2-1
2
EAU00026
2-DESCRIPTION Left view1. Front fork spring preload adjusting bolt (page 3-13)
2. Front fork damping force adjusting screw (page 3-14)
3. Air filter element (page 6-16)
4. Shock absorber assembly spring
preload adjusting ring (page 3-15)
5. Battery (page 6-33)
6. Fuses (page 6-34)
7. Storage compartment (page 3-11)
8. Grab bar9. Luggage strap holder (page 3-17)
10. Seat lock (page 3-11)
11. Shock absorber assembly rebound
damping force adjusting knob (page 3-15)
12. Shock absorber assembly compression
damping force adjusting knob (page 3-16)
13. Shift pedal (page 3-8)
14. Engine oil drain bolt A (page 6-10)
