
their functions before riding.
Consult a Yamaha dealer
regarding any control or func-
tion that you do not thorough-
ly understand.
8Never start the engine or oper-
ate it in a closed area for any
length of time. Exhaust fumes
are poisonous, and inhaling
them can cause loss of con-
sciousness and death within a
short time. Always make sure
that there is adequate ventila-
tion.
8Before starting out, make sure
that the sidestand is up. If the
sidestand is not raised com-
pletely, it could contact the
ground and distract the opera-
tor, resulting in a possible loss
of control.
EAU03515
Starting the engine
Starting the engine
In order for the ignition circuit cut-off
system to enable starting, one of the
following conditions must be met:
8The transmission is in the neutral
position.
8The transmission is in gear with
the clutch lever pulled and the
sidestand up.
EW000054
w8Before starting the engine,
check the function of the igni-
tion circuit cut-off system
according to the procedure
described on page 3-12.
8Never ride with the sidestand
down.
1. Turn the fuel cock lever to “ON”.
2. Turn the key to “ON” and make
sure that the engine stop switch
is set to “#”.
3. Shift the transmission into the
neutral position.NOTE:
When the transmission is in the neu-
tral position, the neutral indicator light
should be on, otherwise have a
Yamaha dealer check the electrical
circuit.
1
1. Arrow mark positioned over “ON”
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 26

5-3
OPERATION AND IMPORTANT RIDING POINTS
5
EAU00423
Shifting
Shifting
Shifting gears lets you control the
amount of engine power available for
starting off, accelerating, climbing
hills, etc.
The gear positions are shown in the
illustration.NOTE:
To shift the transmission into the neu-
tral position, press the shift pedal
down repeatedly until it reaches the
end of its travel, and then slightly
raise it.
EC000048
cC8Even with the transmission in
the neutral position, do not
coast for long periods of time
with the engine off, and do not
tow the motorcycle for long
distances. The transmission is
properly lubricated only when
the engine is running.
Inadequate lubrication may
damage the transmission.
8Always use the clutch while
changing gears to avoid dam-
aging the engine, transmis-
sion, and drive train, which are
not designed to withstand the
shock of forced shifting.
EAU02941
Recommended shift points
(for Switzerland only)
Shift points (for Switzerland only)
The recommended shift points during
acceleration are shown in the table
below.NOTE:
When shifting down two gears at a
time, reduce the speed accordingly
(e.g., down to 35 km/h when shifting
from 4th to 2nd gear).
1 N2 3 4 5
1
1. Shift pedal
N. Neutral position
Shift point
(km/h)
1st→2nd
2nd→3rd
3rd→4th
4th→5th23
36
50
60
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 28

6-25
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00744
Drive chain slack
Drive chain slack
The drive chain slack should be
checked before each ride and adjust-
ed if necessary.
To check the drive chain slack
Checking
1. Place the motorcycle on a level
surface and hold it in an upright
position.NOTE:
When checking and adjusting the
drive chain slack, the motorcycle
should be positioned straight up and
there should be no weight on it.
2. Shift the transmission into the
neutral position.
3. Move the rear wheel by pushing
the motorcycle to locate the tight-
est portion of the drive chain,
and then measure the drive
chain slack as shown.
4. If the drive chain slack is incor-
rect, adjust it as follows.
EAU03780
To adjust the drive chain slack
1. Loosen the brake pedal free play
adjusting nut, axle nut, and lock-
nut at each end of the swingarm.
a
21
a. Drive chain slack 1. Brake pedal free play adjusting nut
2. Locknut
Drive chain slack:
30–40 mm
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 55

8-2
SPECIFICATIONS
8
Fuel
Type Regular unleaded gasoline
Fuel tank capacity 11 L
Reserve amount 3.4 L
Carburetor
Manufacturer MIKUNI
Model ×quantity BDS26 ×1
Spark plug
Manufacturer/model NGK/CR7HSA or
DENSO/U22FSR-U
Gap 0.6–0.7 mm
Clutch typeWet, multiple-disc
Transmission
Primary reduction system Spur gear
Primary reduction ratio 3.400
Secondary reduction system Chain drive
Secondary reduction ratio 3.688
Number of drive chain
sprocket teeth (rear/front) 59/16
Transmission type Constant mesh 5-speed
Operation Left foot operationGear ratio 1st 2.643
2nd 1.684
3rd 1.261
4th 1.000
5th 0.852
Chassis
Frame type Double cradle
Caster angle 35°
Trail 135 mm
Tires
Front
Type With tube
Size 80/100-18 47P
80/100-18 M/C 47P
Manufacturer/ CHENG SHIN/C-916
model INOUE/MARBELLA NF27
Rear
Type With tube
Size 130/90-15 M/C 66P
Manufacturer/ CHENG SHIN/C-915
model INOUE/MARBELLA NR31
